Tatung TME19WA User Manual

Tft lcd monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER' S
TFT LCD MONITOR
MANUAL
MODEL: TME19WA/TME22WA
www.tatungusa.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TME19WA and is the answer not in the manual?

Questions and answers

Related Manuals for Tatung TME19WA

Summary of Contents for Tatung TME19WA

  • Page 1 USER’ S TFT LCD MONITOR MANUAL MODEL: TME19WA/TME22WA www.tatungusa.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS FCC information ---------------------------------------------------------------------- 3 CE information ------------------------------------------------------------------------ 3 Safety Precautions ------------------------------------------------------------------- 3 Scope -------------------------------------------------------------------------------------- 5 Functional specification ------------------------------------------------------------- 5 Controls and indicators -------------------------------------------------------------- 7 OSD Menu --------------------------------------------------------------------------------9 Regulatory Agency ------------------------------------------------------------------- 21 Mechanical ----------------------------------------------------------------------------- 22 Troubleshoot --------------------------------------------------------------------------- 23...

  • Page 3: Fcc Information

    FCC INFORMATION This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 4 personnel or damage equipment. 8. Route power cords so that they cannot be walked upon or tripped over. Do not allow anything to rest on the power cord. 9. Do not install monitor in wet areas, or where it may be exposed to rain or water. Do not spill liquid of any kind on the unit.

  • Page 5: Scope

    1. Scope This specification is used to define the performance of TME19WA/TME22WA color TFT LCD monitor. This system also supports both video input and PC input. In video input mode, the system can automatically detect the NTSC signal and PAL signal. In PC mode, this system can support up to 1920 x 1080 VESA standard.
  • Page 6 2.5 Environmental Temperature Operating: 0 C to +40 Storage: -20 C to +60 Humidity Operating: 10% to 85% (non-condensing) Storage: 10% to 95% (non-condensing) 2.6 EDID This series of displays support EDID, but does not support DDC2B function. 2.7 Connectors D C B A.

  • Page 7: Controls And Indicators

    3. Controls and indicators A. “ ” Source button Press the button to show source menu. Select HDMI, S-Video,VGA and VIDEO input signal B. “ ” UP buttons Press the buttons to scrolling the cursor to desired function. C. “ ”Down button Press the buttons to scrolling the cursor to desired function.
  • Page 8 F. “ ”Menu button Press the button to show the OSD main menu. As a confirmation key during the OSD operation. G. “ ” Power button Press the button to turn ON or turn OFF the monitor H. POWER LED Indication Green - Power on LED light off - Power off Flash Green - Sleep mode (PC mode only)

