On-Screen Display Guide
C336ZC1 HD PTZ Camera

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C336ZC1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FLIR C336ZC1

Summary of Contents for FLIR C336ZC1

  • Page 1 On-Screen Display Guide C336ZC1 HD PTZ Camera...
  • Page 3 On-Screen Display Guide C336ZC1 HD PTZ Camera #LX400048; r. 1.0/23171/23171; en-US...
  • Page 4 Thank you for purchasing this product. FLIR is committed to providing our customers with a high quality, reliable security solution. This manual refers to the following models: C336ZC1 For the latest online manual, downloads and product updates, and to learn about our complete line of accessory products, please visit our website at: www.flirsecurity.com/pro...
  • Page 5 Using the On-Screen Display (OSD) Menu for C336ZC1 You can configure the camera’s advanced settings on a FLIR MPX DVRs using the OSD menu. Use the OSD menu to correct imperfections in the camera image as well as config- ure automated PTZ functions like preset locations, patterns, and tours.
  • Page 6 Using the On-Screen Display (OSD) Menu for C336ZC1 SYSTEM INFORMATION ADDR Displays the camera address. Displays the camera baud rate. PARITY Displays the communication parity. PTZ VER Displays the PTZ firmware version. CAM VER Displays the camera firmware version. ADDR TYPE ADDR INFORMATION •...
  • Page 7 Using the On-Screen Display (OSD) Menu for C336ZC1 1.1.3 Restore Factory Defaults Restore the camera module to its out-of-the-box state. This will reset all menu items ex- cept those in the CAMERA SETTING menu back to their default values. CAUTION This step cannot be undone.
  • Page 8 Using the On-Screen Display (OSD) Menu for C336ZC1 To restart the camera module: 1. Use the on-screen arrow keys to navigate to SYSTEM SETTING and click Enter. 2. Select RESTART and click Enter. 1.2 Display Settings Use the display settings menu to choose what information appears over the camera image.
  • Page 9 Using the On-Screen Display (OSD) Menu for C336ZC1 WB SETTING WB MODE • AUTO • • INDOOR • OUTDOOR • OUTDOOR AUTO • NA LAMP • NA LAMP AUTO • MANUAL 0–100 R GAIN B GAIN 0–100 EXPOSURE AE MODE •...
  • Page 10 Using the On-Screen Display (OSD) Menu for C336ZC1 FOCUS FOCUS MODE • AUTO SETTING • MANUAL • SEMIAUTO FOCUS LIMIT • 10CM • • • • • AUTO • SENSITIVITY • • HIGH • CORRECTION • • AUTO 1–100 IMAGE ADJUST 1–100...
  • Page 11 Using the On-Screen Display (OSD) Menu for C336ZC1 To configure white balance settings: 1. Use the on-screen arrow keys to navigate to CAMERA SETTING and click Enter. 2. Select WB SETTING and click Enter. 3. Under WB MODE, click the left / right arrow keys to select one of the following options based on the camera’s environment:...
  • Page 12 Using the On-Screen Display (OSD) Menu for C336ZC1 To configure the camera’s exposure mode: 1. Use the on-screen arrow keys to navigate to CAMERA SETTING and click Enter. 2. Select EXPOSURE SETTING and click Enter. 3. Under AE MODE, click the left / right arrow keys to select one of the following exposure modes: •...
  • Page 13 Using the On-Screen Display (OSD) Menu for C336ZC1 To set exposure compensation: 1. Use the on-screen arrow keys to navigate to CAMERA SETTING and click Enter. 2. Select EXPOSURE SETTING and click Enter. 3. Under EXPOSURE COMP, click the left / right arrow keys to set the exposure compen- sation value from 1 (darkest) to 15 (brightest).
