Fluke 867B Service Manual

Hide thumbs Also See for 867B:
Table of Contents

Advertisement

Quick Links

See also: User Manual
®
867B,863
Graphical Multimeters

Service Manual

PN 689312
December 1997
© 1997 Fluke Corporation, All rights reserved. Printed in U.S.A.
All product names are trademarks of their respective companies.

Advertisement

Table of Contents
loading

Related Manuals for Fluke 867B

Summary of Contents for Fluke 867B

  • Page 1: Service Manual

    ® 867B,863 Graphical Multimeters Service Manual PN 689312 December 1997 © 1997 Fluke Corporation, All rights reserved. Printed in U.S.A. All product names are trademarks of their respective companies.
  • Page 2 Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price.

  • Page 3: Table Of Contents

    Table of Contents Chapter Title Page Introduction and Specifications ..................1-1 1-1 .. Introduction ......................1-3 1-2. Description ......................1-3 1-3. Power Requirements ....................1-3 1-4. Options, Accessories and Related Equipment ............1-4 1-5. Operating Instructions .................... 1-4 1-6. Obtaining Service ....................1-4 1-7.
  • Page 4 Perfomance Testing and Calibration ................. 4-1 4-1. Introduction ......................4-3 4-2. Required Test Equipment ..................4-3 4-3. Alternative Test Equipment (Fluke 5500A) ............4-3 4-4. Performance Tests ....................4-4 4-5. mV DC Test ......................4-4 4-6. DC Volts Test ......................4-6 4-7.
  • Page 5 Contents (continued) 4-14. Amps Tests ......................4-16 4-15. Peak Hold Test ......................4-19 4-16. Component Test (867B Only) ................4-19 4-17. Rel Test/Touch Hold Test ..................4-20 4-18. Glitch Capture Test ....................4-21 4-19. External Trigger Test ....................4-21 4-20.
  • Page 6 List of Tables Table Title Page 1-1. Power Sources ......................1-4 1-2. Accessories Included with Each GMM ..............1-4 2-1. Power Supply Inputs....................2-4 2-3. Power Supply Signals....................2-7 2-4. Power Source Detection ..................2-9 2-5. Average Converter....................2-15 2-6. RMS Converter (U3) ....................
  • Page 7 List of Figures Figure Title Page 1-1. Temperature and Humidity..................1-7 2-1. Block Diagram......................2-5 2-2. Power Supply Blocks ....................2-11 2-3. Keypad Connections....................2-25 3-1. Disassembly......................3-5 3-2. Reassembly......................3-8 3-3. Replacing the 400 mA Fuse..................3-9 4-1. Configuration 1 (mV DC) ..................4-5 4-2.
  • Page 8 Chapter 1 Introduction and Specifications Title Page 1-1. Introduction..................... 1-3 1-2. Description ....................1-3 1-3. Power Requirements ................1-3 1-4. Options, Accessories and Related Equipment......... 1-4 1-5. Operating Instructions................1-4 1-6. Obtaining Service..................1-4 1-7. Conventions Used in This Manual ............1-5 1-8.

  • Page 9: Introduction And Specifications

    • List of Replaceable Parts (Chapter 5): • Schematic Diagrams and component locators (Chapter 6): The information in this manual is applicable to both the 867B and 863 models unless otherwise indicated. Description 1-2. The Fluke 867B and 863 Graphical Multimeters (GMMs) provide full digital multimeter (DMM) capabilities along with graphical waveform displays and trend plotting.

  • Page 10: Options, Accessories And Related Equipment

    GMM will be repaired and returned for a fixed fee. Contact the nearest Service Center for information and prices. A list of U.S. and International Service Centers is available on the World Wide Web at www.fluke.com. Refer to Chapter 3 for a list of Fluke telephone numbers.

  • Page 11: Conventions Used In This Manual

    • “GMM” refers to all Graphical Multimeter models in the 860 Series. • “863” and “867B” are specifically mentioned where a description does not apply to all models in the 860 Series. • A “pca” is a printed circuit board and its attached parts.

  • Page 12: Specifications

    Service Manual Specifications 1-9. General Display: LCD - Dot Matrix, 240 X 200 pixels Fluke 867B: Transmissive, Backlit Fluke 863: Reflective Temperature Operating: 0°C to 50°C (See Figure 1-1.) Storage: -20°C to 60°C (Batteries Removed) Charging: 0 to 45°C Temperature Coefficient: (0.1 X % Accuracy) per °C (0°C to 18°C and 28°C to 59°C) Relative Humidity: 0% to 90% non-condensing Altitude Operating/Non-operating: 6,562 ft.

