  • Page 1 The energy you need System Manual HYBRID COMPACT HYBRID UNIVERSAL STANDALONE UNIVERSAL BOILER...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Introduction ..........................4 Summary of diagrams and available options ......................4 Hybrid compact ..........................6 Hybrid Compact description ..........................6 2.1.1 Operating principle of the system ........................6 2.1.2 Summary of installation diagrams ........................6 2.1.3 Options compatible with the system .......................7 Example of installation with diagram 9 : eBUS Heat pump, eBUS boiler, one heating zone ........8...
  • Page 3 TABLE OF CONTENTS Options ............................. 56 Multizones ................................56 7.1.1 Option description ............................56 7.1.2 Example installations ...........................57 Day/night tariff ..............................59 Commissioning an installation with just a boiler (diagram 8) ............60 Installation assistant ............................60 Installer menu ..............................60 Thermostat / sensor ............................60 Self check .................................60 Settings ................................60 8.5.1...

  • Page 4: Introduction

    Family Diagram Boiler pump Hybrid eBUS eBUS Compact eBUS eBUS On/Off eBUS 24 V Hybrid On/Off eBUS Universal 230 V On/Off eBUS On/Off On/Off 230 V eBUS Standalone On/Off Boiler only eBUS 0020153648_01 - 02/13 - Glow-worm - 4 -...
  • Page 5 + 1 GW (UFH 2 zones) Heat Family Diagram Boiler pump eBUS eBUS eBUS On/Off eBUS 24 V Genia On/Off eBUS Universel 230 V On/Off On/Off eBUS On/Off On/Off 230 V : Options available 0020153648_01 - 02/13 - Glow-worm - 5 -...

  • Page 6: Hybrid Compact

    The switchover point must be determined in accordance with the respective energy costs (see the "Activation of control unit > Settings> Energy management" chapter). Hybrid Compact description The HYBRID COMPACT system consists of the following 2.1.2 Summary of installation diagrams components :...

  • Page 7: Options Compatible With The System

    3 zone low temperature or high temperature heating (Z30) Monozone OEM UFH (UFH 1 zone) OEM UFH + 1 GW (UFH 2 zones) Swimming pool Management of electricity tariff s (day/night) by programme : Options available 0020153648_01 - 02/13 - Glow-worm - 7 -...

  • Page 8: Example Of Installation With Diagram 9 : Ebus Heat Pump, Ebus Boiler, One Heating Zone

    SYSTEM MANUAL Example of installation with diagram 9 : eBUS Heat pump, eBUS boiler, one heating zone EBUS 230V 230V 0020153648_01 - 02/13 - Glow-worm - 8 -...
  • Page 9 (heating outlet temperature < 50°C) or low temperature radiators (heating outlet temperature < 70°C). Control unit settings Description of main settings Setting None Management by: NTC sensor (1NTC) Thermostat (1Therm) 0020153648_01 - 02/13 - Glow-worm - 9 -...

  • Page 10: Hybrid Universal

    230V signal - A heat pump, - An hydraulic module, - A boiler, - A Systempro control unit, - A wireless outdoor sensor, - A wireless or wired room thermostat. 0020153648_01 - 02/13 - Glow-worm - 10 -...

  • Page 11: Options Compatible With The System

    Systempro control unit. The domestic hot water tank will be connected to, heated by and managed by the boiler (see the boiler installation manual). 0020153648_01 - 02/13 - Glow-worm - 11 -...

  • Page 12: Example Of Installation With Diagram 10 : Ebus Heat Pump, Ebus Boiler, One Heating Zone

    SYSTEM MANUAL Example of installation with diagram 10 : eBUS heat pump, eBus boiler, one heating zone EBUS 230V 230V 0020153648_01 - 02/13 - Glow-worm - 12 -...
  • Page 13 (heating outlet temperature < 50°C) or low temperature radiators (heating outlet temperature < 70°C). Control unit settings Description of main settings Setting None Management by: NTC sensor (1NTC) Thermostat (1Therm) 0020153648_01 - 02/13 - Glow-worm - 13 -...

  • Page 14: Example Of Installation With Diagram 3 : Ebus Heat Pump, Heat Pump Controlled By On/Off Contact 24V, One Heating Zone

    SYSTEM MANUAL Example of installation with diagram 3 : eBUS Heat pump, Heat pump controlled by On/Off contact 24V, one heating zone EBUS 230V 230V RT 24V 0020153648_01 - 02/13 - Glow-worm - 14 -...
  • Page 15 (on the boiler or the circulation pump). - The installation can be performed with a low-temperature heated fl oor (heating outlet temperature < 50°C) or low Put the installation into service. temperature radiators (heating outlet temperature < 70°C). 0020153648_01 - 02/13 - Glow-worm - 15 -...

