Sharp LC-30HV6U Service Manual page 100

LC-30HV6U
Ref. No. Part No.
DUNTKC096DE02
AUDIO UNIT (Display)
INTEGRATED CIRCUITS
IC3803 VHiTA8184F/-1Y
IC3804 VHiM62392FP-1Y
IC3805 VHiPST529DM-1Y
IC3808 VHiNJM4565M-1Y
IC3810 VHiPQ20WZ51-1Y
IC3812 VHiBA09T/FP-1Y
IC3816 VHiBA05SFP+-1Y
TRANSISTORS
Q3801 VS2SA1530AR-1Y
Q3802 VS2SA1530AR-1Y
Q3803 VS2SC3928AR-1Y
Q3804 VSDTC314TK/-1Y
Q3805 VSDTC314TK/-1Y
Q3806 VSDTC144EE/-1Y
Q3807 VSDTC144EE/-1Y
Q3808 VSDTC144EE/-1Y
Q3901 VS2SC3928AR-1Y
Q3902 VS2SC3928AR-1Y
DIODES
D3801 VHDHSU119//-1Y
D3802 VHDHSU119//-1Y
D3803 VHDDAN222//-1Y
D3804 RH-PX0421CEZZY
D3805 RH-PX0421CEZZY
D3806 VHDHSU119//-1Y
D3807 VHDHSU119//-1Y
D3808 VHDHSU119//-1Y
D3901 VHDHSU119//-1Y
D3902 VHDHSU119//-1Y
D3903 RH-EX1283CEZZY
D3904 RH-EX1283CEZZY
D3905 RH-EX1283CEZZY
D3906 RH-EX1283CEZZY
CAPACITORS
C3804 VCKYTV1CB224KY J 0.22
C3805 VCEASX1HN475MY J 4.7
C3806 VCEASX1HN475MY J 4.7
C3807 VCKYCY1HB102KY J 1000p 50V
C3808 VCKYCY1EF104ZY J 0.1
C3809 VCKYCY1HB822KY J 8200p 50V
C3810 VCKYCY1HB822KY J 8200p 50V
C3811 VCKYCY1AB334KY J 0.33
C3812 VCKYCY1AB334KY J 0.33
C3813 VCKYTV1CB224KY J 0.22
C3814 VCEASX1HN106MY J 10
C3815 VCEASX1HN106MY J 10
C3816 VCEASX1HN106MY J 10
C3817 VCEASX1HN106MY J 10
C3818 VCEASX1CN476MY J 47
C3819 VCEASX1HN105MY J 1
C3820 RC-KZ1025CEZZY
C3821 VCKYCY1EB473KY J 0.047 25V
C3822 VCKYCY1EF104ZY J 0.1
C3823 RC-KZ1025CEZZY
C3824 VCEASX1HN225MY J 2.2
C3825 VCEASX1HN225MY J 2.2
C3826 VCKYCY1HB102KY J 1000p 50V
C3827 VCKYCY1EF104ZY J 0.1
C3828 VCKYCY1HB102KY J 1000p 50V
C3829 VCEASW1EN476MY J 47
C3830 VCKYCY1EF104ZY J 0.1
C3831 VCEASW0JN227MY J 220
C3832 VCCCCY1HH270JY J 27p
C3833 VCCCCY1HH270JY J 27p
C3834 VCEASX1CN226MY J 22
C3835 RC-KZ0117TAZZY
C3836 VCEASX1EN336MY J 33
Description Code
J TA8184F AL
J M62392FP AM
J PST529DMT AE
J NJM4565M AE
J PQ20WZ5U AF
J BA09FP-E2 AG
J BA05SFP-E2 AG
J 2SA1530AR AB
J 2SA1530AR AB
J 2SC3928AR AB
J DTC314TK AC
J DTC314TK AC
J DTC144EE AA
J DTC144EE AA
J DTC144EE AA
J 2SC3928AR AB
J 2SC3928AR AB
J Diode AB
J Diode AB
J Diode AA
J Photodiode AD
J Photodiode AD
J Diode AB
J Diode AB
J Diode AB
J Diode AB
J Diode AB
J Zener Diode, 18V AB
J Zener Diode, 18V AB
J Zener Diode, 18V AB
J Zener Diode, 18V AB
16V Ceramic AB
50V Electrolytic AC
50V Electrolytic AC
Ceramic AA
25V Ceramic AA
Ceramic AB
Ceramic AB
10V Ceramic AB
10V Ceramic AB
16V Ceramic AB
50V Electrolytic AC
50V Electrolytic AC
50V Electrolytic AC
50V Electrolytic AC
16V Electrolytic AC
50V Electrolytic AB
J 1 10V Ceramic AB
Ceramic AA
25V Ceramic AA
J 1 10V Ceramic AB
50V Electrolytic AB
50V Electrolytic AB
Ceramic AA
25V Ceramic AA
Ceramic AA
25V Electrolytic AC
25V Ceramic AA
6.3V Electrolytic AC
50V Ceramic AA
50V Ceramic AA
16V Electrolytic AC
J 4.7 6.3V Ceramic AD
25V Electrolytic AC
Ref. No. Part No.
