Related Manuals for DSC Power632

Summary of Contents for DSC Power632

  • Page 1: Installation Manual

    WARNING This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read. Installation Manual PC1565 Software Version 2.4ZD DLS-3 v1.3 and higher...

  • Page 2: Warning Please Read Carefully

    System Users freight cost to the repair centre; (ii) products which are not identified with DSC's product label and lot num- A user may not be able to operate a panic or emergency switch possibly due to permanent or temporary ber or serial number;...

  • Page 3: Table Of Contents

    Table of Contents Section 1: System Introduction 5.4 Assigning Keypad Zones ..........17 1.1 Specifications ................1 5.5 Zone Doubling ..............17 1.2 Additional Devices ..............2 5.6 Communicator – Dialing ..........17 1.3 Out of the Box ...............2 5.7 Communicator – Account Numbers ......18 5.8 Communicator –...
  • Page 4 PC1565 Wiring Diagram...

  • Page 5: Section 1: System Introduction

    Se c tion 1: Sy s t e m Int ro du c ti on Specifications Digital Communicator Specifications • Supports major communication formats including SIA and Downloading Software Support Contact ID • PC1565 v2.4ZD uses DLS-3 v1.3 and higher. •...

  • Page 6: Additional Devices

    The PC5208 adds eight low current outputs (50mA) to the In addition to the information below, see the back cover for a control panel. Each output is individually programmable with DSC module compatibility table. PGM output options. Please refer to section 5.12 ‘PGM Output PC5132 Wireless Receiver Options’...

  • Page 7: Section 2: Getting Started

    High Current/Standard Battery Charge ..Section [701]: [7] into the cabinet from the back. After you have attached the cabinet to the wall, stick the provided DSC logo sticker on the NOTE:Do not connect the battery until all other wiring is com- front of the cabinet.

  • Page 8: Keybus Operation And Wiring

    Programmable Output Terminals – PGM1 and PGM2 • Any module can be connected anywhere along the Key- Each PGM output is designed so that when activated by the bus. You do not need to run a separate Keybus wire for panel, the terminal will switch to ground keypads, etc.

  • Page 9: Supervision

    G e t t i n g S t a r t e d : 2 . 6 S u p e r v i s i o n 2. Enter [000] for Keypad Programming NOTE: Any zone programmed for Fire or 24-hr Supervisory must be wired with a single End of Line (EOL) resistor regard- 3.

  • Page 10: Zone Doubling

    2.10 Fire Zone Wiring ANY Z ANY COM NOTE:4-Wire Smoke Detectors TERMINAL TERMINAL DOUBLE EOL CIRCUIT All fire zones must be wired according to the following diagram: 1 NORMALLY CLOSED CONTACT WITH 5600 END-OF-LINE RESISTORS NOTE: This option can only be selected if Normally Closed (NC) detection devices or contacts are being used.
  • Page 11 G e t t i n g S t a r t e d : 2 . 1 3 K e y p a d Z o n e s Assigning Keypad Zones When using keypad zone inputs, each input used must be assigned a zone number in Installer’s Programming.

  • Page 12: Section 3: Keypad Commands

    Section 3: Keypad Commands Use any system keypad to enter commands and/or program Automatic Arming the PC1565 security system. The LED keypad uses function The system can be programmed to Auto-Arm at a specific and zone indicator lights to represent alarm functions and sta- time every day if it is in the disarmed condition.
  • Page 13 K e y p a d C o m m a n d s : 3 . 4 [ * ] C o m m a n d s Activate Stay/Away Zones from enrolled devices. If the system detects jamming signals If the system is armed in stay mode, the [*][1] command can for longer than 30 seconds, the Trouble (or System) light will be used to activate the stay/away zones.
  • Page 14 [*][3] Alarm Memory Attribute [1] ..User enabled for arming, disarming, alarm The Memory (or System) light will be on if any alarm occurred reset, [*][7][1-2] options, auto-arm cancel- during the last armed period or – in the case of 24-hr zones – lation if an alarm occurred while the panel was disarmed.

  • Page 15: Function Keys

    K e y p a d C o m m a n d s : 3 . 5 F u n c t i o n K e y s Viewing the Event Buffer from an LCD Keypad having to disarm and re-arm the system. (See 5.18 ‘Arming/ Select “View Event Buffer”...