  • Page 16: Example Of Installation With Diagram 13 : Ebus Heat Pump, Boiler Controlled By 230V Signal, One Heating Zone

    SYSTEM MANUAL Example of installation with diagram 13 : eBUS Heat pump, Boiler controlled by 230V signal, one heating zone EBUS 230V 230V Input 230V 0020153648_01 - 02/13 - Glow-worm - 16 -...
  • Page 17 In the case of an On/Off boiler controlled by 230V contact. 230V relay 230VAC Connection to control unit REL1 connector Connection to the 230V thermostat connection of a boiler controlled by contact 0020153648_01 - 02/13 - Glow-worm - 17 -...

  • Page 18: Example Of Installation With Diagram 11: Heat Pump Controlled By On/Off Contact, Ebus Boiler, One Heating Zone

    SYSTEM MANUAL Example of installation with diagram 11: Heat pump controlled by On/Off contact, eBus boiler, one heating zone EBUS 230V 230V 0020153648_01 - 02/13 - Glow-worm - 18 -...
  • Page 19 (heating outlet temperature < 50°C) or low temperature radiators (heating outlet temperature < 70°C). Control unit settings Description of main settings Setting None Management by: NTC sensor (1NTC) Thermostat (1Therm) 0020153648_01 - 02/13 - Glow-worm - 19 -...

  • Page 20: Example Of Installation With Diagram 6 : Heat Pump Controlled By On/Off Contact, Boiler Controlled By On/Off Contact 230V, One Heating Zone

    SYSTEM MANUAL Example of installation with diagram 6 : Heat pump controlled by On/Off contact, boiler controlled by On/ Off contact 230V, one heating zone EBUS 230V 230V Input 230V 0020153648_01 - 02/13 - Glow-worm - 20 -...
  • Page 21 ECO heating mode (*) 1 - 20°C connector Connection to the 24V or 230V (*) Refer to the correspondence table in the “Settings > Heating” thermostat connection of a boiler section. controlled by contact 0020153648_01 - 02/13 - Glow-worm - 21 -...

  • Page 22: Standalone

    The Standalone system consists of the following components: - Operation with 1 temperature sensor on the tank allows 1 - A Glow-worm Envirosorb heat pump, ignition maximum every 8 hours if the hot water programme is not activated.

  • Page 23: Options Compatible With The System

    Domestic hot water cylinder Electric back-up for domestic hot water tank Swimming pool : Options available ∙ Refer to the “options” section to perform the various hydraulic and electrical connections necessary for the selected option. 0020153648_01 - 02/13 - Glow-worm - 23 -...

  • Page 24: Example Of Installation With Diagram 4 : Ebus Heat Pump, One Heating Zone

    SYSTEM MANUAL Example of installation with diagram 4 : eBUS Heat pump, one heating zone 230V 230V 230V EBUS 230V 230V 230V 0020153648_01 - 02/13 - Glow-worm - 24 -...
  • Page 25 With the valve powered, the heating circuit will be closed and the circuit to the domestic hot water tank will be open. Control unit settings Description of main settings Setting 1 sensor T° Hot water tank option 2 sensors T° 0020153648_01 - 02/13 - Glow-worm - 25 -...

  • Page 26: Example Of Installation With Diagram 7 : Heat Pump Controlled By On/Off Contact, One Heating Zone

    SYSTEM MANUAL Example of installation with diagram 7 : Heat pump controlled by On/Off contact, one heating zone 230V 230V 230V EBUS 230V 230V 230V 0020153648_01 - 02/13 - Glow-worm - 26 -...
  • Page 27 (on the boiler or the circulation pump). - The installation can be performed with a low-temperature underfl oor heating (heating outlet temperature < 50°C) or low temperature radiators (heating outlet temperature < 70°C). 0020153648_01 - 02/13 - Glow-worm - 27 -...

  • Page 28: Boiler Only

    Domestic hot water cylinder Boiler back-up for domestic hot water tank : Options available ∙ Refer to the “options” section to perform the various hydraulic and electrical connections necessary for the selected option. 0020153648_01 - 02/13 - Glow-worm - 28 -...

