L C D MONITOR
T M E 2 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TME24 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tatung TME24

  • Page 1 L C D MONITOR T M E 2 4...
  • Page 2: Table Of Contents

    Contents Safety warning and notice………………………………………1 Turning on/Standby…………………………………………10 Features……………………………………………………………3 Signal Source Selection………………………………………10 Mounting and Connecting………………………………………4 Menu operation description…………………………………11 Packing list………………………………………………………4 Menu setting list………………………………………………12 Mounting the Monitor set……………………………………4 USB multimedia function……………………………………13 Connecting peripheral equipment…………………………6 Troubleshooting…………………………………………………16 Panel Control Keys………………………………………………8 Technical Specifications………………………………………18 Remote Control…………………………………………………9 Basic Operations………………………………………………10 Safety warning and notice Thank you to choose the LCD Monitor with LED backlight made by our company, a valuable product with excellent quality and multiple...
  • Page 3 ● If coal gas or other flammable gases leak, do not unplug the power cord of the Monitor set or other electric appliances; instead, close the valve of the gas immediately and open the doors and windows. Warning ● Only use 100-240VAC, 60/50Hz power supply. ●...
  • Page 4: Features

    Attention ● Do not let children climb onto the ● To carry the Monitor set. Monitor set with hands, please grasp the corners ● Keep the small accessories away from children's reach to and hold the bottom; do not apply force on the panel. ●...
  • Page 5: Mounting And Connecting

    4. Much faster response time will completely eliminate shadow of picture. seeing film and playing game may be more fluent. 5. Enough colours. 6. Wider viewing angle, higher brightness, higher contrast, lower consumption. 7. Intelligent image mode and sound mode can offer you intelligent audiovisual effect. 8.
  • Page 6 3. Fasten the wall mounting stand at the position of VESA on the rear cover with bolts. 4. Spin M4 bolts into the left-right nuts on the wall mounting stand. 3-4 mm of depth from bolts washer to stand is recommended. 5.
  • Page 7: Connecting Peripheral Equipment

    ● For your safety, please select appropriate wall mount bracket or base. ● To avoid hurt, it is required to place the set on stable plane, or fix on firm wall. Monitor ● Ask qualified personnel to mount the Monitor set on the wall.
  • Page 8 G Green (Y signal cable) G Green (Y signal cable) HDMI input connection HDMI input connection B Blue (Pb/Cb signal cable) B Blue (Pb/Cb signal cable) Connect to the AV device Connect to the AV device Y Yellow (VIDEO signal cable) Y Yellow (VIDEO signal cable) with HDMI interface with HDMI interface...
  • Page 9: Panel Control Keys

    Remark: 1. The VIDEO-2 and component Y signal of the device share same input interface. AV2 and component audio share same input interface. 2. If an earphone is inserted, the speaker of the Monitor set turns off automatically. 3.The peripheral equipment and cables described in this manual should be purchased separately. Panel Control Keys 1.
  • Page 10: Remote Control

    Remote Control Remote Control Key Instruction Invalid Function Power POWER ( Switch between normal working and standby Mute MUTE ( Turn off the sound Numerical key Numerical input button Freeze picture Numerical key SMART S Switch the audio mode among Standard, Music, Movie, User SMART P Switch the image mode among Standard, Soft, User, Bright ▲▼/ ...
  • Page 11: Basic Operations

    Remark: The picture may be different from the remote control; please refer to the actual product. Installing battery Remove the battery cover, and insert two AAA (1.5V) batteries; make sure that the polarity of the battery is consistent with the marks "+/-" in the battery slot.
  • Page 12: Menu Operation Description

    Then press "▲/▼" key on remote control or "UP/DOWN" key on the control panel to choose the signal source. Press Input Source "OK" key on the remote control or "MENU" key on the control panel and Monitor will switch the current signal source to the signal source you choose.
  • Page 13: Menu Setting List

    Menu setting list Refer to the table below for the specific menu settings. Picture Mode Adjust the overall effect of images: Standard, Soft, User, Bright. Adjust the overall layering of images: increase the analog value to improve the contrast and Contrast decrease the analog value to reduce the contrast (0-100).
  • Page 14: Usb Multimedia Function

    OSD Language Set the menu language: There are many languages to select. OSD Duration Adjust duration of OSD menu: 15, 30, 45, 60. Unit: second. Adjust the menu transparency: increase the analog value to increase the transparency and OSDTransparency decrease the analog value to reduce the transparency (0-100). Blue Screen Set up whether screen turns to blue when there is no signal: On and Off.
  • Page 15 5. The USB interface of this Monitor set can supply a voltage of 5V and the maximum current is 500mA; accurate identification of the multimedia player will be affected when a storage device above 500mA is used, which is a normal phenomenon. Press "/"...
  • Page 16 File info: Press "/" key to select this function, and press "OK" key to show the picture info, including resolution, size, etc. Rotate CW: Press "/" key to select this function, and press "OK" key to rotate the picture clockwise. Rotate CCW: Press "/"...
  • Page 17: Troubleshooting

    Slow playing: Press "/" key to select this function, and press "OK" key to slow the playing. Press "PLAY" key to resume normal playing. Single step: Press "/" key to select this function, and press "OK" key to play the video step by step. Press "PLAY" key to resume normal playing.
  • Page 18 Problem Reason Solution 1. Move the object to avoid blocking the receiver 1. The receiver window is blocked. Remote control distance becomes window. 2. Battery voltage of the remote control short, out of control. 2. Replace the battery. is too low. 1.
  • Page 19: Technical Specifications

    Technical Specifications Interface specification: Interface Specification DB-15, 75Ω 0.5~0.7Vp-p H/V:TTL Level (Support mode refer to VGA Input Mode ) Video signal: 1080p, 1080i, 720p, 576p, 576i, 480p, 480i HDMI Audio: LPCM 48KHz, 44.1KHz, 32KHz, 24Bit, 20Bit, 16Bit YCbCr/Ypbpr Y: 75Ω 1Vp-p; Cb/Cr: 75Ω 0.7Vp-p Signal mode: 1080p, 1080i, 720p, 576p, 576i, 480p, 480i Audio Input/Output 20KΩ, 0.5Vp-p...
  • Page 20 Operating environment: temperature: 5℃~40℃; RH: 10%~85%; atmospheric pressure: 86kPa~104kPa Storage environment: temperature: -20℃~55℃; RH: 5%~95%; atmospheric pressure: 86kPa~104kPa VGA display mode FHD panel Mode Resolution Refresh rate (Hz) 720×400 640×480 SVGA 800×600 1024×768 1280×720 1280×960 SXGA 1280×1024 1360×768 WXGA 1600×900 WUXGA 1920×1080 Recommended mode: 1920X1080@60Hz...
