Grandview Sky-Show User Manual

Limit Settings
The screen is fitted with 2 limits. The limits
automatically stop the screen in the fully Up
(top limit) and fully Down (bottom limit)
positions. You can adjust the bottom limit to
set your viewing height.
Setting The Bottom Limit
Caution: Setting the bottom limit beyond the black
leader may render your screen inoperable and
void your warranty
The bottom limit switch is accessible through a
grommeted hole on the left side of the casing.
Lower the screen to the operating position then
insert the supplied Hex key into the white coloured
screw. Turn it clockwise to raise the screen or turn
it anti-clockwise to lower the screen.
When lowering the bottom limit the screen will
move as you adjust it.
When raising the bottom limit please lift and lower
the screen with the remote or side buttons to see
the new limit setting.
Protecting Your Screen:
• Keep away from direct sunlight or
high temperatures.
• Examine both the front and back
surfaces before retracting into the
case to make sure it is free of dust,
dirt, insects or other foreign matter.
• Use a soft brush or cloth to lightly
remove any foreign particles.
Cleaning Your Screen:
• Do not use any solvents, chemicals
or abrasive cleaners on the
screen surface.
• Use a mild detergent with warm water
to remove any marks on the surface or
screen case.
• Always immediately dab the screen
with a soft cloth to avoid soap marks.
• Do not scrub the surface.
Warranty: 12 Months
Imported and Distributed in Australia by
Herma Technologies
Factory 4A, 6 Albert St
Preston, VIC 3072
For more information please go to
www.grandviewscreens.com.au
or call 1300 730 025
Nov 2008 v1