  • Page 29: Example Of Installation With Diagram 8 : Ebus Boiler, One Heating Zone

    Boiler circuit return 2 port valve need with option "DHW cylinder" Heating circuit fl ow Heating circuit return Heating circuit 2 port valve (necessary for monozone heating) Overheating safety (not supplied) Not used 0020153648_01 - 02/13 - Glow-worm - 29 -...
  • Page 30 (on the boiler or the circulation pump). - The installation can be performed with a low-temperature heated fl oor (heating outlet temperature < 50°C) or low temperature radiators (heating outlet temperature < 70°C). 0020153648_01 - 02/13 - Glow-worm - 30 -...

  • Page 31: Universal

    This depends on the outside temperature measured by the wireless outside sensor continually corrected by the real temperature measured by the wired or wireless room thermostat. 0020153648_01 - 02/13 - Glow-worm - 31 -...

  • Page 32: Options Compatible With The System

    Back-up boiler for domestic hot water tank (only with e-BUS boiler) Swimming pool Management of electricity tariff s (day/night) by electrical connection Management of electricity tariff s (day/night) by programme : Options available 0020153648_01 - 02/13 - Glow-worm - 32 -...
  • Page 33 Swimming pool Management of electricity tariff s (day/night) by programme : Options available ∙ Refer to the “options” section to perform the various hydraulic and electrical connections necessary for the selected option. 0020153648_01 - 02/13 - Glow-worm - 33 -...

  • Page 34: Example Of Installation With Diagram 14 : Ebus Heat Pump

    SYSTEM MANUAL Example of installation with diagram 14 : eBUS Heat pump 6.2.1 eBUS Heat pump, directly to the heating installation, without back-up EBUS 230V 230V 0020153648_01 - 02/13 - Glow-worm - 34 -...
  • Page 35 - The installation can be performed with a low-temperature Systempro control unit heated fl oor (heating outlet temperature < 50°C) or low Electrical power and protection of the back-up heater temperature radiators (heating outlet temperature < 70°C). 0020153648_01 - 02/13 - Glow-worm - 35 -...

  • Page 36: Ebus Heat Pump, Directly To The Heating Installation With Electric Back-Up (2, 4, 6 Kw)

    SYSTEM MANUAL 6.2.2 eBUS Heat pump, directly to the heating installation with electric back-up (2, 4, 6 kW) EBUS 230V 230V 230V 230V 230V 230V 0020153648_01 - 02/13 - Glow-worm - 36 -...
  • Page 37 - A safety valve and an expansion vessel are essential in the heating circuit. - The installation can be performed with a low-temperature heated fl oor (heating outlet temperature < 50°C) or low temperature radiators (heating outlet temperature < 70°C). 0020153648_01 - 02/13 - Glow-worm - 37 -...

  • Page 38: Ebus Heat Pump, With Decoupling On The Heating Installation, Without Back-Up

    SYSTEM MANUAL 6.2.3 eBUS Heat pump, with decoupling on the heating installation, without back-up EBUS 230V 230V OUT3 OUT2 OUT1 NTC1 NTC2 0020153648_01 - 02/13 - Glow-worm - 38 -...
  • Page 39 - A safety valve and an expansion vessel are essential in the heating circuit. - The installation can be performed with a low-temperature heated fl oor (heating outlet temperature < 50°C) or low temperature radiators (heating outlet temperature < 70°C). 0020153648_01 - 02/13 - Glow-worm - 39 -...

  • Page 40: Ebus Heat Pump, With Decoupling From The Heating Installation, With Electric Back-Up (2, 4, 6 Kw)

    SYSTEM MANUAL 6.2.4 eBUS Heat pump, with decoupling from the heating installation, with electric back-up (2, 4, 6 kW) EBUS 230V 230V 230V OUT3 OUT2 OUT1 NTC1 NTC2 230V 0020153648_01 - 02/13 - Glow-worm - 40 -...
  • Page 41 - A safety valve and an expansion vessel are essential in the heating circuit. - The installation can be performed with a low-temperature underfl oor heating (heating outlet temperature < 50°C) or low temperature radiators (heating outlet temperature < 70°C). 0020153648_01 - 02/13 - Glow-worm - 41 -...

  • Page 42: Ebus Heat Pump, With Decoupling From The Heating Installation, With E-Bus Boiler Back-Up

    SYSTEM MANUAL 6.2.5 eBUS Heat pump, with decoupling from the heating installation, with e-BUS boiler back-up EBUS 230V 230V 17 18 OUT3 OUT2 OUT1 NTC1 NTC2 0020153648_01 - 02/13 - Glow-worm - 42 -...
  • Page 43 - A safety valve and an expansion vessel are essential in the heating circuit. - The installation can be performed with a low-temperature heated fl oor (heating outlet temperature < 50°C) or low temperature radiators (heating outlet temperature < 70°C). 0020153648_01 - 02/13 - Glow-worm - 43 -...

