Metra Electronics 99-7407 Installation Instructions

4
Fig. A
IF AN EQUALIZER WILL BE INCLUDED: Slide the aftermarket equalizer into the back of the
Radio Housing. Using the hardware included with the equalizer, mount the unit to the kit.
(see Fig. A)
IF AN EQUALIZER WILL NOT BE INCLUDED: Snap the Equalizer Dummy Plate into the
Radio Housing. (see Fig. B)
5
A
B
C
D
A) Strip wire ends back ½"
B) Twist ends together
C) Solder
D) Tape
Locate the factory wiring harness in the
dash. Metra recommends using the
proper mating adaptor and making
connections as shown. (Isolate and
individually tape off the ends of any
unused wires to prevent electrical short
circuit).
3
Fig. B
6
Re-connect the battery terminal and test the unit
for proper operation. Mount the head unit/kit
assembly to the sub-dash with (4) screws
previously removed in step #1.
rev. 100103
KIT FEATURES
Shaft and
DIN unit
99-7407
provisions
Equalizer
INSTALLATION
provisions
INSTRUCTIONS
KIT COMPONENTS
Radio Housing
APPLICATIONS
CAR
NISSAN
240SX 1989-94........................................................... 1
Maxima 1989-94.........................................................1
Stanza 1987-89...........................................................2
Faceplate
#1
Faceplate
#2
Equalizer
Dummy Plate
TOOLS REQUIRED
Phillips screwdriver
Cutting tool
1-800-221-0932
Wrench
© COPYRIGHT 2001 METRA ELECTRONICS CORPORATION
