Team C T8TE Instructions And Tips page 7

5
Front/Rear Differential
x2
T08633
20T Diff Gear
T08633
2.5x11.5 Pin
T08669 6.1x11x0.2
T08600 5.8x1.9
T08600
Differential Housing
T08664 8x16x5
T08634
Diff Connecting Cup
T08600/T08636 5.8x1.9 O-Ring
.....................4
6
Front Differential Case
Bag
T08601
Differential Case
T08663 6x13x5
T08663 6x13x5
T08636
10T Gear
T08673 M3x16
Apply threadlock
Screw
Cement
C
-
Bag
T08633
T08633 4.1x12x0.2
10T Diff Gear
T08633
Diff Shaft
7000# for Front
3000# for Rear
T08633 4.1x12x0.2 Washer
............8
C D
- -
Bag
TG8016
87mm Center Front CVD
Screw
Cement
TG8016 M5x4
Assemble as many times as specified
x2
T08633
2.5x11.5 Pin
T08669 6.1x11x0.2 Washer
............4
T08304
13.1x15.9x0.2
T08601
Differential Case
3
T08633
20T Diff Gear
T08669 6.1x11x0.2
T08600
Differential Pads
T08636 5.8x1.9
T08636
43T Diff Gear
T08664 8x16x5
T08634
Diff Connecting Cup
T08664 8x16x5 Ball Bearing
T08636 M3x12 Screw
.........4
T08663 6x13x5 Ball Bearing
T08304 13.1x15.9x0.2 Washer
T08673 M3x16 Screw
TG8016 M5x4 Screw
T08636 M3x12
......8
.........2
............2
......2
..................1