  • Page 14 Using the On-Screen Display (OSD) Menu for C336ZC1 3. Under BLC, click the left / right arrow keys to select ON. 1.3.5 Slow Shutter Slow shutter is used to allow extra light into the camera thereby providing brighter images in low light conditions.
  • Page 15 Using the On-Screen Display (OSD) Menu for C336ZC1 To configure AGC: 1. Use the on-screen arrow keys to navigate to CAMERA SETTING and click Enter. 2. Select EXPOSURE SETTING and click Enter. 3. Select NEXT PAGE and click Enter. 4. Under AGC GAIN LIMIT, click the left / right arrow keys to set the high limit for the cam- era’s automatic gain control (1–3).
  • Page 16 Using the On-Screen Display (OSD) Menu for C336ZC1 4. Under NR, click the left / right arrow keys to set the 2D noise reduction level (1–16). It is recommended to keep the 2D noise reduction at the default level of 8 unless the camera image is noisey in low-light conditions.
  • Page 17 Using the On-Screen Display (OSD) Menu for C336ZC1 4. Under HIGH LIGHT REDUCE, click the left / right arrow keys to select a sensitivity level: • HIGH: The brightness of highlighted areas is greatly reduced. • LOW: The brightness of highlighted areas is slightly reduced.
  • Page 18 Using the On-Screen Display (OSD) Menu for C336ZC1 To enable digital WDR: 1. Use the on-screen arrow keys to navigate to CAMERA SETTING and click Enter. 2. Select EXPOSURE SETTING and click Enter. 3. Select NEXT PAGE and click Enter. Repeat on the next page to reach the last page of the EXPOSURE SETTING menu.
  • Page 19 Using the On-Screen Display (OSD) Menu for C336ZC1 4. Under TYPE, click the left / right arrow keys to select one of the following options: • ELECTRON: Day / night switch-over is determined by camera software. This is rec- ommended if the camera switches its viewing mode at around the same time every day (for example, sunset or sunrise in an outdoor location).
  • Page 20 Using the On-Screen Display (OSD) Menu for C336ZC1 To adjust the camera image: 1. Use the on-screen arrow keys to navigate to CAMERA SETTING and click Enter. 2. Select IMAGE ADJUST and click Enter. 3. Under HUE, click the left / right arrow keys to select a hue value for the camera image (1–100).
  • Page 21 Using the On-Screen Display (OSD) Menu for C336ZC1 2. Under ZOOM SPEED, click the left / right arrow keys to select a zoom speed value from 1 (slowest) to 8 (fastest). 1.3.15 Aperture Settings Set the aperture and aperture restrain values for the camera to configure the sharpness of the camera image.
  • Page 22 Using the On-Screen Display (OSD) Menu for C336ZC1 3. Under DIGITAL ZOOM, click the left / right arrow keys to turn on digital zoom. 1.3.17 Picture Flip You can manually rotate the camera image 180° using the PICTURE FLIP feature.
  • Page 23 Using the On-Screen Display (OSD) Menu for C336ZC1 To set picture mode: 1. Use the on-screen arrow keys to navigate to CAMERA SETTING and click Enter. 2. Select NEXT PAGE and click Enter. 3. Under PICTURE MODE, click the left / right arrow keys to select the resolution and frame rate for the live video stream.
  • Page 24 Using the On-Screen Display (OSD) Menu for C336ZC1 1.3.21 Camera Restart Restarts the camera module. This means that the camera’s PTZ module will restart with- out the whole camera powering off. NOTE Restarting the camera module does not affect OSD menu settings.