  • Page 44: Ebus Heat Pump, With Decoupling From The Heating Installation, With Boiler Back-Up Controlled By On/Off Contact

    Heat pump, with decoupling from the heating installation, with boiler back-up controlled by On/Off contact on/off 230V on/off 24V EBUS 230V 230V Input 230V OUT3 OUT2 OUT1 NTC1 NTC2 RT 24V 0020153648_01 - 02/13 - Glow-worm - 44 -...
  • Page 45 - A safety valve and an expansion vessel are essential in the heating circuit. - The installation can be performed with a low-temperature heated fl oor (heating outlet temperature < 50°C) or low temperature radiators (heating outlet temperature < 70°C). 0020153648_01 - 02/13 - Glow-worm - 45 -...

  • Page 46: Examples Of Installations With Diagram 15: Heat Pump Controlled By On/Off Contact

    SYSTEM MANUAL Examples of installations with diagram 15: Heat pump controlled by On/Off contact 6.3.1 On/Off heat pump, directly connected to the heating installation, without back-up 230V 230V 0020153648_01 - 02/13 - Glow-worm - 46 -...
  • Page 47 - The installation can be performed with a low-temperature Systempro control unit underfl oor heating (heating outlet temperature < 50°C) or low Electrical power and protection of the back-up heater temperature radiators (heating outlet temperature < 70°C). 0020153648_01 - 02/13 - Glow-worm - 47 -...

  • Page 48: On/Off Heat Pump, With Decoupling On The Heating Installation, Without Back-Up

    SYSTEM MANUAL 6.3.2 On/Off heat pump, with decoupling on the heating installation, without back-up EBUS 230V OUT3 OUT2 OUT1 NTC1 NTC2 230V 0020153648_01 - 02/13 - Glow-worm - 48 -...
  • Page 49 - An expansion vessel are essential in the heating circuit. - The installation can be performed with a low-temperature heated fl oor (heating outlet temperature < 50°C) or low temperature radiators (heating outlet temperature < 70°C). 0020153648_01 - 02/13 - Glow-worm - 49 -...

  • Page 50: On/Off Heat Pump, With Decoupling From The Heating Installation, With Electric Back-Up (2, 4, 6 Kw)

    SYSTEM MANUAL 6.3.3 On/Off heat pump, with decoupling from the heating installation, with electric back-up (2, 4, 6 kW) EBUS 230V 230V 230V OUT3 OUT2 OUT1 NTC1 NTC2 230V 0020153648_01 - 02/13 - Glow-worm - 50 -...
  • Page 51 - An expansion vessel are essential in the heating circuit. - The installation can be performed with a low-temperature heated fl oor (heating outlet temperature < 50°C) or low temperature radiators (heating outlet temperature < 70°C). 0020153648_01 - 02/13 - Glow-worm - 51 -...

  • Page 52: On/Off Heat Pump, With Decoupling From The Heating Installation, With E-Bus Boiler Back-Up

    SYSTEM MANUAL 6.3.4 On/Off heat pump, with decoupling from the heating installation, with e-BUS boiler back-up EBUS 230V 17 18 230V OUT3 OUT2 OUT1 NTC1 NTC2 0020153648_01 - 02/13 - Glow-worm - 52 -...
  • Page 53 - An expansion vessel are essential in the heating circuit. - The installation can be performed with a low-temperature underfl oor heating (heating outlet temperature < 50°C) or low temperature radiators (heating outlet temperature < 70°C). 0020153648_01 - 02/13 - Glow-worm - 53 -...

  • Page 54: On/Off Heat Pump, With Decoupling From The Heating Installation, With Boiler Back-Up Controlled By On/Off Contact

    SYSTEM MANUAL 6.3.5 On/Off heat pump, with decoupling from the heating installation, with boiler back-up controlled by On/Off contact on/off 230V EBUS 230V Input 230V 230V OUT3 OUT2 OUT1 NTC1 NTC2 0020153648_01 - 02/13 - Glow-worm - 54 -...
  • Page 55 - An expansion vessel are essential in the heating circuit. - The installation can be performed with a low-temperature underfl oor heating (heating outlet temperature < 50°C) or low temperature radiators (heating outlet temperature < 70°C). 0020153648_01 - 02/13 - Glow-worm - 55 -...