  • Page 13: Introduction And Specifications

    = Storage (-20 C — 60 C) ° ° = Normal Operation (0 C — 50 C) os1f.eps Figure 1-1. Temperature and Humidity Power Fluke 867B Fluke 863 Battery Eliminator/Charger Optional Eliminator only Optional BP7217 Battery NiCd Battery Pack Pack Optional BC7210 Ext. Charger...
  • Page 14 867B,863 Service Manual Resolution and Accuracy The following specifications apply within 1 year of calibration when operating in a temperature range of 18°C (64°F) to 28°C (82°F). AC Volts (True RMS, AC-Coupled) [±(percent of reading + counts)] Frequency Range Res.
  • Page 15 Reference: 2, 4, 8, 16, 50, 75, 93, 110, 125, 135, 150, 300, 600, 900, 1000, and 1200Ω Overload Protection: 1000V rms DC Volts [±(percent of reading + counts)] Function Range Res. Fluke 867B Fluke 863 300.00 mV 0.01 mV 0.025% + 2 0.04% + 2 mV DC 3000.0 mV...
  • Page 16 0.2% + 15 1 mA 0.2% + 2 1. Ranges available on the Fluke 867B only. 2. Fluke 863 30 mA DC range accuracy 0.1% + 15. AC Current Accuracy [±(percent of reading + counts)] Range Resolution True RMS AC Current Accuracy (Average AC counts) True RMS Avg.
  • Page 17 Introduction and Specifications Specifications Conductance [±(percent of reading + counts)] Open Circuit Range Resolution Accuracy Voltage 300.00 nS 0.01 nS 0.5% + 20 3.2V 3000.0 nS 0.1 nS 0.5% + 20 3.2V Overload Protection: 1000V rms Capacitance [±(percent of reading + counts)] Range Resolution Accuracy...
  • Page 18 867B,863 Service Manual Frequency AC Sensitivity AC Volts AC Current Frequency Sine Wave Frequency Ranges Sine Wave Level Level 300 µA - 300 mA 2 Hz - 500 kHz 60 mV rms 5 Hz - 30 kHz 20% of range...

  • Page 19: Frequency Measurements

    Introduction and Specifications Specifications Logic (Fluke 867B Only) Trigger Levels Logic Family High 3V CMOS 1.4V 1.7V 5V CMOS 2.6V 2.8V 1.7V 1.9V 1. Frequency measurements will trigger on the logic family high levels. All measurements are made using the Logic/Ext. Trig. input jack.
  • Page 20 867B,863 Service Manual Component Test Frequency Capacitance 0.72 µF to 72 µF 2 Hz 20 Hz 0.072 µF to 7.2 µF 200 Hz 7200 pF to 0.72 µF 2 kHz 720 pF to 0.072 µF 18.75 kHz 77 pF to 7700 pF Peak Hold Captures peak minimums and maximums of signals ≥10 µs.

  • Page 21: Theory Of Operation

    Chapter 2 Theory of Operation Title Page 2-1. Introduction..................... 2-3 2-2. Start-Up Sequence ................2-3 2-3. Function Selection ................2-3 2-4. Power Supply ..................2-4 2-5. Power Supply Input Voltages ............. 2-4 2-6. Power Supply Output Voltages and Currents........2-6 2-7.
  • Page 22 867B,863 Service Manual 2-37. Waveform Triggering................2-20 2-38. Overview..................... 2-20 2-39. Dual Trigger..................2-20 2-40. Single Trigger ..................2-21 2-41. External Trigger.................. 2-21 2-42. Glitch Capture..................2-22 2-43. Single Shot..................2-22 2-44. Frequency Trigger ................2-22 2-45. Logic Activity Trigger ................ 2-22 2-46.

  • Page 23: Introduction

    Theory of Operation Introduction Introduction 2-1. This chapter describes the functional blocks shown in Figure 2-1. Overall descriptions are broken down into Power Supply, Analog Circuitry, and Digital Circuitry. For all measurements, inputs (e.g., Ë and â) are applied through overvoltage (and overcurrent) protection circuits, switched to an appropriate range, and branched into two signal paths.

  • Page 24: Power Supply

    The NiCd battery pack recharges in a minimum of 16 hours when the GMM is not operating or at a trickle rate while the GMM is operating. Only cells in the Fluke BP7217 battery pack can be charged internally. Internal charging is not available with Model 863.

  • Page 25: Block Diagram

    Theory of Operation Power Supply os2f..eps Figure 2-1. Block Diagram...

