Glow-worm SwiftFlow 120 Servicing Instructions page 8

PILOT WILL NOT LIGHT
START HERE
Check gas line - open all cocks,
rectify any blockages, purge out
any air. Does pilot light?
NO
Apply match to pilot burner instead
of pressing piezo unit button.
Does pilot light?
NO
Undo tubing nut at pilot burner.
Press multifunctional control knob.
Does gas flow freely?
NO
Rectify blockage in pilot injector,
or renew pilot injector.
NO
Undo tubing nut at pilot outlet of
mulitfunctional control.
Press multifunctional control knob.
Does gas flow freely?
NO
Change blocked pilot tube.
NO
Change multifunctional control.
221045A
Supplied By www.heating spares.co Tel. 0161 620 6677
3 F a u l t F i n d i n g
YES
YES
YES
YES
8
Does pilot stay alight when
multi-functional control knob
is released?
NO YES
PILOT SATISFACTORY
Does pilot flame
envelope thermocouple?
NO YES
Check aeration. If necessary -
clean pilot, rectify blockage in pilot
injector, or replace.
Check thermocouple circuit using
thermocouple and boiler overheat
cut-off fault finding.
On pressing piezo unit button is
there a spark across electrode gap?
NO
YES
Remove electrode from pilot bracket.
Hold tip close to pilot burner and
operate piezo unit.
Is there a spark across gap?
NO YES
Pull ignition lead off piezo unit.
Using blade of an insulated screw-
driver, touch unit chassis and leave
approx. 4mm gap from connection
tag on piezo unit. Operate piezo.
Is there a spark across gap?
NO YES
Change
Change electrode
piezo unit.
assembly.
Check electrode gap. Reposition,
or replace electrode as necessary.
Diagram 3.3
