INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
MT. VERNON E2 INSERT
PELLET STOVE
Model(s):
MTVI-E2-MBK
MTVI-E2-CSB
MTVI-E2-PMH
Please read this entire manual before installation and use of this
pellet fuel-burning room heater. Failure to follow these instructions
could result in property damage, bodily injury or even death.
CAUTION
Tested and approved for wood pellets and shelled
corn only. Burning of any other type of fuel voids your
warranty.
A 2:1 mix of pellets to corn is approved, but may require the
fi repot to be cleaned more frequently.
To obtain a French translation of this manual, please contact
your dealer or visit www.quadrafi re.com
Pour obtenir une traduction française de ce manuel, s'il vous
00
plaît contacter votre revendeur ou visitez www.quadrafi re.com
1
Installation Manual
Installation & Appliance Set-Up
NOTICE: DO NOT DISCARD THIS MANUAL
Tested and
O-T L
Listed by
C
OMNI-Test Laboratories, Inc.
061-S-84-2
NOTE
NOTE
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfi re - If heater or chimney con-
nector glows, you are overfi ring. Overfi ring
will void your warranty.
• Comply with all minimum clearances to
combustibles as specifi ed. Failure to
comply may cause house fi re.
Portland
Oregon USA
US
Hot glass will cause burns.
•
Do not touch glass until it is cooled
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
fi replace.
•
Alert children and adults to hazards of high temperatures
•
High temperatures may ignite clothing or other
fl ammable materials.
•
Keep clothing, furniture, draperies and other fl ammable
materials away.
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and na-
tional codes and regulations.
• Consult local building, fi re offi cials or authorities having juris-
diction about restrictions, installation inspection, and permits.
7082-131J
WARNING
If the information in these instruc-
tions is not followed exactly, a
fi re could result causing property
damage, personal injury, or death.
WARNING
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
CAUTION
August 3, 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MTVI-E2-MBK and is the answer not in the manual?

Questions and answers

Related Manuals for Quadra-Fire MTVI-E2-MBK

Summary of Contents for Quadra-Fire MTVI-E2-MBK

  • Page 1 PELLET STOVE damage, personal injury, or death. Model(s): • Do not store or use gasoline or other fl am- MTVI-E2-MBK mable vapors and liquids in the vicinity of this or any other appliance. MTVI-E2-CSB • Do not overfi re - If heater or chimney con- MTVI-E2-PMH nector glows, you are overfi...

  • Page 2: Table Of Contents

    I. Power Cord ................22 G. Installation into a Masonry Fireplace ........11 J. Trim Adjustment..............23 H. Prefabricated Metal Chimney ...........11 Mobile Home Installation ....24 Accessory List ........25 Quadra-Fire is a registered trademark of Hearth & Home Technologies. 7082-131J August 3, 2015...

  • Page 3: Important Safety Information

    - Iron cause undesired operation. - Concrete - Tile The Quadra-Fire Mt. Vernon E2 Pellet Insert meets the U.S. Envi- - Glass - Slate ronmental Protection Agency’s emission limits for pellet inserts Materials reported as passing ASTM E 136, Standard sold after May 15, 2015.

  • Page 4: Getting Started

    MT VERNON E2 INSERT Install Guide Getting Started A. Design, Installation & Location Considerations Since pellet exhaust can contain ash, soot or sparks, you must consider the location of: 1. Appliance Location • Windows NOTICE: Check building codes prior to installation. •...

  • Page 5: Tools And Supplies Needed

    MT VERNON E2 INSERT B. Tools And Supplies Needed C. Inspect Appliance and Components • Open the appliance and remove all the parts and articles Tools and building supplies normally required packed inside the Component Pack. Inspect all the parts for installation, unless installing into an existing and glass for shipping damage.

  • Page 6: Install Checklist

    Location of Fireplace: Installer: Dealer/ Distributor Phone #: Serial #: Model (circle one): MTVI-E2-MBK MTVI-E2-CSB MTVI-E2-PMH WARNING! Risk of Fire or Explosion! Failure to install fi replace according to these instructions can lead to a fi re or explosion. Appliance Install IF NO, WHY? Required non-combustible fl...

  • Page 7: Dimensions And Clearances

    MT VERNON E2 INSERT Dimensions and Clearances A. Appliance Dimensions 16-1/2 [419] 32 [812] 23-7/8 [606] [23] [382] 29-3/4 [756] 23-7/8 [605] 13-1/8 [333] 26-1/4 [667] 26-7/8 [683] Figure 7.1 - Top View Figure 7.3 - Side View 36-5/8 [930] [838] 34-7/8 [886]...

  • Page 8: Clearance To Combustibles, Us & Canada

    MT VERNON E2 INSERT B. Clearance To Combustibles, US & Canada Built-in Unit - Rear Vent Figure 8.1 Location Confi guration Inches Millimeters Side of Outside Skin Top or Rear Vent Vent Pipe to Combustible Top or Rear Vent Cast Side to Side Wall Top or Rear Vent WARNING Built-in Unit - Rear Vent with Outside Air...

  • Page 9: Masonry & Zero Clearance Fireplaces

    MT VERNON E2 INSERT Built-In Vertical D. Floor Protection Location Inches Millimeters Floor protection hearth extension from door opening Floor protection to the side of door 3 in opening [76mm] • Use a non-combustible fl oor protector, extending beneath appliance and to the front, and sides as indicated. •...

  • Page 10: Installation Into A Factory-Built Fireplace

    MT VERNON E2 INSERT F. Installation into a Factory-Built Fireplace The following is only one example as there are many differ- ent models of factory-built fi replaces. The following modifi cations are permissible: NOTE: This example is for reference only. Any modifi ca- •...

