Team C T8TE Instructions And Tips page 11

13
Steering Turnbuckle
Bag
Steering-Left
1:1 x1
Steering-Right
1:1 x1
TG8020 4x86 Turnbuckle
14
Front Upper/Steering Turnbuckle
Front Upper Turnbuckle-Right
T08674 M3x16 Screw T08666 M3 Nylon Nut
......2
True - to - scale diagram
1:1
D
-
.........2
D
-
Bag
Steering Turnbuckle-Right
T08666 M3
T08666 M3
T08676 M3x25 Screw
............6
Assemble as many times as specified
x1
Approx.64.5mm
▲Projection.Note direction
Approx.64.5mm
▲Projection.Note direction
T08753 6.8 Ball stud T08754 6.8 Ball stud T08760 6.8 Ball End-Steering
............2
Steering Turnbuckle-Left
Front Upper Turnbuckle-Left
T08676 M3x18 Screw
......2
7
............2
......2
......4