  • Page 26: Power Supply Output Voltages And Currents

    867B,863 Service Manual Power Supply Output Voltages and Currents 2-6. Refer to Table 2-2. Table 2-2. Power Supply Outputs Ripple Name Voltage Tol ± ± ± ± V Tol ± ± ± ± % Power Notes (peak to peak) 5.2V 0.26...

  • Page 27: Power Supply Signals

    Table 2-3. Power Supply Signals Signal Name Description BACKLIGHT_ON* Control signal generated by U25. In Model 867B, this signal toggles the backlight power levels. BATT_LVL Monitors an attenuated (0 to 5V) version of the raw battery voltage. This signal is monitored by the U25 microprocessor A/D Converter.

  • Page 28: Power On/Off Requirements

    NiCd Charging Requirements 2-9. Models 867B use an internal two-state charger. The initial charge state is at approximately 170 mA (±30 mA) to allow for full overnight charging (16 hours minimum). The second charge state is at approximately 40 mA (±15 mA) to allow for battery charge maintenance without full charging from a discharged condition.

  • Page 29: Power Source Detection

    Theory of Operation Power Supply Functional Blocks Table 2-4. Power Source Detection LOW BATTERY SOFT POWER- SCALE POWER TYPE DETECTION FACTOR Battery Eliminator connected BATT_ELIM 0.0951 ≥ 1.0 Volts NiCd Battery Pack installed BATT_TYPE 6.2V 5.7V 0.0909 5 ≤ V ≤10.5 Volts Alkaline (AA) Batteries installed BATT_TYPE 6.2V...

  • Page 30: Boost Preregulator (B)

    This prevents excessive power dissipation in Q22 with a dead battery or shorted cells. Note The Fluke battery pack (BP7217) uses an extra wire to allow charging current to flow. If individual batteries are installed, no connection is made, and no charging current can flow.

  • Page 31: Power Supply Blocks

    Theory of Operation Power Supply Functional Blocks os3f.eps Figure 2-2. Power Supply Blocks 2-11...

  • Page 32: Dc-Dc Converter (D)

    867B,863 Service Manual DC-DC Converter (D) 2-15. The DC-DC converter is a conventional push-pull transformer couple type. The center tap of T1 is fed from the +15 from the boost preregulator. Q16 drives one side or the other of the primary to ground at the rate of approximately 100 kHz, determined by the oscillator (U34, R10, and C22) and a divide-by-2 flip-flop (U33).

  • Page 33: Linear Post Regulators (I)

    Theory of Operation Input Overload Protection a 3 volt minimum value for VCC. C19 delays this trip for at least 100 ms after power is applied to the GMM. CR5 assures that the cycle is completely repeated by discharging C19 at power down. Linear Post Regulators (I) 2-20.

  • Page 34: External Trigger And Logic Activity Input Protection

    867B,863 Service Manual • The Millivolt Sense Path is used for DC measurements in the 3V and 300 mV dc ranges, and for all Ohms, Diode Test, and Component Test measurements. This path uses two 100-kΩ resistors (R99 and R20), two metal-oxide varistors (RV2 and RV3), and internal clamp diodes (U30).

  • Page 35: Average Converter

    Theory of Operation Input Signal Conditioning resistor of Z1, which is connected to a virtual ground created by U6. C31 blocks DC voltages. CR3 clamps any over voltages to a safe level for U18. The signal is returned through Ground 3, to TP6, Ground 5, U26, L8, the low leg of R109, and then to the â...

  • Page 36: Dc Volts

    867B,863 Service Manual precharging the Slow A/D Converter through U30-67 (the analog processor). The output also goes to an RC filter (R30 and C26) and then on to the Slow A/D Converter at U30- 66 (TP17). See Table 2-6. Table 2-6. RMS Converter (U3)

  • Page 37: Ohms

    Theory of Operation Input Signal Conditioning Ohms 2-29. Ohms measurements are connected at the Ë and â inputs. A ratiometric measurement method is used: the same current is sourced through the unknown resistor and a reference resistor. The Slow A/D Converter first integrates the voltage across the unknown resistor, then deintegrates using the voltage across the reference resistor.

  • Page 38: Ma/Μa

    867B,863 Service Manual mA/µA 2-32. Milliamp and microamp measurements are connected at the = and â inputs. For the 300 mA and 30 mA ranges, input current flows through L9, F2, K1-4, K1-5, K1- 6, R42, and R109 to â. The voltage developed across R42 and R109 is sensed through R151 by U16.

  • Page 39: Waveform Processing

    Theory of Operation Waveform Processing Waveform Processing 2-34. Overview 2-35. An input signal takes AC and DC paths. With AC voltage or AC current functions, the signal is sent directly to the Fast A/D Converter for digitizing. With DC voltage or DC current functions, signals from the AC path and the DC path are recombined to form an AC + DC signal.