  • Page 11: Installation Into A Masonry Fireplace

    MT VERNON E2 INSERT H. Prefabricated Metal Chimney Example Removal of Factory-Built Fireplace Cont. The chimney can be new or existing, masonry or prefabricated and must meet the following minimum requirements: • Must be minimum 6 inch (152mm) inside diameter of Keep sharp edge of high temperature chimney listed to UL 103 HT (2100 metal floor away from...

  • Page 12: Vent Information

    MT VERNON E2 INSERT Vent Information A. Venting Termination Minimum Requirements Electrical Service Inside Corner FIXED FIXED OPEN CLOSED CLOSED OPEN J or K Termination Cap Air Supply Inlet Restricted Area Gas Meter Figure 12.1 All minimum clearances are listed with an Outside Air Kit (OAK) installed, unless otherwise noted in table below. 12 in.

  • Page 13: Avoiding Smoke And Odors

    MT VERNON E2 INSERT B. Avoiding Smoke and Odors Vent Confi gurations Negative Pressure, Shut-Down and Electrical Power To reduce probability of reverse drafting during shut-down Failure conditions Hearth & Home Technologies strongly recom- To reduce the probability of back-drafting or burn-back in mends: the pellet appliance during power failure or shut down con- •...

  • Page 14: Negative Pressure

    2. Mobile Home: Approved for all Listed pellet vent. If using the 3 and other combustion appliances to 6 inch (76-152mm) Top Vent Offset Adapter, use Listed double wall fl ue connector. A Quadra-Fire Outside Air Kit (OAK-3) must • Clothes dryers be used with manufactured home installations.

  • Page 15: Equivalent Feet Of Pipe

    MT VERNON E2 INSERT F. Equivalent Feet of Pipe WARNING The table below can help you calculate the equivalent feet of pipe which is a method used to determine pellet vent size. Vent surfaces get HOT, can cause burns if Figure 15.1.

  • Page 16: Venting Systems

    MT VERNON E2 INSERT Venting Systems A. Full Reline With Outside Air - Horizontal WARNING Fire Risk. CAUTION Inspection of Chimney: • Masonry chimney must be in good condition. Never draw outside combustion air from: • Meets minimum standard of NFPA 211 •...

  • Page 17: Full Reline With Outside Air - Vertical

    MT VERNON E2 INSERT B. Full Reline With Outside Air - Vertical NOTE: In Canada only a full reline is allowed per ULC NOTE: Check clearances carefully for this type of instal- S628, ORD ULC C1482-M1990. lation to ensure adequate room for outside air venting. 12 in [305mm] min.

  • Page 18: Appliance Set-Up

    MT VERNON E2 INSERT Appliance Set-Up A. Leveling System The leveling bolts are located on the sides of the appliance, front and rear. To access the bolts, remove the front access panels. Reach in and turn the bolt to the desired height to level the appliance.

  • Page 19: Removal Of Cast Sides

    MT VERNON E2 INSERT E. Surround and Trim Set - Cast Included in Surround Kit: (2) side panels, left and right; 3 inch high Set (1) panel top; (1) fastener package. Attach Trim to Insert from inside Insert. Included in Cast Trim Kit: (2) cast trim legs, left and right; (1) cast trim header;...

  • Page 20: Surround & Trim Set, Basic

    MT VERNON E2 INSERT F. Surround & Trim Set, Basic G. Optional Log Set Placement Instructions Included in Surround & Trim Kit: (2) corner brackets and set 2 PIECE LOG SET INSTALLATION screws; (1) trim set, 3 piece; (2) side panels; (1) top panel; 1.

  • Page 21: Programmable Wall Thermostat Installation

    MT VERNON E2 INSERT H. Programmable Wall Thermostat Installation Programming Thermostat The appliance comes standard with a wall thermostat and 25’ of wire. If you need to run more than 25’ make sure you use The thermostat maintains a desired room temperature. The a continuous strand of 18 to 22 gauge thermostat wire.

  • Page 22: Power Cord

    MT VERNON E2 INSERT Battery Installation and Replacement Program Schedule Pre-set settings are shown below. You can program 4 time periods each day, with different NOTE: 2 AA batteries are included with the thermostat settings for weekdays and weekends. and must be installed before the appliance can be op- erated.

  • Page 23: Trim Adjustment

    MT VERNON E2 INSERT J. Trim Adjustment Where to Start: (Factory default setting is -2) If Burning Hardwood Pellet Fuel QuadraFire recommends setting the appliance at a -4 trim setting as a start. From our testing, hardwood fuels burn well between -4 and -2 settings. If Burning Lower BTU Pellet Fuel, Utility Pellet Fuel, or More Air &...

  • Page 24: Mobile Home Installation

    MT VERNON E2 INSERT Mobile Home Installation You must use a Quadra-Fire Outside Air Kit CAUTION for installation in a mobile home. THE STRUCTURAL INTEGRITY OF THE MOBILE HOME An outside air inlet must be provided for the combustion air and FLOOR, WALL AND CEILING/ROOF MUST BE MAINTAINED must remain clear of leaves, debris, ice and/or snow.

  • Page 25: Accessory List

    MT VERNON E2 INSERT Accessory List MT VERNON INSERT-E2 Service Parts Beginning Manufacturing Date: Dec 2014 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.
  • Page 26 MT VERNON E2 INSERT 7082-131J August 3, 2015...
  • Page 27 MT VERNON E2 INSERT August 3, 2015 7082-131J...
  • Page 28 Hearth & Home Technologies 1445 North Highway Colville, WA 99114 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafi re.com CAUTION DO NOT DISCARD THIS MANUAL...
