INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
MT. VERNON E2 PELLET APPLIANCE
Model(s):
MTV-E2-CSB-C
MTV-E2-PFT-C
MTV-E2-PBK-C
CAUTION
Tested and approved for wood pellets only. Burning of
any other type of fuel voids your warranty.
To obtain a French translation of this manual, please contact
your dealer or visit www.quadrafire.com
Pour obtenir une traduction française de ce manuel, s'il vous
00
plaît contacter votre revendeur ou visitez www.quadrafire.com
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
1
Installation Manual
Installation & Appliance Set-Up
NOTICE: DO NOT DISCARD THIS MANUAL
MTV-E2-MBK-C
MTV-E2-PDB-C
MTV-E2-PMH-C
NOTE
If the information in these instruc-
tions is not followed exactly, a
fire could result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not over fire - If appliance or chimney
connector glows, you are over firing. Over
firing will void your warranty.
• Comply with all minimum clearances to
combustibles as specified. Failure to
comply may cause house fire.
Hot glass will cause burns.
•
Do not touch glass until it is cooled
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
fireplace.
•
Alert children and adults to hazards of high temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other flammable
materials away.
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and na-
tional codes and regulations.
• Consult local building, fire officials or authorities having juris-
diction about restrictions, installation inspection, and permits.
7080-162B
WARNING
WARNING
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
CAUTION
October 12, 2017
Advertisement
Table of Contents
Related Manuals for Quadra-Fire MT VERNON E2-C
Summary of Contents for Quadra-Fire MT VERNON E2-C
- Page 1 Installation Manual Installation & Appliance Set-Up INSTALLER: Leave this manual with party responsible for use and operation. OWNER: Retain this manual for future reference. NOTICE: DO NOT DISCARD THIS MANUAL WARNING If the information in these instruc- MT. VERNON E2 PELLET APPLIANCE tions is not followed exactly, a fire could result causing property Model(s):...
-
Page 2: Table Of Contents
B. Avoiding Smoke and Odors ..........14 C. Negative Pressure .............15 D. Draft...................15 E. Chimney and Exhaust Connection ........15 F. Equivalent Feet of Pipe .............16 G. Pipe Selection Chart ............16 Quadra-Fire is a registered trademark of Hearth & Home Technologies. 7080-162B October 12, 2017... -
Page 3: Important Safety Information
- Tile - Glass - Slate Materials reported as passing ASTM E 136, Standard The Quadra-Fire Mt. Vernon E2 Pellet Appliance meets the U.S. ENVIRONMENTAL PROTECTION AGENCY Certified to comply Test Method for Behavior of Metals, in a Vertical Tube with 2020 particulate emission standards at 0.74 G/HR EPA CFR... -
Page 4: Getting Started
MT VERNON E2-C Install Guide Getting Started A. Design, Installation & Location Considerations Since pellet exhaust can contain ash, soot or sparks, you must consider the location of: 1. Appliance Location • Windows NOTICE: Check building codes prior to installation. -
Page 5: Tools And Supplies Needed
MT VERNON E2-C B. Tools And Supplies Needed C. Inspect Appliance and Components • Open the appliance and remove all the parts and articles Tools and building supplies normally required packed inside the Component Pack. Inspect all the parts for installation, unless installing into an existing and glass for shipping damage. -
Page 6: Install Checklist
MT VERNON E2-C D. Install Checklist ATTENTION INSTALLER: Follow this Standard Work Checklist This standard work checklist is to be used by the installer in conjunction with, not instead of, the instructions contained in this installation manual. __________________________________________________________________________ Customer: ______________________________________________________________________... -
Page 7: Dimensions And Clearances
MT VERNON E2-C Dimensions and Clearances A. Appliance Dimensions 5-13/16 in 14-1/16 in 3-13/16 in (147mm) (357mm) (97mm) 3-5/8 in 3-5/8 in 10-3/8 in 10-3/8 in (93mm) (93mm) (264mm) (264mm) 2-9/16 in (65mm) Figure 7.1 - Top View Figure 7.3 - Top View with Top Vent Adapter (TPVNT-3) and Offset Adapter (812-3570). - Page 8 MT VERNON E2-C 28-3/4 in (730mm) 26-7/8 in (683mm) 10-3/8 in 10-3/8 in (264mm) (264mm) 5 in 5 in 8-1/4 in 8-1/4 in (128mm) (128mm) 3-3/4 in 3-3/4 in (208mm) (208mm) (97mm) (97mm) 19-9/16 in (497mm) 20 in (508mm) Figure 8.1 - Top View with Top Vent Adapter Figure 8.3 -Side View...
- Page 9 MT VERNON E2-C 31-1/16 in (788mm) 27-1/8 in 27-1/8 in (688mm) (688mm) 29-3/16 in 25-3/8 in 25-3/8 in (741mm) (646mm) (646mm) Figure 9.1 - Side View with Top Vent Adapter Figure 9.3 - Side View with Top Vent Adapter (TPVNT-3) and Offset Adapter (812-3570).