  • Page 16: Features Available For The Lcd5500Z

    [00] Null Key: The key is not used and will perform no Features Available for the LCD5500Z function when pressed. These features are only available for LCD5500Z keypads with [01]-[02] For future use zone inputs: [03] Stay Arm: As described above. Automatic Scrolling of Alarms in Memory [04] Away Arm: As described above.

  • Page 17: Section 4: How To Program

    Se c t ion 4 : H o w t o P ro g r am The following section of the manual describes the Installer’s Programming Decimal Data Programming function and how to program the various sec- A set number of programming boxes are allotted for each sec- tions.

  • Page 18: Programming Toggle Option Sections

    Programming Toggle Option Sections The keypad displays the information using a binary format, according to the following chart: See Hex data Some programming sections contain several toggle options. entry instructions The panel will use zone lights 1 through 8 to indicate if the dif- ferent options are enabled or disabled.

  • Page 19: Section 5: Program Descriptions

    Section 5: Program Descriptions The following section explains the operation of all programma- should be disarmed. If the panel is disarmed before the entry ble features and options and provides a summary of all corre- time expires, no alarm will be generated. sponding programming locations.

  • Page 20: Zone Attributes

    NOTE:If a second Fire type zone is violated or if the Fire keys [24] GSM Answer Zone are pressed during the delay period, the panel will latch the Downloading can be performed via the GSM1000 Cellular Communicator (if used) when the conventional telephone line alarm output and will immediately communicate the alarm.

  • Page 21: Assigning Keypad Zones

    P r o g r a m D e s c r i p t i o n s : 5 . 4 A s s i g n i n g K e y p a d Z o n e s garage door open.

  • Page 22: Communicator - Account Numbers

    Communicator Enable/Disable ..Section [380]: [1] Communicator – Reporting Codes Communicator Call Direction Options . . . Section [361]-[368] The panel can be programmed to report events to the central Force Dialing ......Section [702]: [2] station by sending the Reporting Code programmed for a Delay Between Dialing Attempts.

  • Page 23: Communicator - Reporting Formats

    P r o g r a m D e s c r i p t i o n s : 5 . 1 0 C o m m u n i c a t o r – R e p o r t i n g F o r m a t s AC Failure Trouble Alarm Code pulse formats and two 10 BPS formats are supported, in addi-...

  • Page 24: Downloading

    If the Contact ID uses Automatic Reporting Codes option is telephone number with the Pager Format selected, the panel enabled, the panel will operate as follows: will attempt to page. 1. If an event’s reporting code is programmed as [00], the When calling a pager, extra digits will be required in order for panel will not attempt to call the central station.

  • Page 25: Pgm Output Options

    P r o g r a m D e s c r i p t i o n s : 5 . 1 2 P G M O u t p u t O p t i o n s If the Answering Machine/Double Call option is enabled (or Downloading Access Code .
  • Page 26 [09] System Trouble Output [12] TLM and Alarm The PGM output will activate when any of the selected trouble The PGM output activates when the system experiences both conditions are present. It will deactivate when all the selected a telephone line trouble and an alarm. When the system is trouble conditions are cleared.

  • Page 27: Telephone Line Monitor (Tlm)

    P r o g r a m D e s c r i p t i o n s : 5 . 1 3 T e l e p h o n e L i n e M o n i t o r ( T L M ) 5.13 Telephone Line Monitor (TLM) entered, and the PGM2 Alarm reporting code will be sent to...

  • Page 28: Transmission Delay

    Minutes/Days allows you to select whether the Land Line Test NOTE:The Fire, Auxiliary, Panic keys will operate even if Keypad Transmission cycle will be counted in minutes or days. If you Blanking is active (See 5.23 ‘Keypad Blanking’ on page 26.) have selected the test transmission cycle to be in minutes, the Test Transmission Time of Day counter will not apply.

  • Page 29: Entry/Exit Delay Options

    P r o g r a m D e s c r i p t i o n s : 5 . 1 9 E n t r y / E x i t D e l a y O p t i o n s To prevent disarming by wireless keys which don’t have exit delay will be terminated and the panel will be armed access codes, disable this option.

