INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
MT. VERNON PELLET STOVE E2
Model(s):
MTV-E2-CSB
MTV-E2-MBK
MTV-E2-PFT
MTV-E2-PDB
MTV-E2-PBK
MTV-E2-PMH
Please read this entire manual before installation and use of this
pellet fuel-burning room heater. Failure to follow these instructions
could result in property damage, bodily injury or even death.
CAUTION
Tested and approved for wood pellets only
CAUTION
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and na-
tional codes and regulations.
• Consult local building, fire officials or authorities having juris-
diction about restrictions, installation inspection, and permits.
1
Installation Manual
Installation & Appliance Set-Up
NOTICE: DO NOT DISCARD THIS MANUAL
Tested and
O-T L
Portland
Oregon USA
Listed by
C
US
OMNI-Test Laboratories, Inc.
061-S-83-2
If the information in these instruc-
tions is not followed exactly, a
fire could result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfire - If heater or chimney con-
nector glows, you are overfiring. Overfiring
will void your warranty.
• Comply with all minimum clearances to
combustibles as specified. Failure to
comply may cause house fire.
Hot glass will cause burns.
•
Do not touch glass until it is cooled
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
fireplace.
•
Alert children and adults to hazards of high temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other flammable
materials away.
To obtain a French translation of this manual, please contact
your dealer or visit www.quadrafire.com
Pour obtenir une traduction française de ce manuel, s'il vous
plaît contacter votre revendeur ou visitez www.quadrafire.com
7080-131B
WARNING
WARNING
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
NOTE
March 14, 2014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Quadra-Fire MTV-E2-CSB
Summary of Contents for Quadra-Fire MTV-E2-CSB
- Page 1 NOTICE: DO NOT DISCARD THIS MANUAL WARNING If the information in these instruc- MT. VERNON PELLET STOVE E2 tions is not followed exactly, a fire could result causing property Model(s): damage, personal injury, or death. MTV-E2-CSB • Do not store or use gasoline or other flam- MTV-E2-MBK mable vapors and liquids in the vicinity of this or any other appliance. MTV-E2-PFT • Do not overfire - If heater or chimney con- MTV-E2-PDB nector glows, you are overfiring. Overfiring...
-
Page 2: Table Of Contents
Vent Information ....... 10 A. Venting Termination Minimum Requirements ....10 B. Avoiding Smoke and Odors ..........11 .............12 C. Negative Pressure D. Draft .................12 E. Chimney and Exhaust Connection ........12 F. Equivalent Feet of Pipe ............13 G. Pipe Selection Chart ............13 Quadra-Fire is a registered trademark of Hearth & Home Technologies. 7080-131B March 14, 2014... -
Page 3: Important Safety Information
Materials reported as passing ASTM E 136, Standard cause undesired operation. Test Method for Behavior of Metals, in a Vertical Tube The Quadra-Fire Mt. Vernon E2 Pellet Stove meets the U.S. Envi- Furnace of 750° C. ronmental Protection Agency’s 1990 particulate emission standards. G. Combustible Materials NOTICE: This installation must conform with local codes. In... -
Page 4: Getting Started
MT VERNON E2 Install Guide Getting Started A. Design, Installation & Location Considerations Since pellet exhaust can contain ash, soot or sparks, you must consider the location of: 1. Appliance Location • Windows NOTICE: Check building codes prior to installation. • Air Intakes • Installation MUST comply with local, regional, state and • Air Conditioner national codes and regulations. • Overhang, soffits, porch roofs, adjacent walls • Consult insurance carrier, local building inspector, fire • Landscaping, vegetation... -
Page 5: Remote Thermostat Location
MT VERNON E2 B. Remote Thermostat Location D. Inspect Appliance and Components The remote thermostat’s location will have some affect on the • Open the appliance and remove all the parts and articles appliance’s operation. packed inside the Component Pack. Inspect all the parts and glass for shipping damage. • When located close to the appliance, it may require a slightly higher temperature setting to keep the rest of the • Report to your dealer any parts damaged in shipment. -
Page 6: Install Checklist
Follow this Standard Work Checklist This standard work checklist is to be used by the installer in conjunction with, not instead of, the instructions contained in this installation manual. Customer: Date Installed: Lot/Address: Location of Fireplace: Installer: Dealer/ Distributor Phone #: Serial #: Model (circle one): MTV-E2-MBK MTV-E2-CSB MTV-E2-PFT MTV-E2-PDB MTV-E2-PBK MTV-E2-PMH WARNING! Risk of Fire or Explosion! Failure to install fireplace according to these instructions can lead to a fire or explosion. Appliance Install IF NO, WHY? Required non-combustible floor protection (Pg. 9) Verified clearance to combustible (Pg. 8) Unit is leveled and secured (Pg. 18) Venting/Chimney Section 4 (Pg. -