  • Page 40: Waveform Triggering

    867B,863 Service Manual The sum amplifier in U30 adds the reconstructed AC + DC input and the midpoint bias signal from the second divider. When the GMM is displaying waveforms, R145 and C99 form a filter that is selected by the analog switch (U14-3, U14-4, U14-5, and U14-9.) The output of this filter is...

  • Page 41: Single Trigger

    Theory of Operation Waveform Triggering • The upper comparator, controlled by DAC2, recognizes signals crossing the more positive of two thresholds. The DAC2 output passes through filter R67 and C79; the filtered DAC2 output can be observed at TP16. • The lower comparator, controlled by DAC1, recognizes signals crossing the more negative threshold.

  • Page 42: Glitch Capture

    867B,863 Service Manual Glitch Capture 2-42. A brief spike (glitch) on the input signal can be used to trigger the GMM for a single waveform acquisition. Glitch capture thresholds are fixed at ±10% of the full scale value of the waveform display. For example, in the 3V range the full scale value of the waveform display is approximately ±5V.

  • Page 43: Component Test

    Theory of Operation Component Test Test the auto diode circuit by placing a diode across the input terminals and viewing the input waveform to the Fast A/D Converter (TP19.) A rectified waveform indicates that the analog circuit is working properly. Component Test 2-48.

  • Page 44: Digital Circuitry

    867B,863 Service Manual Digital Circuitry 2-49. The H8 microprocessor (U25) provides the core of the digital circuitry. The processor fetches instructions from two 128k x8 ROMs (U11 and U19) in 16-bit words. A single 32k x8 RAM (U20) provides system Read/Write memory. A serial 16k-bit EEPROM (U23) provides nonvolatile data storage (setup information, calibration constants, and saved waveforms).

  • Page 45: Keypad Connections

    Theory of Operation RS-232 Serial Port SOFTKEY1 SOFTKEY2 SOFTKEY3 SOFTKEY4 SOFTKEY5 DISPLAY TOUCHHOLD SAVE/PRINT MIN/MAX RANGE HERTZ BACK_WAKE KEYPADINT* WAKEUP* S12A os4.eps Figure 2-3. Keypad Connections 2-25...

  • Page 46: Maintenance

    Chapter 3 Maintenance Title Page 3-1. Introduction..................... 3-3 3-2. Warranty Repairs and Shipping Information .......... 3-3 3-3. Static-Safe Handling ................3-3 3-4. Cleaning ....................3-4 3-5. Disassembly .................... 3-4 3-6. Reasssembly.................... 3-7 3-7. Replacing the 440 mA Fuse ..............3-9 3-8.

  • Page 47: Introduction

    Warranty Repairs and Shipping Information 3-2. If your GMM is still under warranty, see the warranty information at the front of this manual for instructions on returning the unit. To contact Fluke, call one of the following telephone numbers: USA and Canada: 1-800-44-FLUKE...

  • Page 48: Cleaning

    867B,863 Service Manual Note Modern electronic components are sensitive to static voltages under 100V. You can develop a charge of 2,000V by walking across a vinyl tile floor or a charge of 5,000 to 15,000V when polyester clothing moves on your body.
  • Page 49 Maintenance Disassembly 6 Places os5f.eps Figure 3-1. Disassembly...
  • Page 50 867B,863 Service Manual os6f.eps Figure 3-1. Disassembly (cont)

  • Page 51: Reasssembly

    Maintenance Reasssembly Reasssembly 3-6. Generally, reassembly reverses the disassembly procedure. Specifically, do the following: 1. Verify that the selector switch still points to “OFF”. 2. Place the case top face down on a non-marring surface. Note At all times, avoid stressing the ribbon cable. 3.
  • Page 52 867B,863 Service Manual os30f.eps Figure 3-2. Reassembly...

  • Page 53: Replacing The 440 Ma Fuse

    Maintenance Replacing the 440 mA Fuse Replacing the 440 mA Fuse 3-7. Refer to Figure 3-3 when replacing the 440 mA fuse. Fuse Spare Fuse Spare Fuse os7f.eps Figure 3-3. Replacing the 400 mA Fuse Replacing the 11A (High Energy) Fuse 3-8.

  • Page 54: Perfomance Testing And Calibration

    Perfomance Testing and Calibration Title Page 4-1. Introduction..................... 4-3 4-2. Required Test Equipment ..............4-3 4-3. Alternative Test Equipment (Fluke 5500A) ........4-3 4-4. Performance Tests................... 4-4 4-5. mV DC Test..................4-4 4-6. DC Volts Test ..................4-6 4-7. Diode Test................... 4-7 4-8.