  • Page 30: Keypad Blanking

    5.23 Keypad Blanking • as the sole communicator for the panel • as a backup for either or both telephone numbers If the Blank Keypad When Not in Use option is enabled, the • as a redundant backup to the land line communicator, panel will turn off all lights and LCDs on the keypads when no where the panel will call using the land line and the GSM.

  • Page 31: Additional System Modules

    P r o g r a m D e s c r i p t i o n s : 5 . 2 8 A d d i t i o n a l S y s t e m M o d u l e s 5.31 Resetting Factory Defaults Please refer to the GSM1000 installation Manual for more...

  • Page 32: Installer's Lockout

    5.32 Installer’s Lockout To perform a walk test: Step 1 - Enter Installer Programming If Installer’s Lockout is selected, a hardware default cannot Step 2 - Enter Section [901] be performed. If a software default is performed, all program- ming will restore to factory default. When any zone is violated the panel will activate the Bell Out- put for two seconds, log the event to the event buffer and If Installer’s Lockout Disable is selected, the panel will...

  • Page 33: Section 6: Programming Worksheets

    Section 6: Programming Worksheets For the Record Customer: _______________________________________________________________________________________________________ Address: ________________________________________________________________________________________________________ Telephone: ___________________________________________ Installation Date: ___________________________________________ Installer’s Code: __________________________________________________________________________________________________ Module Name Description Location PC1565 Main Panel I________________________________________________________________________________________________________________I PC5132 Wireless Receiver I________________________________________________________________________________________________________________I PC5400 Serial Printer Module I________________________________________________________________________________________________________________I GSM1000 Cellular Communicator I________________________________________________________________________________________________________________I LINKS2X50 Long Range Radio I________________________________________________________________________________________________________________I...

