INSTALLATION INSTRUCTIONS FOR PART 99-7402
APPLICATIONS
Nissan
350Z 2003-2005
99-7402
KIT FEATURES
• DIN Radio Provision with pocket
• ISO Radio Provision with pocket
• Two stacked ISO units provision
• Double DIN radio provision
KIT COMPONENTS
A) Radio Housing with Pocket B) Double DIN Trim-plate C) ISO Spacer Brackets D) ISO Snap-in Brackets E) ISO Trim-plate
A
B
C
D
E
TOOLS REQUIRED:
Panel Removal Tool or
Phillips Screwdriver
Small Flat Blade Screwdriver
1-800-221-0932
www.metraonline.com
© COPYRIGHT 2004 METRA ELECTRONICS CORPORATION
Advertisement
Related Manuals for Metra Electronics 99-7402
Summary of Contents for Metra Electronics 99-7402
- Page 1 INSTALLATION INSTRUCTIONS FOR PART 99-7402 APPLICATIONS Nissan 350Z 2003-2005 99-7402 KIT FEATURES • DIN Radio Provision with pocket • ISO Radio Provision with pocket • Two stacked ISO units provision • Double DIN radio provision KIT COMPONENTS A) Radio Housing with Pocket B) Double DIN Trim-plate C) ISO Spacer Brackets D) ISO Snap-in Brackets E) ISO Trim-plate...
-
Page 2: Table Of Contents
99-7402 T ABLE OF CONTENTS Dash Disassembly Nissan 350Z 2003-2005...1, 2 Kit Assembly Din Mount Radio Provision with pocket... ISO Mount Radio Provision with pocket... Double DIN Radio... Two Stacked ISO mount units... Final Assembly ... 7... -
Page 3: Dash Disassembly Nissan 350Z 2003-2005
99-7402 DASH DISASSEMBL Y NISSAN 350Z 2003-2005 Disconnect the negative battery terminal to prevent an accidental short circuit. For vehicles with automatic trans- mission, Unsnap and remove smaller trim-ring from around shifter. (Figure A) For vehicles with manual transmis- sion, Unscrew and remove shifter knob. -
Page 4: Dash Disassembly Nissan 350Z 2003-2005
99-7402 DASH DISASSEMBL Y NISSAN 350Z 2003-2005 Remove (2) screws above the radio and (2) screws below the radio. Also remove (2) screws securing the radio/trim panel assembly. (Figure E) Unplug and remove the radio / trim panel assembly. (Figure F) -
Page 5: Kit Assembly
99-7402 DIN MOUNT RADIO PROVISION WITH POCKET Slide DIN cage (supplied with radio) into the radio housing from the front. (Figure A) Secure DIN cage to radio housing by bending the locking tabs outward. (Figure A) Slide the radio into the DIN cage until it snaps into place. -
Page 6: Iso Mount Radio Provision With Pocket
99-7402 ISO MOUNT RADIO WITH POCKET Align the holes in the ISO brackets with the holes in the radio. Mount the brackets to the radio using screws supplied with the radio. (Figure A) Slide the radio bracket assembly into the radio housing until it snaps into place. -
Page 7: Double Din Radio
99-7402 DOUBLE DIN RADIO Cut and remove center divider from double DIN trim-plate. (Figure A) Place the double DIN trim-plate on the front of the radio. (Figure B) Place one of the ISO spacer brackets and the right factory mounting... -
Page 8: Two Stacked Iso Mount Units
99-7402 TWO STACKED ISO MOUNT UNITS Place the double DIN trim-plate on the front of the two ISO units. (Figure A) Place one of the ISO spacer brackets and the right factory mounting bracket (Removed from radio during disassembly) on the right side of the ISO units. -
Page 9: Final Assembly
99-7402 FINAL ASSEMBL Y 1 Locate the factory wiring harness in the dash and make the connection as shown. Metra recomends using the proper mating adapter and making the connections as shown. (Isolate and individually tape off the ends of any unused wires to prevent electrical short circuit.) - Page 10 99-7402 NOTES...
- Page 11 99-7402 NOTES...
- Page 12 99-7402 INSTRUCTIONS 1-800-221-0932 www.metraonline.com © COPYRIGHT 2004 METRA ELECTRONICS CORPORATION INST99-7402 REV. 05/05/06...
