Sharp LC-30HV6U Service Manual page 99

Ref. No. Part No.
DKEYHC094FE51
MAIN UNIT (Display)(Continued)
R2216 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2217 VRS-CY1JF473JY J 47k 1/16W Metal Oxide
R2218 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2219 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2220 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2221 VRS-CY1JF822FY J 8.2k 1/16W Metal Oxide
R2222 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2224 VRS-CY1JF222FY J 2.2k 1/16W Metal Oxide
R2227 VRS-CY1JF223JY J 22k 1/16W Metal Oxide
R2228 VRS-CY1JF223JY J 22k 1/16W Metal Oxide
R2229 VRS-CY1JF000JY J 0
R2230 VRS-CY1JF473FY J 47k 1/16W Metal Oxide
R2231 VRS-CY1JF473FY J 47k 1/16W Metal Oxide
R2232 VRS-CY1JF473JY J 47k 1/16W Metal Oxide
R2233 VRS-CY1JF100FY J 10
R2234 VRS-CY1JF473JY J 47k 1/16W Metal Oxide
R2235 VRS-CY1JF100FY J 10
R2238 VRS-CY1JF220JY J 22
R2239 VRS-CY1JF220JY J 22
R2240 VRS-CY1JF473JY J 47k 1/16W Metal Oxide
R2241 VRS-CY1JF220JY J 22
R2242 VRS-CY1JF473JY J 47k 1/16W Metal Oxide
R2243 VRS-CY1JF220JY J 22
R2244 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide
R2245 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2246 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide
R2247 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2248 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide
R2249 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2251 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2252 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2253 VRS-CY1JF330JY J 33
R2254 VRS-CY1JF330JY J 33
R2256 VRK-CD1JJ680JY J 68
R2257 VRK-CD1JJ680JY J 68
R2258 VRS-CB1JF680JY J 68
R2259 VRS-CA1JF680JY J 68
R2260 VRS-CY1JF102JY J 1k
R2261 VRS-CY1JF511JY J 510 1/16W Metal Oxide
R2262 VRS-CY1JF102JY J 1k
R2263 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2264 VRS-CY1JF000JY J 0
R2265 VRS-CY1JF223JY J 22k 1/16W Metal Oxide
R2266 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide
R2267 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2268 VRS-CY1JF223JY J 22k 1/16W Metal Oxide
R2269 VRS-CY1JF223JY J 22k 1/16W Metal Oxide
R2270 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide
R2272 VRS-CY1JF223JY J 22k 1/16W Metal Oxide
R2273 VRS-CY1JF223JY J 22k 1/16W Metal Oxide
R2274 VRS-CY1JF223JY J 22k 1/16W Metal Oxide
R2275 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2276 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide
R2278 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide
R2279 VRS-CY1JF223JY J 22k 1/16W Metal Oxide
R2281 VRK-CD1JJ680JY J 68
R2282 VRS-CB1JF680JY J 68
R2283 VRS-CA1JF680JY J 68
R2284 VRK-CD1JJ680JY J 68
R2285 VRS-CA1JF680JY J 68
R2286 VRS-CB1JF680JY J 68
R2287 VRS-CY1JF223JY J 22k 1/16W Metal Oxide
R2288 VRS-CY1JF223JY J 22k 1/16W Metal Oxide
R2289 VRS-CY1JF223JY J 22k 1/16W Metal Oxide
R2291 VRS-CA1JF680JY J 68
R2292 VRS-CY1JF000JY J 0
R2293 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2296 VRS-CY1JF104JY J 100k 1/16W Metal Oxide
R2297 VRS-CY1JF473JY J 47k 1/16W Metal Oxide
R2298 VRS-CY1JF104JY J 100k 1/16W Metal Oxide
Description Code
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
1/16W Metal Oxide AA
AA
AA
AA
1/16W Metal Oxide AB
AA
1/16W Metal Oxide AB
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
AA
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Compo. AC
1/16W Metal Compo. AC
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
1/16W Metal Compo. AC
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Compo. AC
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
AA
AA
99
Ref. No. Part No.
