Sharp LC-30HV6U Service Manual page 101

Ref. No. Part No.
DUNTKC096DE02
AUDIO UNIT (Display)(Continued)
R3845 VRS-CY1JF104JY J 100k 1/16W Metal Oxide
R3846 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R3847 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R3848 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R3849 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R3850 VRS-TV1JD181FY J 180 1/10W Metal Oxide
R3851 VRS-TV1JD181FY J 180 1/10W Metal Oxide
R3852 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide
R3853 VRS-TV1JD181FY J 180 1/10W Metal Oxide
R3854 VRS-CY1JF471JY J 470 1/16W Metal Oxide
R3855 VRS-CY1JF471JY J 470 1/16W Metal Oxide
R3856 VRS-CY1JF104JY J 100k 1/16W Metal Oxide
R3861 VRS-CY1JF000JY J 0
R3901 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide
R3902 VRS-CY1JF104JY J 100k 1/16W Metal Oxide
R3903 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide
R3904 VRS-CY1JF104JY J 100k 1/16W Metal Oxide
R3905 VRS-TW2ED101JY J 100 1/4W
R3906 VRS-TW2ED101JY J 100 1/4W
R3907 VRS-TW2ED101JY J 100 1/4W
R3908 VRS-TW2ED101JY J 100 1/4W
MISCELLANEOUS PARTS
RY3801 RRLYDA004WJZZ J Relay
RY3901 RRLYDA002WJZZY J Relay
RY3902 RRLYDA002WJZZY J Relay
FB3901 RBLN-0210TAZZY J Ferrite Bead
FB3902 RBLN-0210TAZZY J Ferrite Bead
FB3903 RBLN-0210TAZZY J Ferrite Bead
FB3904 RBLN-0210TAZZY J Ferrite Bead
J3901 QSOCDA016WJZZ J DISPLAY INPUT3 Terminal AG
P3801 QPLGNA045WJZZ J Plug, 6-pin(SA)
P3803 QPLGN1558REZZY J Plug, 15-pin(SB)
P3804 QPLGNA049WJZZ J Plug, 10-pin(AM)
P3805 QLUGHA001WJZZY J Lug
P3806 QLUGHA001WJZZY J Lug
P3807 QLUGHA001WJZZY J Lug
P3901 QLUGHA001WJZZY J Lug
P3902 QLUGHA001WJZZY J Lug
P3903 QPLGN0858REZZY J Plug, 8-pin(SD)
P3904 QPLGNA059WJZZ J Plug, 5-pin(SC)
PSLDMA279WJFN J Terminal Shield
LHLDW1076GEZZ J Wire Holder, x1
XBPSN30P06JS0 J Screw, x2
Description Code
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
1/16W Metal Oxide AA
AA
AA
AA
AA
Metal Oxide AA
Metal Oxide AA
Metal Oxide AA
Metal Oxide AA
AN
AK
AK
AB
AB
AB
AB
AC
AD
AD
AD
AD
AD
AD
AD
AD
AC
AG
AA
AB
101
Ref. No. Part No.
DUNTKC097DE02
R/C, LED UNIT (Display)
INTEGRATED CIRCUIT
IC101 VHiTPS850++-1Y J TPS850
TRANSISTORS
Q101 VS2SC2712Y/-1Y J 2SC2712Y
Q102 VS2SC2712Y/-1Y J 2SC2712Y
Q103 VS2SC2712Y/-1Y J 2SC2712Y
Q104 VS2SC3928AR-1Y J 2SC3928AR
Q105 VS2SC3928AR-1Y J 2SC3928AR
Q106 VS2SC2712Y/-1Y J 2SC2712Y
DIODES
D101 RH-PX0419CEZZY J SLEEP Indicator
D102 RH-PX0421CEZZY J POWER Indicator
D103 RH-PX0421CEZZY J OPC Indicator
D104 RH-EXA092WJZZY J Zener Diode, 12V
CAPACITORS
C102 VCKYTV1CF225ZY J 2.2
C104 VCEASX1CN106MY J 10
C105 VCKYCY1HF103ZY J 0.01
RESISTORS
R101 VRS-CY1JF273JY J 27k 1/16W Metal Oxide
R102 VRS-CY1JF393JY J 39k 1/16W Metal Oxide
R103 VRS-CY1JF683JY J 68k 1/16W Metal Oxide
R104 VRS-CY1JF273JY J 27k 1/16W Metal Oxide
R105 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide
R108 VRS-CY1JF471JY J 470 1/16W Metal Oxide
R109 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide
R111 VRS-CY1JF273JY J 27k 1/16W Metal Oxide
R112 VRS-CY1JF471JY J 470 1/16W Metal Oxide
R114 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R115 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
MISCELLANEOUS PARTS
P101 QPLGNA062WJZZ J Plug, 8-pin(RM)
RMC101 RRMCU0239CEZZ J Remote Receiver
SLD101 PSLDM4646CEFW J Shield
QCNW-B809WJQZ J Connecting Cord
LC-30HV6U
Description Code
AG
AB
AB
AB
AB
AB
AB
AC
AD
AD
AB
16V Ceramic AB
16V Electrolytic AC
50V Ceramic AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AC
AG
AD
AL