C3838 VCEASX1HN225MY J 2.2
C3839 VCEASX1HN225MY J 2.2
C3840 VCEASX1CN106MY J 10
C3841 VCKYCY1HF223ZY J 0.022 50V Ceramic
C3842 VCKYCY1HF223ZY J 0.022 50V Ceramic
C3843 VCEASX1CN476MY J 47
C3844 VCEASX1CN106MY J 10
C3845 VCEASX1HN225MY J 2.2
C3846 VCEASX1HN225MY J 2.2
C3847 VCEASX1CN106MY J 10
C3848 VCKYCY1EF104ZY J 0.1
C3850 VCEASW1EN227MY J 220
C3852 VCEASX1VN227MY J 220
C3853 RC-KZ1025CEZZY
C3854 VCEASW1EN337MY J 330
C3855 VCEASW1CN477MY J 470
C3876 VCEASX1CN476MY J 47
C3881 VCEASX1CN106MY J 10
C3885 VCKYCY1HB102KY J 1000p 50V Ceramic
C3886 VCKYCY1HB102KY J 1000p 50V Ceramic
C3901 VCCCCY1HH151JY J 150p
C3902 VCCCCY1HH151JY J 150p
C3903 VCKYCY1CF224ZY J 0.22
C3904 VCCCCY1HH151JY J 150p
C3905 VCCCCY1HH151JY J 150p
C3906 VCCCCY1HH151JY J 150p
C3907 VCCCCY1HH151JY J 150p
C3908 VCKYCY1CF224ZY J 0.22
C3909 VCKYCY1HF223ZY J 0.022 50V Ceramic
C3910 VCKYCY1HF223ZY J 0.022 50V Ceramic
C3911 VCKYCY1HB102KY J 1000p 50V Ceramic
C3912 VCKYCY1HB102KY J 1000p 50V Ceramic
C3913 VCKYCY1HB102KY J 1000p 50V Ceramic
C3914 VCKYCY1HB102KY J 1000p 50V Ceramic
RESISTORS
R3801 VRS-CY1JF000JY
R3803 VRS-CY1JF103JY
R3804 VRS-CY1JF000JY
R3807 VRS-CY1JF222JY
R3808 VRS-CY1JF102JY
R3809 VRS-CY1JF101JY
R3810 VRS-CY1JF332JY
R3811 VRS-CY1JF101JY
R3812 VRS-CY1JF222JY
R3813 VRS-CY1JF103JY
R3814 VRS-CY1JF103JY
R3815 VRS-CY1JF332JY
R3816 VRS-CY1JF153JY
R3817 VRS-CY1JF223JY
R3818 VRS-CY1JF223JY
R3819 VRS-CY1JF101JY
R3821 VRS-CY1JF223JY
R3823 VRS-CY1JF101JY
R3824 VRS-CY1JF101JY
R3825 VRS-CY1JF102JY
R3826 VRS-CY1JF102JY
R3827 VRS-CY1JF562JY
R3828 VRS-CY1JF473JY
R3829 VRS-CY1JF473JY
R3830 VRS-CY1JF222JY
R3831 VRS-CY1JF223JY
R3832 VRS-CY1JF223JY
R3833 VRS-CY1JF184JY
R3834 VRS-CY1JF184JY
R3835 VRS-TW2ED000JY J 0
R3836 VRS-CY1JF822FY
R3837 VRS-CY1JF103JY
R3838 VRS-CY1JF202FY
R3839 VRS-CY1JF103JY
R3840 VRS-CY1JF103JY
R3841 VRS-CY1JF103JY
R3842 VRS-CY1JF562JY
R3843 VRS-TW2ED000JY J 0
R3844 VRS-CY1JF473JY
100
Description Code
50V Electrolytic AB
50V Electrolytic AB
16V Electrolytic AC
AB
AB
16V Electrolytic AC
16V Electrolytic AC
50V Electrolytic AB
50V Electrolytic AB
16V Electrolytic AC
25V Ceramic AA
25V Electrolytic AD
35V Electrolytic AD
J 1 10V Ceramic AB
25V Electrolytic AD
16V Electrolytic AD
16V Electrolytic AC
16V Electrolytic AC
AA
AA
50V Ceramic AA
50V Ceramic AA
16V Ceramic AB
50V Ceramic AA
50V Ceramic AA
50V Ceramic AA
50V Ceramic AA
16V Ceramic AB
AB
AB
AA
AA
AA
AA
J 0 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 0 1/16W Metal Oxide AA
J 2.2k 1/16W Metal Oxide AA
J 1k 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 3.3k 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 2.2k 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 3.3k 1/16W Metal Oxide AA
J 15k 1/16W Metal Oxide AA
J 22k 1/16W Metal Oxide AA
J 22k 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 22k 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 100 1/16W Metal Oxide AA
J 1k 1/16W Metal Oxide AA
J 1k 1/16W Metal Oxide AA
J 5.6k 1/16W Metal Oxide AA
J 47k 1/16W Metal Oxide AA
J 47k 1/16W Metal Oxide AA
J 2.2k 1/16W Metal Oxide AA
J 22k 1/16W Metal Oxide AA
J 22k 1/16W Metal Oxide AA
J 180k 1/16W Metal Oxide AA
J 180k 1/16W Metal Oxide AA
1/4W Metal Oxide AB
J 8.2k 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 2.0k 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 10k 1/16W Metal Oxide AA
J 5.6k 1/16W Metal Oxide AA
1/4W Metal Oxide AB
J 47k 1/16W Metal Oxide AA