  • Page 55: Introduction

    Alternative Test Equipment (Fluke 5500A) 4-3. The Fluke 5500A can also be used as the source where a calibrator is called for in performance testing and calibration. Some performance test points change when a 5500A is used; these changes are noted in the following tables: •...

  • Page 56: Performance Tests

    • Fluke 85 DMM Component Test Alternative Test Equipment • • Fluke 5500A Multi Product Calibrator ACV, DCV, ACA, DCA, Ohms, Capacitance Performance Tests 4-4. The following procedures ensure that the 860 Series GMM meets or exceeds all customer specifications. To successfully perform these tests, it is important that you have read the User Manual and know how to make the measurements each specific test calls for.

  • Page 57: Configuration 1 (Mv Dc)

    Perfomance Testing and Calibration Performance Tests 5700A Calibrator FREEZE DISPLAY SAVE RANGE OUTPUT SENSE MODE PRINT Ω Ω TOUCH HOLD WIDEBAND WAKE UP GUARD GROUND CURRENT mA/ A EXT TRIG os12f.eps Figure 4-1. Configuration 1 (mV DC)

  • Page 58: Dc Volts Performance Test

    Connect the GMM and 5700A in Configuration 2 (Figure 4-2). Then perform the three steps called for in Table 4-3. Before proceeding to the next test, place the 5700A in Standby. Table 4-3. DC Volts Performance Test Model 867B Model 863 Lower Upper...

  • Page 59: Diode Test

    Perfomance Testing and Calibration Performance Tests Diode Test 4-7. ä Rotate the GMM selector to Diode Test ( ). Connect the GMM and 5700A in ä Configuration 2 (Figure 4-2, selected). Then perform the three steps called for in Table 4-4. Before proceeding to the next test, place the 5700A in Standby.

  • Page 60: Ac Volts Test

    276.40 303.60 1000.0V 1000.0V, 50 Hz 5725A 984.0 1016.0 * Use 10.00V, 100 kHz with the Fluke 5500A. Use 290V, 20 kHz with the Fluke 5500A. Table 4-6. AC Volts Average Performance Test Step Range Input Input Source Lower Limit Upper Limit 300.0 mV...

  • Page 61: Configuration 6 (Ac Volts)

    Perfomance Testing and Calibration Performance Tests 5700A Calibrator FREEZE SAVE DISPLAY RANGE OUTPUT SENSE MODE PRINT Ω Ω TOUCH HOLD WIDEBAND WAKE UP GUARD GROUND CURRENT mA/ A EXT TRIG os17f.eps Figure 4-3. Configuration 6 (AC Volts)

  • Page 62: Ohms And Conductance Tests

    867B,863 Service Manual Ohms and Conductance Tests 4-9. ò Rotate the GMM selector to Ohms ( ). Connect the GMM and the 5700A in Configuration 5 (Figure 4-4). Then perform the test steps in Table 4-7 (for ohms) and Table 4-8 (for conductance).

  • Page 63: Capacitance Performance Test

    Perfomance Testing and Calibration Performance Tests 5700A Calibrator FREEZE SAVE DISPLAY RANGE OUTPUT SENSE MODE PRINT Ω Ω TOUCH HOLD WIDEBAND WAKE UP GUARD GROUND CURRENT mA/ A EXT TRIG os16f.eps Figure 4-4. Configuration 5 (Ohms) Capacitance Test 4-10. ä ).

  • Page 64: Frequency Test

    PM 5139 1.4991 1.5009 (Model 867B only.) If necessary, press x to select Next, rotate the selector to AC. Connect the 5700A to the a and â GMM inputs. If necessary, presscw to select µA-100e. Perform step 1 in Table 4-11. Press wagain to select mA-1e, then perform step 2.

  • Page 65: Configuration 7 (Pm5139)

    Perfomance Testing and Calibration Performance Tests FREEZE SAVE DISPLAY RANGE MODE PRINT TOUCH HOLD WAKE UP PM 5139 function generator 0.1 mHz 10MHz RANGE LOCAL ADDR OUTPUT RESET Ω Zo 50 mA/ A EXT TRIG os18f.eps Figure 4-5. Configuration 7 (PM5139) 4-13...

  • Page 66: Duty Cycle Performance Test

    867B,863 Service Manual Duty Cycle Test 4-12. Rotate the GMM selector to AC Volts ( ). Check that ‘Full Auto’ is selected in the display above x. Select Hz and Duty Cycle. Connect the GMM and the PM5139 in Configuration 10 (Figure 4-6) and perform the test shown in Table 4-12.

