Tatung TME19A User Manual

Tft
Hide thumbs Also See for TME19A:
Table of Contents

Advertisement

Quick Links

USER' S
MANUAL

TFT LCD MONITOR

MODEL: TME19A

Advertisement

Table of Contents
loading

Related Manuals for Tatung TME19A

Summary of Contents for Tatung TME19A

  • Page 1: Tft Lcd Monitor

    USER’ S MANUAL TFT LCD MONITOR MODEL: TME19A...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS FCC information ---------------------------------------------------------------------- 1 CE information ------------------------------------------------------------------------ 1 Safety Precautions ------------------------------------------------------------------- 1 Scope -------------------------------------------------------------------------------------- 3 Functional specification ------------------------------------------------------------- 3 Controls and indicators -------------------------------------------------------------- 5 OSD Menu -------------------------------------------------------------------------------- 6 Regulatory Agency ------------------------------------------------------------------ 18 Mechanical ----------------------------------------------------------------------------- 19...

  • Page 3: Fcc Information

    FCC INFORMATION This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 4 7. Do not place monitor on an unstable cart, stand, or shelf where it may fall and injure personnel or damage equipment. 8. Route power cords so that they cannot be walked upon or tripped over. Do not allow anything to rest on the power cord. 9.

  • Page 5: Scope

    1. Scope This specification is used to define the performance of TME19A color TFT LCD monitor. This system also supports both video input and PC input. In video input mode, the system can automatically detect the NTSC signal and PAL signal. In PC mode, this system can support up to 1920 x 1080 VESA standard.
  • Page 6 2.5 Environmental Temperature Operating: 0 C to +40 C; 32 F to 104 Storage: -20 C to +60 C; -4 F to 140 Humidity Operating: 10% to 85% (non-condensing) Storage: 10% to 95% (non-condensing) 2.6 EDID This series of displays support EDID, but does not support DDC2B function. 2.7 Connectors D C B A.

  • Page 7: Controls And Indicators

    3. Controls and indicators TME19A MONITOR A. “ ”Source button Press the button to show source menu. Select HDMI, S-Video, VGA and VIDEO input signal B. “ ”Down buttons Press the buttons to scrolling the cursor to desired function. Press the buttons to decrease the value of selected function in sub OSD menu.

  • Page 8: Osd Menu

    D. “ ”Menu button Press the button to show the OSD main menu. As a confirmation key during the OSD operation. E. “ ” Power button Press the button to turn ON or turn OFF the monitor F. POWER LED Indication Green - Power on LED light off - Power off Flash Green - Sleep mode (PC mode only)
  • Page 9 RUNNING HOURS： Remove AC power-> Push " " & " " key and Plug in AC power ->Display Running Hours information. VGA & HDMI mode ： ： ： ： OSD Menu structure： ： ： ： Use the Source button to select the VGA, HDMI, CVBS, or S-VIDEO, the menu structure within each varies, refer to sections below on how to set-up each option.
  • Page 10 HDMI MAIN MENU MAIN ADJUST： ： ： ： 1. Press Down / UP buttons to select an icon. 2. Press MENU button to select item, 3. Press Down / UP buttons to adjust the value 4. Press MENU button to return...
  • Page 11 VIVID MODE：Select the VIVID MODE (0~3 and USER) USER, 0: TEXT, 1: PHOTO, 2: MOVIE, 3: GAME BRIGHTNESS：Adjust the brightness value CONTRAST：Adjust the contrast value BACKLIGHT：Adjust the backlight value VOLUME：Adjust the volume EXIT：Press MENU button to return to the main menu COLOR ADJUST：...
  • Page 12 USER COLOR：Adjust the color temperature. RED：Adjust the RED value for user mode. GREEN：Adjust the GREEN value for user mode. BLUE：Adjust the BLUE value for user mode. EXIT：Press MENU button to return to the main menu. IMAGE ADJUST (VGA ONLY)： ： ： ： 1.
  • Page 13 EXIT：Press MENU button to return to the main menu INFORMATION： ： ： ： Press MENU button to get the VGA timing information LANGUAGE： ： ： ： Press MENU button to enter the sub-menu 1. Press Down / UP buttons to select language 2.
  • Page 14 SETUP MENU： ： ： ： 1. Press Down / UP buttons to select an icon 2. Press MENU button to select adjust item 3. Press Down / UP buttons to adjust the value 4. Press MENU button to return OSD TIMEOUT：Adjust the OSD Show time (5 ~120 sec) GREEN MODE：Off or On (5 min~10 min) OFF –...

  • Page 15: Video Mode

    AUTO SHIFT scan line EXIT：Press MENU button to return to the main menu RECALL： ： ： ： Brightness, Contrast, Volume, Vivid Mode, OSD Timeout, Green Mode, Auto Shift return to default Value. Video mode ： ： ： ： Press the Menu button to bring up the MAIN MENU Page. The following page will appear Press Down / UP buttons to select an icon, then Press MENU button to change the values in the sub menu.
  • Page 16 MAIN ADJUST： ： ： ： 1. Press Down / UP buttons to select an icon 2. Press MENU button to select item 3. Press Down / UP buttons to adjust the value 4. Press MENU button to return VIVID MODE：Select the VIVID MODE (0~3 and USER) USER, 0: TEXT, 1: PHOTO, 2: MOVIE, 3: GAME BRIGHTNESS：Adjust the brightness value.
  • Page 17 EXIT：Press MENU button to return to the main menu. COLOR ADJUST： ： ： ： Set the color temperature of the LCD. monitor for the CIE coordinate 9300˚k or 6500˚k or USER MODE. 1. Press Down / UP buttons to select an icon. 2.
  • Page 18 SCAN SETTING： ： ： ： 1. Press MENU button to select the sub-menu. 2. Press Down / UP buttons to select Scan Setting state. 3. Press MENU button to return. INFORMATION： ： ： ： Press MENU button to get the timing information. LANGUAGE：...
  • Page 19 1. Press Down / UP buttons to select language. 2. Press MENU button to enter. SETUP MENU： ： ： ： 1. Press Down / UP buttons to select an icon. 2. Press MENU button to select adjust item. 3. Press Down / UP buttons to adjust the value. 4.

  • Page 20: Regulatory Agency

    Screen will back to normal when any button is being touched. AUTO SHIFT：Adjust AUTO SHIFT ON/OFF. OFF – No Function. ON – Every one hour there will one scan line from top to bottom. (Every 1 second down one scan line) to prevent panel sticking. AUTO SHIFT scan line EXIT：Press MENU button to return to the main menu.

  • Page 21: Mechanical

    6. Mechanical 6.1 Cabinet Material: Plastic Finish: Black 6.2 Dimensions (Physical) Unit: inch - Weight: Model TME19A 7.94 6.3 Dimension (Packing ): - Size Model Unit TME19A Inch 18.27 23.03 4.76 - Weight: Model TME19A 4.44 9.79...
