5.1 Part Identification

The key number in diagram 5.1 and the first column of
the list will help identify the spare part.
5.2 Ordering
When ordering any spare part, please quote the part
number and the description from the list together with
the model name and serial number information from the
data label. The data label is positioned on the inner case
cover, see diagram 1.3.
Key No Part No
1 800512
2 205724
3 203433
4 202627
5 203518
6 202435
7 432869
8 432868
9 900501
9 900501
10 800134
11 202217
12 800513
13 800510
14 202068
15A 800504
15B 800504
16 800136
17A 202226
17B 202240
18 800155
19 202218
20 202221
21 208214
22 800153
23 800149
24 203373
26 800515
221045A
Supplied By www.heating spares.co Tel. 0161 620 6677
5 S p a r e P a r t s
Description
Fan assembly
Main injector assembly
Pilot burner
Spark electrode with lead
Pilot injector
Thermocouple
Boiler over heat cut off assy
DHW high limit control assy
Piezo unit)
}
alternatives
Piezo unit)
Pressure gauge assembly
Control board inc fuses
Transformer
Multifunctional control
Central heating selector switch
Thermistor assembly-Domestic
Thermistor assembly-Heating
DHW switch assembly
Fuse 1
Fuse 2
Water pressure switch assembly
User PCB
Air pressure switch assy
Water inlet filter
Automatic air vent assembly
Safety valve assembly
Gas/air ratio unit
Fan driver board
30
GC No
278 129
278 130
379 485
278 131
381 656
378 204
376 988
313 024
382 585
384 146
313 294
278 132
278 133
278 134
382 813
278 135
278 135
313 277
278 136
*** ***
278 142
278 141
278 137
281 359
313 285
397 677
278 138
278 140