  • Page 67: Logic Performance Test

    Perfomance Testing and Calibration Performance Tests Logic Test (867B Only) 4-13. Rotate the GMM selector to LOGIC. If necessary, press t so that ‘TTL’ is selected (highlighted). Connect the GMM and the 5139 in Configuration 9 (Figure 4-7.) Then perform the test shown in Table 4-13.

  • Page 68: Amps Tests

    30.00 µA, 10 kHz 5700A 29.20 30.80 (863 na) 30.000 mA 21.000 mA, 10 kHz 5700A 20.560 21.440 3.0000A 2.9000A, 3 kHz * 5725A 2.8773 2.9228 10.000A 1.00A, 3 kHz 5725A 0.983 1.018 * Use 2.90A, 1 kHz with the Fluke 5500A. 4-16...

  • Page 69: Ac Amps Average Performance Test

    214.6 (863 na) 3.000A 2.90A, 3 kHz * 5725A 2.874 2.926 * Use 2.90A, 1 kHz with Fluke 5500A. ** When using the battery eliminator the upper limit for this test is 2.0. 5700A Calibrator FREEZE DISPLAY SAVE RANGE OUTPUT...

  • Page 70: Configuration 4 (Amps, Dc And Ac)

    867B,863 Service Manual 5700A Calibrator (Rear Panel) 5725A 5725A Calibrator (Rear Panel) FREEZE SAVE DISPLAY RANGE MODE PRINT TOUCH 5700A HOLD WAKE UP 5725A Amplifier (Front Panel) CURRENT OUTPUT mA/ A EXT TRIG os15f.eps Figure 4-9. Configuration 4 (Amps, DC and AC)

  • Page 71: Peak Hold Test

    Component Test (867B Only) 4-16. Use the Fluke 85 in the tests detailed in Table 4-18 to measure the expected limits at the GMM input jacks (V, e, G, and â). Rotate the GMM selector to Component Test and measure the appropriate signal. See Figure 4-10.

  • Page 72: Rel Test/Touch Hold Test

    867B,863 Service Manual Rel Test/Touch Hold Test 4-17. 1. Turn on the GMM to VDC, and apply 1000V dc. 2. Press t [Rel]. 3. Check for a Rel reading between the limits shown in Table 4-19. Table 4-19. Rel Performance Test...

  • Page 73: Glitch Capture Test

    Perfomance Testing and Calibration Calibration Glitch Capture Test 4-18. 1. Turn on the GMM to mV. 2. Press d, vc[View], w [Glitch Capture], t [Arm]. 3. Apply a .070V p-p Pulse 10 kHz Pulse wave. 4. Check for the Glitch Capture PASS/FAIL indications shown in Table 4-21. Table 4-21.

  • Page 74: Calibration

    867B,863 Service Manual Calibration 4-20. The calibration procedure involves 40 steps, all of which must be completed for calibration to take effect. Each step, as identified on the GMM screen, is also shown in bold in this manual. For example, “Step 1” as seen on the screen appears as Step 1 in text.

  • Page 75: Mv Dc Calibration

    Perfomance Testing and Calibration Calibration message disappears and will only appear again if the calibration procedure is started over. On the GMM, softkeys (t, u, v, w, x) select menu items shown in the boxes displayed at the bottom of the LCD. For example, press t to “Proceed” in the following set of softkeys: Abort Proceed...

  • Page 76: Dc Volts Calibration

    867B,863 Service Manual DC Volts Calibration 4-24. ã 1. Rotate the selector knob to (VDC). 2. Step 5: Apply 1000.0V dc. Allow for settling; then press t [Proceed]. 3. Step 6: Apply 290.00V dc. Allow for settling; then press t [Proceed].

  • Page 77: Ohms/Ns Calibration

    Perfomance Testing and Calibration Ohms/nS Calibration Ohms/nS Calibration 4-27. Modifying the Displayed Value 4-28. You must modify the calibration constants to compensate for the measured lead resistance. See Figure 4-13. Change the selected digit of the displayed nominal value by pressing u [Modify value], u [[], or v []].

  • Page 78: Ohms Calibration

    867B,863 Service Manual Ohms Calibration 4-29. Refer to Figure 4-14 for an example of the display during ohms calibration. 1. Verify that the 5700A is in Standby. ò (Ohms), and remove the á connection. 2. On the GMM, rotate the selector to 3.

  • Page 79: Ac Volts Calibration

    Perfomance Testing and Calibration Ohms/nS Calibration AC Volts Calibration 4-30. 1. Rotate the selector knob to v (VAC). Remove the ohms connection and connect the 5700A to the Ë and â inputs on the GMM. 2. Step 24: Apply 1000.0V, 1 kHz. Allow for settling; then press t [Proceed]. 3.