  • Page 9: Osd Menu

    4. OSD Menu Hot key ： ： ： ： Quick adjust keys from front panel hot keys： ： ： ： VOLUME： Press button to select the function and press buttons to adjust the volume, the press MENU button to exit OSD menu. KEY LOCK：Push MENU key for 6 sec to enable this function.
  • Page 10 VGA & HDMI mode ： ： ： ： OSD Menu structure： ： ： ： Use the Source button to select the VGA, HDMI, CVBS, or S-VIDEO, the menu structure within each varies, refer to sections below on how to set-up each option. VGA / HDMI mode：...
  • Page 11 MAIN ADJUST： ： ： ： 1. Press Down / UP buttons to select an icon. 2. Press MENU button to select item, 3. Press buttons to adjust the value 4. Press MENU button to return VIVID MODE：Select the VIVID MODE (0~3 and USER) USER, 0: TEXT, 1: PHOTO, 2: MOVIE, 3: GAME BRIGHTNESS：Adjust the brightness value.
  • Page 12 COLOR ADJUST： ： ： ： Set the color temperature of the LCD monitor for the CIE coordinate 9300˚k or 6500˚k or USER MODE 1. Press Down / UP buttons to select an icon 2. Press MENU button to select adjust item, 3.
  • Page 13 IMAGE ADJUST (VGA ONLY)： ： ： ： 1. Press Down / UP buttons to select an icon 2. Press MENU button to select adjust item 3. Press buttons to adjust the value 4. Press MENU button to return. AUTO ADJUST：Press MENU buttons to auto adjust the H. Position, V.
  • Page 14 LANGUAGE： ： ： ： Press MENU button to enter the sub-menu 1. Press Down / UP buttons to select language 2. Press MENU button to enter SETUP MENU： ： ： ： 1. Press Down / UP buttons to select an icon 2.
  • Page 15 ON – Every one hour there will one scan line from top to bottom ( Every 1 second down one scan line) to prevent panel sticking. AUTO SHIFT scan line EXIT：Press MENU button to return to the main menu RECALL： ： ： ： Brightness, Contrast, Volume, Vivid Mode, OSD Timeout, Green Mode, Auto Shift return to default Value.
  • Page 16 MAIN ADJUST： ： ： ： 1. Press Down / UP buttons to select an icon 2. Press MENU button to select item 3. Press buttons to adjust the value. 4. Press MENU button to return. VIVID MODE：Select the VIVID MODE (0~3 and USER) USER, 0: TEXT, 1: PHOTO, 2: MOVIE, 3: GAME BRIGHTNESS：Adjust the brightness value.
  • Page 17 COLOR ADJUST： ： ： ： Set the color temperature of the LCD monitor for the CIE coordinate 9300˚k or 6500˚k or USER MODE 1. Press Down / UP buttons to select an icon 2. Press MENU button to select adjust item, 3.
  • Page 18 SCAN SETTING： ： ： ： 1. Press MENU button to select the sub-menu 2. Press buttons to select Scan Setting state. 3. Press MENU button to return. INFORMATION： ： ： ： Press MENU button to get the timing information LANGUAGE： ： ： ： Press MENU button to enter the sub-menu 1.
  • Page 19 SETUP MENU： ： ： ： 1. Press Down / UP buttons to select an icon 2. Press MENU button to select adjust item 3. Press buttons to adjust the value 4. Press MENU button to return OSD TIMEOUT：Adjust the OSD Show time (5 ~120 sec) GREEN MODE：Off or On (5 min~10 min) OFF –...
  • Page 20 EXIT：Press MENU button to return to the main menu. RECALL： ： ： ： Brightness, Contrast, Sharpness, Saturation, Tint, Volume, Vivid Mode, OSD Timeout, Green Mode, Auto Shift return to default Value.

  • Page 21: Regulatory Agency

    5. Regulatory Agency 5.1 Safety Approvals This series design shall meet the standards of the following domestic and foreign agencies: CE LVD : EN60950-1 5.2 EMI/EMS Emission Approvals This series design shall meet following EMI/EMS specifications: FCC Compliance: FCC Rules and Regulations, Part 15, subpart B, Class B. CE COMPLIANCE: EN55032 class B, EN55024, EN50130-4...

  • Page 22: Mechanical

    12.47 14.81 2.01 7.28 6.3 Dimension (Packing) - Size Unit Model TME19WA Inch 19.53 4.13 15.35 TME22WA Inch 22.24 4.57 16.54 - Weight: TATUNG COMPANY OF AMERICA, Model TME19WA 8.38 INC. TME22WA 4.48 9.88 LIMITED WARRANTY COMMERCIAL DISPLAY MONITOR PRODUCT...

  • Page 23: Troubleshoot

    Check if the volume is set to 0. Check if AUDIO is set to mute. If you are experiencing trouble with your product, try the following solutions. You may contact Tatung's service department if the problem persist at 1-800-829-2850 ext 216 or email service@tatungusa.com...
  • Page 24 Tatung Company of America, Inc. (“Tatung”) warrants to you, the original commercial purchaser of this new Tatung product (the “product”), that all parts of this product will be free from defects in materials or workmanship, as hereinafter provided, for three years from the date of original purchase.
  • Page 25 This warranty does not cover: 1. Defects, malfunction or failures resulting from causes beyond the control of Tatung or the manufacturer of the product, including, but not limited to, shipping or transit accident, abuse, misuse, operation contrary to furnished instructions, improper or...
  • Page 26 This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state. This is the only express warranty applicable to the product; Tatung neither assumes nor authorizes anyone to assume for it any other express warranty. This...
  • Page 27 TATUNG Co. of America, Inc 2850 El Presidio Street Long Beach CA 90810 Tel: 1-800-829-2850 x242 www.tatungusa.com service@tatungusa.com For Service and Repair Please call us at 1-800-829-2850 ext 242 or email service@tatungusa.com or go to www.tatungusa.com click on "Support" then select either "Online repair Request Form" or Mail or Fax Repair...