  • Page 34: Zone Programming Summary

    Zone Programming Summary Zone programming can be found in sections [001] - [004], [101] - [132], [020] and [202] - [205]. Use this area to record a sum- mary of your zone programming. Refer to Appendix B: ‘Programming LCD Keypads’ on page 46, for instructions on programming zone labels.
  • Page 35 P r o g r a m m i n g W o r k s h e e t s Keypad Programming [000] Keypad Enrollment (Section 2.5 “Keypad Assignment” on page 4) NOTE: This must be done at each keypad requiring programming. [0] Slot [Valid entries are 11-18;...
  • Page 36 [002] Zone 9-16 Definitions (Section 5.2 “Zone Programming” on page 15) Default Default Zone 9 Zone 13 I_______I_______I I_______I_______I Zone 10 Zone 14 I_______I_______I I_______I_______I Zone 11 Zone 15 I_______I_______I I_______I_______I Zone 12 Zone 16 I_______I_______I I_______I_______I [003] Zone 17-24 Definitions (Section 5.2 “Zone Programming”...
  • Page 37 P r o g r a m m i n g W o r k s h e e t s [010] PC5208 PGM Output Programming (Section 5.10 “PGM Outputs”) Default Default PGM 3 PGM 7 I_______I_______I I_______I_______I PGM 4 PGM 8 I_______I_______I I_______I_______I...
  • Page 38 [016] Fourth System Option Code Default Option Section Page # AC Trouble Displayed AC Trouble Not Displayed I________I Trouble Light Flashes if AC Fails Trouble Light Does Not Follow AC Status I________I Blank Keypad When Not Used Keypad Active Always 5.23 I________I Code Required to Remove Kypd BlankingNo Code Required...
  • Page 39 P r o g r a m m i n g W o r k s h e e t s Advanced System Programming Zone Attributes (Section 5.3 “Zone Attributes” on page 16) Zone Attribute Defaults (Y = Option ON; N = Option OFF): Attribute: Audible Steady...
  • Page 40 [116] I________I I________| I________| I________| I________| I________| I________| I________I [117] I________I I________| I________| I________| I________| I________| I________| I________I [118] I________I I________| I________| I________| I________| I________| I________| I________I [119] I________I I________| I________| I________| I________| I________| I________| I________I [120] I________I I________| I________| I________| I________| I________|...
  • Page 41 P r o g r a m m i n g W o r k s h e e t s Section PGM Output Type* [141] I________I I________| I________| I________| I________| I________| I________| I________I [142] I________I I________| I________| I________| I________| I________| I________| I________I...
  • Page 42 Alarm Restoral Reporting Codes, Zones 1-32 (Section 5.9 “Communicator – Reporting Codes” on pg. 18, & Appendix A) Section [324] Zone 1 Zone 2 Zone 3 Zone 4 Zone 5 Zone 6 Zone 7 Zone 8 I_______I_______I I_______I_______I I_______I_______I I_______I_______I I_______I_______I I_______I_______I I_______I_______I...
  • Page 43 P r o g r a m m i n g W o r k s h e e t s Closing (Arming) Reporting Codes, Access Codes 1-32 (Section 5.9 “Communicator – Reporting Codes” on pg. 18, & Appendix A) Section [339] Code 1...
  • Page 44 [352] Test Transmission Reporting Codes (Section 5.9 “Communicator – Reporting Codes” on pg. 18, & Appendix A) 1. Periodic Test Transmission 3. GSM1000 Test Transmission Code* I_______I_______I I_______I_______I 2. System Test I_______I_______I *The GSM Test Transmission Code must be programmed as “00” for the GSM Test Transmission to be disabled. [353] Wireless Maintenance Reporting Codes (Section 5.9 “Communicator –...
  • Page 45 P r o g r a m m i n g W o r k s h e e t s [370] Communication Variables Default Section Page # Swinger Shutdown (Alarms and Rest) (001-014 Transmissions, 000=disabled) 5.20 I_______I_______I_______I Swinger Shutdown (Tampers and Rest)(001-014 Transmissions, 000=disabled) 5.20 I_______I_______I_______I Swinger Shutdown (Maint and Rest) (001-014 Transmissions, 000=disabled)
  • Page 46 Downloading Options [401] First Downloading Option Code (Section 5.11 “Downloading” on page 20) Default Option Answering machine/double call enabledAnswering machine/double call disabled I_______I User Can Enable DLS Window User Cannot Enable DLS Window I_______I Call-Back Enabled Call-Back Disabled I_______I User-initiated Call-up Enabled User-initiated Call-up Disabled I_______I For future use...
  • Page 47 Module Programming [801] PC5400 Printer Module Programming Please refer to your PC5400 Installation Manual for installation and programming instructions. [803] Alternative Communicator Programming Please refer to your LINKS2X50 Installation Manual for installation and programming instructions. [804] PC5132 Wireless Expansion Programming Please refer to your PC5132 Installation Manual for programming locations and instructions.

  • Page 48: Appendix A: Reporting Codes

    Appendix A: Reporting Codes The following tables contain Contact ID and Automatic SIA for- SIA Format - Level 2 (Hardcoded) mat reporting codes. For more information on reporting code The SIA communication format used in this product follows the formats and notes about individual reporting codes, see sec- level 2 specifications of the SIA Digital Communication Stan- tions 5.9 ‘Communicator –...
  • Page 49 Dialer Contact SIA Auto Rep Section # Reporting Code Code Sent When... Direction* ID Codes Codes** [349-350] AC Line Trouble/Rest. AC power to control panel is disconnected or inter- MA/R (3) A1 AT-00/AR-00 rupted/AC power restored (Both codes follow AC Fail- ure Comm.

  • Page 50: Appendix B: Programming Lcd Keypads

    Appendix B: Programming LCD Keypads If you have an LCD5500Z Keypad, additional programming is required for proper operation. The following is a description of the available programming options and their accompanying programming sections: How to Enter LCD Programming Follow the programming procedure as outlined in Section 4 by pressing [*][8][Installer’s Code]. Press the [*] key. Enter the two digit Section number to be programmed.
  • Page 51 P r o g r a m m i n g L C D K e y p a d s : 5 . 3 3 W a l k T e s t ( I n s t a l l e r ) [62] Third User Display Mask Default Option...
  • Page 52 (See ‘[*][5] functions with other software versions. Programming Access Codes’ on page 10.) Direct all comments concerning this ©2002 Digital Security Controls Ltd. publication to pubs@dscltd.com. Toronto, Canada • www.dsc.com Printed in Canada 29005155 R002...