  • Page 80: Internal Constants Calibration

    867B,863 Service Manual Internal Constants Calibration 4-33. 1. Place the 5700A in Standby. 2. Rotate the selector to e (mV DC). 3. Remove the á (Amps) connection and connect the 5700A directly to the Ë and â inputs. 4. Step 40: Apply 29.00 mV dc. Allow for settling; then press t [Proceed].

  • Page 81: List Of Replaceable Parts

    Chapter 5 List of Replaceable Parts Title Page 5-1. Introduction..................... 5-3 5-2. How To Obtain Parts ................5-3 5-3. Manual Status Information..............5-3 5-4. Newer Instruments .................. 5-3 5-5. Service Centers ..................5-4 5-6. Parts......................5-4...

  • Page 82: Introduction

    Introduction Introduction 5-1. This chapter contains an illustrated list of replaceable parts for the 867B and 863 Graphical Multimeters. Parts are listed by assembly; alphabetized by reference designator. Each assembly is accompanied by an illustration showing the location of each part and its reference designator. The parts lists give the following information: •...

  • Page 83: Service Centers

    867B,863 Service Manual Service Centers 5-5. A list of service centers is located on the Fluke website (www.fluke.com) or you can reach Fluke at: USA and Canada: 1-800-44-FLUKE (1-800-443-5853) Europe: +31 402-678-200 Japan: +81-3-3434-0181 Singapore: +65- -276-6196 Anywhere in the world: +1-425-356-5500 Parts 5-6.

  • Page 84: Series Final Assembly

    List of Replaceable Parts Parts Table 5-1. 860 Series Final Assembly Reference Fluke Stock Description Tot Qty Notes Designator 863 MAIN PCA 103629 867B MAIN PCA 616570 BATTERY PACK ASSY 938170 BT2-7 BATTERY,1.5,AA,ALKALINE 376756 CONTACT,PTF 822676 FUSE, .406x1.375, 0.440A, 1000V FAST 943121 SCREW,PH,P,THD FORM,STL,2-14,.375...

  • Page 85: Series Final Assembly

    Table 5-1. 860 Series Final Assembly (cont) Reference Fluke Stock Description Tot Qty Notes Designator 863 KEYPAD MODULE 948799 867B KEYPAD MODULE 948641 86X USER MANUAL,GRP E (ENG,FR,SP,DUTCH) 944178 86X USER MANUAL,GRP G (GER,ITAL,SWE,NORW) 944181 86X USER MANUAL,GRP J (ENG,JAPAN) 944710 860 USER MANUAL 688192 1.
  • Page 86 H6 (6 Places) BT2-7 (6 Places) MP23 (2 Places) MP14 MP40 MP41 (2 Places) A1, U11, U19 H3 (3 Places) MP11 Tab Edge MP13 MP12 H12 (2 Places) MP20 MP21 Fluke 860 T&B os20f.eps Figure 5-1. 860 Series Final Assembly...