MISCELLANEOUS PARTS
CN2001 QSOCN0464FJZZY J Socket, 50-pin(MC)
FB2001 RBLN-0006TAZZY J Ferrite Bead
FB2002 RBLN-0050TAZZY J Ferrite Bead
FB2003 RBLN-A005WJZZY J Ferrite Bead
FB2004 RBLN-A005WJZZY J Ferrite Bead
FB2005 RBLN-A005WJZZY J Ferrite Bead
FB2006 RBLN-A005WJZZY J Ferrite Bead
FB2007 RBLN-A005WJZZY J Ferrite Bead
FB2008 RBLN-A005WJZZY J Ferrite Bead
FB2009 RBLN-A005WJZZY J Ferrite Bead
FB2010 RBLN-A005WJZZY J Ferrite Bead
FB2011 RBLN-A005WJZZY J Ferrite Bead
FB2012 RBLN-A005WJZZY J Ferrite Bead
FB2013 RBLN-A005WJZZY J Ferrite Bead
FB2014 RBLN-A005WJZZY J Ferrite Bead
FB2015 RBLN-A005WJZZY J Ferrite Bead
FB2016 RBLN-A005WJZZY J Ferrite Bead
FB2021 RBLN-A005WJZZY J Ferrite Bead
FB2022 RBLN-A005WJZZY J Ferrite Bead
FB2023 RBLN-A005WJZZY J Ferrite Bead
FB2201 RBLN-0006TAZZY J Ferrite Bead
FB2203 RBLN-0210TAZZY J Ferrite Bead
FB2204 RBLN-0210TAZZY J Ferrite Bead
FB2205 RBLN-0006TAZZY J Ferrite Bead
FB2206 RBLN-0006TAZZY J Ferrite Bead
FB2207 RBLN-0210TAZZY J Ferrite Bead
FB2208 RBLN-0006TAZZY J Ferrite Bead
FB2209 RBLN-0006TAZZY J Ferrite Bead
FB2211 RBLN-A005WJZZY J Ferrite Bead
FB2212 RBLN-A005WJZZY J Ferrite Bead
P2001 QPLGN0548FJZZY J Plug, 11-pin
P2002 QPLGNA059WJZZ J Plug, 5-pin(KK)
P2003 QPLGNA064WJZZ J Plug, 10-pin(AM)
P2004 QPLGNA047WJZZ J Plug, 8-pin(RM)
P2101 QPLGNA046WJZZ J Plug, 7-pin(PA)
P2102 QPLGNA045WJZZ J Plug, 6-pin(PB)
P2103 QPLGN0175FJZZY J Plug, 3-pin(MB)
P2104 QPLGNA045WJZZ J Plug, 6-pin(SA)
P2106 QPLGN0364TAZZY J Plug, 3-pin(MD)
P2107 QLUGHA001WJZZY J Lug
P2235 QLUGHA001WJZZY J Lug
P2236 QLUGHA001WJZZY J Lug
P2237 QLUGHA001WJZZY J Lug
P2238 QLUGHA001WJZZY J Lug
P2239 QLUGHA001WJZZY J Lug
P2240 QLUGHA001WJZZY J Lug
P2243 QLUGHA001WJZZY J Lug
SC2201 QSOCZA017WJZZ J DISPLAY INPUT-1 Terminal AM
SC2202 QSOCZ2015CEZZ J DISPLAY INPUT-2 Terminal AG
SC2203 QCNCWA015WJZZ J Connector, 80-pin
PSLDMA278WJFN J Terminal Shield
PSLDMA280WJFW J Shield
QCNW-B680WJQZ J Connecting Cord
QCNW-B681WJQZ J Connecting Cord
QCNW-B683WJQZ J Connecting Cord
QCNW-B684WJQZ J Connecting Cord
QCNW-B812WJQZ J Connecting Cord
QCNW-B816WJQZ J Connecting Cord
NSFTZ0134CEFW J Shaft Screw, x2
LHLDWA035WJZZ J Wire Holder, x1
LHLDW1046CEZZ J Wire Holder, x1
LX-BZ3434CEFN J Screw, x2
XBPSN30P06JS0 J Screw, x4
LC-30HV6U
Description Code
AH
AB
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AB
AB
AB
AB
AB
AB
AB
AB
AA
AA
AE
AC
AD
AC
AC
AC
AC
AC
AC
AD
AD
AD
AD
AD
AD
AD
AD
AU
AK
AK
AM
AG
AH
AH
AE
AK
AD
AC
AA
AB
AB