  • Page 25: Table Of Contents

    Using the On-Screen Display (OSD) Menu for C336ZC1 TOUR TOUR NO 1–8 SETTING Configure a custom tour using 2 or more of your preset locations. DELETE Deletes currently selected tour. CALL Begins the selected tour. STOP Stops the tour. 1–5...

  • Page 26: Tour No

    Using the On-Screen Display (OSD) Menu for C336ZC1 NEXT PRIVACY PRIVACY 1–24 PAGE MASKING ACTIVATE ON / OFF SETTING RESIZE Use on-screen arrows to re- size privacy mask. SAVE Save privacy mask. 1–3 SPEED SET ZERO Sets the camera’s current position as the horizontal benchmark position.
  • Page 27 Using the On-Screen Display (OSD) Menu for C336ZC1 To add presets: 1. Before entering the OSD menu, move the PTZ camera to the location where you would like to add a preset location, then launch the OSD menu. 2. Use the on-screen arrow keys to navigate to FUNCTION SETTING and click Enter.

  • Page 28: Tour

    Using the On-Screen Display (OSD) Menu for C336ZC1 To add auto-scan cycles: 1. Before entering the OSD menu, move the PTZ camera to the starting position for the auto-scan cycle you want to setup, then launch the OSD menu. 2. Use the on-screen arrow keys to navigate to FUNCTION SETTING and click Enter.

  • Page 29: Pattern

    Using the On-Screen Display (OSD) Menu for C336ZC1 5. Configure the following: • Select 01 under the NO column and click Enter to configure the first preset location in the tour. • Use the left / right arrows to select PRESET. Use the up / down arrows to choose the number of the first preset location in the tour.
  • Page 30 Using the On-Screen Display (OSD) Menu for C336ZC1 To add a pattern: 1. Launch the OSD menu. Use the on-screen arrow keys to navigate to FUNCTION SET- TING and click Enter. 2. Select PATTERN and click Enter. 3. Under PATTERN NO, click the left / right arrow keys to select a number for the pattern.
  • Page 31 Using the On-Screen Display (OSD) Menu for C336ZC1 To create a privacy mask: 1. Launch the OSD menu. Use the on-screen arrow keys to navigate to FUNCTION SET- TING and click Enter. 2. Select NEXT PAGE and click Enter. 3. Select PRIVACY MASKING and click Enter.
  • Page 32 Using the On-Screen Display (OSD) Menu for C336ZC1 To set PTZ speed: 1. Launch the OSD menu. Use the on-screen arrow keys to navigate to FUNCTION SET- TING and click Enter. 2. Select NEXT PAGE and click Enter. 3. Under PTZ SPEED, use the left / right arrows to set the PTZ speed between 1 (slow- est) and 5 (fastest).
  • Page 33 Using the On-Screen Display (OSD) Menu for C336ZC1 1.4.10 Menu Password You can set a password that will be required to configure the OSD menu. To set a menu password: 1. Launch the OSD menu. Use the on-screen arrow keys to navigate to FUNCTION SET- TING and click Enter.
  • Page 34 Using the On-Screen Display (OSD) Menu for C336ZC1 To set menu idle: 1. Launch the OSD menu. Use the on-screen arrow keys to navigate to FUNCTION SET- TING and click Enter. 2. Select NEXT PAGE and click Enter. 3. Under MENU IDLE, use the left / right arrows to set the length of time before the OSD menu closes automatically (1MIN - 5MIN) or select OFF to prevent the menu from closing automatically.
  • Page 35 Using the On-Screen Display (OSD) Menu for C336ZC1 RELAY OUT • • 1–5S RESET DELAY • • • • • 120S To configure an alarm device: 1. Launch the OSD menu. Use the on-screen arrow keys to navigate to ALARM SET- TING and click Enter.
  • Page 36 C336ZC1 OSD Menu Default Values 2.1 System Settings Menu SETTING DEFAULT VALUE HARD SYSTEM SETTING → ADDR INFORMATION → ADDR TYPE SYSTEM SETTING → LANGUAGE ENGLISH 2.2 Display Settings Menu DEFAULT VALUE SETTING DISPLAY SETTING → PRESET DISPLAY SETTING → AZIMUTH DISPLAY DISPLAY SETTING →...
  • Page 37 C336ZC1 OSD Menu Default Values SETTING DEFAULT VALUE CAMERA SETTING → IMAGE ADJUST → HUE CAMERA SETTING → IMAGE ADJUST → BRIGHTNESS CAMERA SETTING → IMAGE ADJUST → SATURATION CAMERA SETTING → IMAGE ADJUST → CHROMA SUPPRESS CAMERA SETTING → IMAGE ADJUST → GAMMA CAMERA SETTING →...
  • Page 40 © 2015, FLIR Systems, Inc. All rights reserved worldwide. Names and marks appearing herein are either registered trademarks or trademarks of FLIR Systems and/or its subsidiaries. All other trademarks, trade names or company names referenced herein are used for identification only and are the property of their respective owners.