  • Page 87: A1 Main Pca

    867B,863 Service Manual Table 5-2. A1 Main PCA Reference Fluke Stock Description Tot Qty Notes Designator C1,C89 CAP,TA,1UF,+-20%,35V,3528 866970 C2,C12,C61, CAP,TA,1UF,+-20%,20V,3216 942552 C65,C88 942552 C3,C90 CAP,AL,220UF,+-20%,25V,SOLV PROOF 944686 C4,C6 CAP,TA,2.2UF,+-20%,6V,3216 930248 C5,C11,C14- CAP,CER,0.1UF,+-10%,25V,X7R,0805 942529 16,C18,C28, 942529 C29,C32,C33, 942529 C39,C44,C58, 942529...
  • Page 88 List of Replaceable Parts Parts Table 5-2. A1 Main PCA (cont) Reference Description Fluke Stock Tot Qty Notes Designator CAP,POLYPR,6800PF,+-5%,50V 706564 C68,C69 CAP,TA,68UF,+-10%,10V,7343 930250 C70,C73 CAP,TA,100UF,+-20%,10V,7343 929877 C71,C94, CAP,TA,1UF,+-20%,35V,3528 866970 C110 866970 CAP,CER,0.01UF,+-10%,50V,X7R,0805 106146 CAP,AL,10UF,+-20%,16V,NP,SOLV PROOF 697177 CAP,POLYES,2200PF,+-10%,50V 832683 CAP,CER,150PF,+-5%,50V,C0G,0805...
  • Page 89 867B,863 Service Manual Table 5-2. A1 Main PCA (cont) Reference Fluke Stock Description Tot Qty Notes Designator SHIELD,FENCE 948729 SHIELD,ANALOG,RIGHT 948737 SHIELD,ANALOG,LEFT 948682 CONN,FLAT FLEX,1MM CTR,RT ANG,16 POS 945001 HEADER,1 ROW,2MM CTR,3 PIN 944579 Q1-3, Q5, Q6, TRANSISTOR,SI,NPN,BIASED,SC-59 930052 Q11-13,Q32-...
  • Page 90 List of Replaceable Parts Parts Table 5-2. A1 Main PCA (cont) Reference Fluke Stock Description Tot Qty Notes Designator R14,R53,R56, RES,CERM,1M,+-1%,0.1W,200PPM,0805 928945 R68,R126, 928945 R139 928945 R15,R18,R27- RES,CERM,100K,+-1%,0.1W,100PPM,0805 928866 29,R57,R63, 928866 R78,R130, 928866 R13,R138, 928866 R141-143 928866 RES,CERM,0.2,+-5%,0.1W,100PPM,0805 944439 R20,R99...
  • Page 91 867B,863 Service Manual Table 5-2. A1 Main PCA (cont) Reference Fluke Stock Description Tot Qty Notes Designator RES,CERM,4.75M,+-1%,0.1W,400PPM,0805 928994 RES,CERM,100,+-1%,0.1W,100PPM,0805 928937 RES,CERM,31.6K,+-1%,0.1W,100PPM,0805 928841 RES,CERM,20K,+-1%,0.1W,100PPM,0805 928820 RES,CERM,133K,+-1%,0.1W,100PPM,0805 928874 RES,CERM,0,+.05 MAX,.125W,1206 810747 RES,CERM,10.7K,+-1%,0.1W,100PPM,0805 930037 RES,CERM,1.5M,+-1%,2W,100PPM 944280 R92,R121, RES,CERM,100K,+-1%,0.1W,100PPM,0805 928866 R134 928866 RES,CERM,16.9K,+-1%,0.1W,100PPM.0805...
  • Page 92 List of Replaceable Parts Parts Table 5-2. A1 Main PCA (cont) Reference Fluke Stock Description Tot Qty Notes Designator R171 RES,CERM,274K,+-1%,0.1W,100PPM,0805 930193 R172 RES,CERM,7.68K,+-1%,0.1W,100PPM,0805 930123 THERMISTOR,POS,1.1K,+-20%,25 C 867192 RV1-3 VARISTOR,910,+-10%,1.0MA 876193 SWITCH,ROTARY 948646 TRANSORMER,SWITCHING 948658 JUMPER,WIRE,NONINSUL,0.200CTR 816090 IC,CMOS,10 BIT DAC,CUR OUT,SOIC...
  • Page 93 RES,MF,SOIC,16 PIN,6 RES,CUSTOM 943477 1. 863 Qty = 4 (C7,C10, C21, C119) 2. 867B only. 3. 863 Qty = 10 (CR2-7, CR16, CR17, CR26) 4. 863 Qty = 6 (Q5, Q12, Q13, Q32-34) 5. 863 Qty = 5 (R14, R53, R56, R126, R139) 6.

  • Page 94: A1 Main Pca

    List of Replaceable Parts Parts FLUKE 86X-4001 (Sheet 1 of 2) os31_1f.eps Figure 5-2. A1 Main PCA 5-15...
  • Page 95 867B,863 Service Manual FLUKE 86X-4001 (Sheet 2 of 2) os31_2f.eps Figure 5-2. A1 Main PCA (cont) 5-16...

  • Page 96: Schematic Diagrams

    Chapter 6 Schematic Diagrams Title Page 6-1. A1 Main PCA Assembly.................6-3...
  • Page 97 Schematic Diagrams Top (Ckt 1) Assembly FLUKE 867-1001 (Sheet 1 of 5) FLUKE 86X-4001 Bottom (Ckt 1) Assembly Figure 6-1. A1 Main PCA...
  • Page 98 867B,863 Service Manual FLUKE 867-1001 (Sheet 2 of 5) Figure 6-1. A1 Main PCA (cont)
  • Page 99 Schematic Diagrams FLUKE 867-1001 (Sheet 3 of 5) Figure 6-1. A1 Main PCA (cont)
  • Page 100 867B,863 Service Manual FLUKE 867-1001 (Sheet 4 of 5) Figure 6-1. A1 Main PCA (cont)
  • Page 101 Schematic Diagrams FLUKE 867 -1001 (Sheet 5 of 5) Figure 6-1. A1 Main PCA (cont)
