Team C T8TE Instructions And Tips page 6

3
Servo Saver Post/Side Plate
Bag
TG8003
Side Plate-Right
T08674 M3x8
T08674 M4x10
Screw
Cement
A
-
4
Buffer
Bag
T08673 M3x8
T08761
Buffer Plate-Plastic
T08761
Buffer Plate-Aluminium
T08666 M3
T08674 M3x8 Screw
..................1
T08674 M3x10 Screw
............1
T08674 M3x12 Screw
............1
T08674 M3x14 Screw
.........1
T08674 M4x10 Screw
............2
T08662 6x10x3 Ball Bearing
..................4
T08666 M3 Nylon Nut
.....................3
Apply threadlock
Screw
Cement
A B
- -
Bag
T08650
Servo Saver Post
T08662
6x10x3
T08662 6x10x3
T08674 M4x10
Screw
T08674 M3x14
T08674 M4x10
TG8006
Front Chassis Stiffener
T08666 M3
T08674 M3x10
2
T08674 M3x8
T08674 M3x8 Screw
T08674 M4x10 Screw
Screw
Cement
T08674 M3x12
TG8027
Chassis
TG8003
Side Plate-Left
............7
............2
