Administration; Password; Ssh; Telnet - Trango Systems Altum AC 600 User Manual

3.2 Administration
Within the System → Administration page, you can
configure the radio Password, SSH, Telnet, Web, and
FTP settings.
3.2.1 Password
Figure 23: Setting the radio password.
Password: Allows changing the password, the default
being trango.
Confirmation: Requires you to re‐enter the password.
3.2.2 SSH
Figure 24: SSH settings in the System →
Administration page.
SSH: Allows access the radio's Linux shell and file
system using the Secure Shell protocol. For example,
the programs PuTTY and WinSCP can be used. It is
recommended to use the web interface for normal
setup and monitoring operations, and use SSH only
for debugging if needed.
14
Interface: Lets the radio listen on a given interface or
all interfaces.
Port: Specifies the listening port, the default being 22.
Password authentication: Allows SSH password
authentication.
Allow root logins with password: This is enabled by
default.
Gateway ports: Allow remote hosts to connect to
local SSH forwarded ports.
3.2.3 Telnet
Figure 25: Telnet settings in the System →
Telnet: Provides administrator tools for controlling
the device or network debugging, over an
unencrypted connection. It is recommended to use
the web interface for normal setup and monitoring
operations, and use Telnet only for debugging if
needed.
Port: Specifies the listening port, the default being 23.
3.2.4 Web
Figure 26: The radio's web server mode and port.
Web Server Mode: This can be set to Hypertext
Transfer Protocol (HTTP) or Hypertext Transfer
Protocol Secure (HTTPS). For HTTPS, if you see the
warning, "The certificate is not trusted because it is
self‐signed". Click "Add Exception", "Confirm Security
Exception" and proceed.
LT‐9064 Rev A
Administration page.
Altum AC 600 User Manual