  • Page 56: Options

    Three zones (Z30) The options are made up of the following elements: - Three 2-way valves, - A Systempro control unit, - Three wired or wireless room thermostat, - A wireless outdoor sensor. 0020153648_01 - 02/13 - Glow-worm - 56 -...

  • Page 57: Example Installations

    Climapro1 programmable wireless room thermostat "zone 2" 2 port valve "heating zone 3" Climapro1 programmable wireless room thermostat "zone 3" Heating circuit zone 3 10 Systempro control unit Heating circuit fl ow Heating circuit return 0020153648_01 - 02/13 - Glow-worm - 57 -...
  • Page 58 11 Zone 1 high temperature 2-way valve 12 High temperature zone 1 heating circuit 13 High temperature zone 1 room thermostat (*) OEM underfl oor heating kit (not supplied) Heating circuit fl ow Heating circuit return 0020153648_01 - 02/13 - Glow-worm - 58 -...

  • Page 59: Day/Night Tariff

    2 heating zones low or high temperature (Z20) 3 heating zones low or high temperaturee (Z30) Type of kit multi-zone OEM UFH (UFH 1 zone) OEM UFH + 1 GW (UFH 2 zones) 0020153648_01 - 02/13 - Glow-worm - 59 -...

  • Page 60: Commissioning An Installation With Just A Boiler (Diagram 8)

    The optimum value is obtained approximately 24 hours after the system is started. It is recommended to activate this function. 0020153648_01 - 02/13 - Glow-worm - 60 -...

  • Page 61: Domestic Hot Water

    ∙ Refer to the boiler instructions for fi lling the boiler. Venting the heating circuit The control box bleeding function opens the valves of each zone to prepare the system and start the bleeding routine for 15 minute. 0020153648_01 - 02/13 - Glow-worm - 61 -...

  • Page 62: Commissioning An Installation Containing A Heat Pump

    • Do not modify the cables when connected to the mains. If the connection is not correct, the message "Not OK" appears opposite the component. In this case, check the connections (wired and wireless). 0020153648_01 - 02/13 - Glow-worm - 62 -...

  • Page 63: Settings

    Heating water law curves for the low 0.1 - 0.6 Z20 or Z30 0.5 (factory setting) Parameter 112 temperature zone Heating water law curves for the high 0.6 - 4.0 temperature zone 0020153648_01 - 02/13 - Glow-worm - 63 -...

  • Page 64: Cooling

    - "-3°C" for the 5kW heat pump as it cannot operate below -3°C, ∙ Manipulate the bleed valves until the installation is completely bled. "-20°C" for the other heat pumps. ∙ Top up the fi ll and repeat the operation if necessary. 0020153648_01 - 02/13 - Glow-worm - 64 -...
  • Page 65 - the price exc VAT per ton of propane gas. - the price exc VAT per litre of heating oil. ∙ Enter the information and the values in the tables below. 0020153648_01 - 02/13 - Glow-worm - 65 -...

  • Page 66: 10 Appendix

    57,60 to 60,00 60,10 to 62,50 62,60 to 65,00 65,10 to 67,50 67,60 to 70,00 70,10 to 72,50 72,60 to 75,00 75,10 to 77,50 77,60 to 80,00 80,10 to 80,25 82,60 to 85,00 0020153648_01 - 02/13 - Glow-worm - 66 -...

  • Page 67: Summary Table Of Control Box Connections

    0,0751 to 0,0775 0,0776 to 0,0800 10.2 Summary table of control box connections Connecteurs 230V Connecteurs 24V 230V~ REL1 REL2 REL3 REL4 REL5 OUT1 OUT2 OUT3 NTC1 NTC2 NTC3 NTC4 EBUS EBUS EBUS 0020153648_01 - 02/13 - Glow-worm - 67 -...
  • Page 68 SYSTEM MANUAL 0020153648_01 - 02/13 - Glow-worm - 68 -...
  • Page 69 SYSTEM MANUAL 0020153648_01 - 02/13 - Glow-worm - 69 -...
  • Page 70 SYSTEM MANUAL 0020153648_01 - 02/13 - Glow-worm - 70 -...
  • Page 72 Supplier / Manufacturer GLOW-WORM Nottingham Road, Because of our constant endeavour for Belper, Derbyshire. improvement, details may vary slightly DE56 1JT from those shown in these instructions. The energy you need www.glow-worm.co.uk...