-
Page 10: Clearances To Combustibles (Us & Canada)
MT VERNON E2-C B. Clearances to Combustibles (US & Canada) NOTE: • Illustrations reflect typical installations and are FOR DESIGN PURPOSES ONLY. • Illustrations/diagrams are not drawn to scale. • Actual installation may vary due to individual design preference. Horizontal Through the Wall... -
Page 11: Hearth Pad Requirements (Ul & Ulc)
MT VERNON E2-C USA INSTALLATIONS: A non-combustible floor protec- C. Hearth Pad Requirements (UL & ULC) tion is recommended extending beneath the flue pipe when EMBER PROTECTION: It is necessary to install a Type I installed with horizontal venting or under the Top Vent floor protector. -
Page 12: Alcove
MT VERNON E2-C D. Alcove Figure 12.1 Minimum* Maximum Inches Millimeters Inches Millimeters Height 1092 Width 1016 Depth To Side Wall *All minimums listed are to a combustible surface. NOTE: • Illustrations reflect typical installations and are FOR DESIGN PURPOSES ONLY. -
Page 13: Vent Information
MT VERNON E2-C Vent Information A. Venting Termination Minimum Requirements Electrical Service Inside Corner FIXED FIXED OPEN CLOSED CLOSED OPEN J or K Termination Cap Restricted Area Air Supply Inlet Gas Meter Figure 13.1 All minimum clearances are listed with an Outside Air Kit (OAK) installed, unless otherwise noted in table below. -
Page 14: Avoiding Smoke And Odors
MT VERNON E2-C B. Avoiding Smoke and Odors Vent Configurations Negative Pressure, Shut-Down and Electrical Power When installing a pellet appliance with a horizontal vent con- Failure figuration the frequency of power outages should be consid- ered: To reduce the probability of back-drafting or burn-back in the pellet appliance during power failure or shut down con- •... -
Page 15: Negative Pressure
Imbalances of the HVAC air handling system to 6 inch (76-152mm) Top Vent Offset Adapter, use Listed • Upper level air leaks such as: double wall flue connector. A Quadra-Fire Outside Air Kit - Recessed lighting (OAK-3) must be used with manufactured home installa- tions. -
Page 16: Equivalent Feet Of Pipe
MT VERNON E2-C F. Equivalent Feet of Pipe WARNING The table below can help you calculate the equivalent feet Vent surfaces get HOT, can cause burns if of pipe which is a method used to determine pellet vent size. touched. Non-combustible shielding or guards Figure 16.1. -
Page 17: Venting Systems
(152mm) from the wall. Approved for mobile home installa- conform to CAN/CSA-B365 tions. Must use 3 or 4 inch (76-102mm) “L” or “PL” Listed pellet venting or Listed double wall pipe and a Quadra-Fire Outside Air Kit in mobile homes. Straight Out... -
Page 18: Vertical Into Existing Class A Chimney
Must use 3 or 4 inch (76 to 102mm) “L” or “PL” Listed Rain Cap pellet venting or Listed double wall pipe and Quadra-Fire Outside Air Kit in mobile homes. Single wall pipe is approved for residential installations only. -
Page 19: Masonry
MT VERNON E2-C E. Masonry Fireclay Flue Liner Concrete Cap with airspace Flashing 1 in [25mm] clearance 1 in [25mm] clearnance with firestop 3 in [76mm] min to 6 in combustible material [152mm] Sheathing Clean-out cover Airtight clean-out door Non-combustible Hearth Pad Figure 19.1... -
Page 20: Appliance Set-Up
MT VERNON E2-C Appliance Set-Up A. Leg Leveling System B. Outside Air Kit Instructions 1. Thread Allen bolts through nuts until flush. Figure 20.1. The Allen bolts and nuts are included in the component pack CAUTION inside the appliance firebox. -
Page 21: Top Vent Adapter Installation
MT VERNON E2-C C. Top Vent Adapter Installation 3 to 3 inch (76-76mm) Top Vent Adapter 3 to 6 inch (76-152mm) Top Vent Offset Adapter Installing the Top Vent Adapter Put a layer of high temperature silicone on the 3 inch (76mm) exhaust outlet. -
Page 22: Optional Log Set Placement Instructions
MT VERNON E2-C E. Optional Log Set Placement Instructions 2 PIECE LOG SET INSTALLATION 1. Place the left log as shown. There are 2 indentations in the bottom of the log to fit over the screw heads in the firebox. Figures 22.1 and 22.2. -
Page 23: Programmable Wall Thermostat Installation
MT VERNON E2-C F. Programmable Wall Thermostat Installation Programming Thermostat The appliance comes standard with a wall thermostat and 25’ of wire. If you need to run more than 25’ make sure you use The thermostat maintains a desired room temperature. The a continuous strand of 18 to 22 gauge thermostat wire. - Page 24 MT VERNON E2-C Battery Installation and Replacement Program Schedule Pre-set settings are shown below. You can program 4 time periods each day, with different NOTE: 2 AA batteries are included with the thermostat settings for weekdays and weekends. and must be installed before the appliance can be op- erated.
-
Page 25: Power Cord
MT VERNON E2-C H. Trim Adjustment G. Power Cord 1. Prior to installing the power cord, turn the dial control “OFF”. 2. Make sure the wall receptacle has 120vac output. NOTE: Using a circuit protector can protect the appliance circuits from power surges. -
Page 26: Mobile Home Installation
MT VERNON E2-C Mobile Home Installation CAUTION You must use a Quadra-Fire Outside Air Kit for installation in a mobile home. THE STRUCTURAL INTEGRITY OF THE MOBILE HOME FLOOR, WALL AND CEILING/ROOF MUST BE An outside air inlet must be provided for the combustion... -
Page 27: Accessory List
Sienna Bronze SRV7080-061 Cleanout Tool 414-1140 MT VERNON E2-C Leveling Assembly 7000-000 Matte Black 812-0910 Accessory List Porcelain Black 1-00-0022 1-00-0020 Porcelain Dark Blue Paint Touch-Up Porcelain Frost 1-00-0021 MTV-E2-C Service Parts 855-1450 Porcelain Mahogany Beginning Manufacturing Date: July 2017... - Page 28 Hearth & Home Technologies 352 Mountain House Road Halifax, PA 17032 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafire.com CAUTION DO NOT DISCARD THIS MANUAL...