Page 7: Dimensions And Clearances
MT VERNON E2 Dimensions and Clearances A. Appliance Dimensions 5-13/16 14-1/16 3-13/16 [147] [357] [97] 2-9/16 [65] 31-1/16 [788] 29-3/16 [741] Figure 7.1 - Top View with Top Vent Adapter Figure 7.2 - Side View with Top Vent Adapter and 3 to 6 and 3 to 6 in (76-152mm) Adapter in (76-152mm) Offset Adapter. -
Page 8: Clearances To Combustibles (Us & Canada)
MT VERNON E2 B. Clearances to Combustibles (US & Canada) C. Hearth Pad Requirements (US & Canada) Use a non-combustible floor protector, extending beneath appliance and to the front, sides and rear as indicated. Mea- sure front distance “M” from the surface of the glass door. Straight Back Against Wall Inches Millimeters... -
Page 9: Alcove
MT VERNON E2 D. Alcove Figure 9.1 Minimum* Maximum Inches Millimeters Inches Millimeters Height 1092 Width 1016 Depth To Side Wall *All minimums listed are to a combustible surface. NOTE: • Illustrations reflect typical installations and are FOR DESIGN PURPOSES ONLY. • Illustrations/diagrams are not drawn to scale. • Actual installation may vary due to individual design preference. March 14, 2014 7080-131B... -
Page 10: Vent Information
MT VERNON E2 Vent Information A. Venting Termination Minimum Requirements Electrical Service Inside Corner FIXED FIXED OPEN CLOSED CLOSED OPEN J or K Figure 10.1 Termination Cap Restricted Area Air Supply Inlet Gas Meter All minimum clearances are listed with an Outside Air Kit (OAK) installed, unless otherwise noted in table below. 12 in. -
Page 11: Avoiding Smoke And Odors
MT VERNON E2 B. Avoiding Smoke and Odors Vent Configurations To reduce probability of reverse drafting during shut-down Negative Pressure, Shut-Down and Electrical Power conditions Hearth & Home Technologies strongly recom- Failure mends: To reduce the probability of back-drafting or burn-back in • I nstalling the pellet vent with a minimum vertical run of the pellet appliance during power failure or shut down con- 5 feet (1.52m). Preferably terminating above the roof... -
Page 12: Negative Pressure
1. Chimney & Connector: Use 3 or 4 inch (76-102mm) able for the appliance to operate properly. It can be strongest diameter type “L” or “PL” venting system. It can be vented in lower levels of the house. vertically or horizontally. Causes include: 2. Mobile Home: Approved for all Listed pellet vent. If using • Exhaust fans (kitchen, bath, etc.) the 3 inch (76mm) vertical Top Vent Adapter Kit or the 3 • Range hoods to 6 inch (76-152mm) Top Vent Offset Adapter, use Listed double wall flue connector. A Quadra-Fire Outside Air Kit • Combustion air requirements for furnaces, water heaters (OAK-3) must be used with manufactured home installa- and other combustion appliances tions. • Clothes dryers 3. Residential: The 3 inch (76mm) vertical Top Vent Adapter • Location of return-air vents to furnace or air conditioning Kit and the 3 to 6 inch (76-152mm) Top Vent Offset Adapter are tested to use 24 gauge single wall flue connector or • Imbalances of the HVAC air handling system Listed double wall flue connector to Class A Listed metal • Upper level air leaks such as:... -
Page 13: Equivalent Feet Of Pipe
MT VERNON E2 F. Equivalent Feet of Pipe WARNING The table below can help you calculate the equivalent feet Vent surfaces get HOT, can cause burns if of pipe which is a method used to determine pellet vent size. touched. Non-combustible shielding or guards Figure 13.1. may be required. Example of 3 Elbow-Rear Vent Termination Calculation Pellet Venting # of Feet of Multiplied Equivalent Components Component Elbows Pipe Feet Equivalent Feet 2 ft. Elbow or Tee Elbow Horizontal Pipe... -
Page 14: Venting Systems
MT VERNON E2 Venting Systems A. Through The Wall Horizontal termination cap must be a minimum of 6 inches. NOTE: In Canada, where passage through a wall or partition (152mm) from the wall. Approved for mobile home installa- tions. Must use 3 or 4 inch (76-102mm) “L” or “PL” Listed of combustible construction is desired, the installation pellet venting or Listed double wall pipe and a Quadra-Fire shall conform to CAN/CSA-B365 Outside Air Kit in mobile homes. 2 in [51mm] min Horizontal Straight Out Termination Wall Thimble 6 in [152mm] 6 in... -
Page 15: Vertical Into Existing Class A Chimney
We recommend a minimum of 60 inches (1524mm) vertical, however above the eave is preferred. Rain Cap All three installations are approved for mobile home installations. Must use 3 or 4 inch (76 to 102mm) “L” or “PL” Listed pellet venting or Listed double wall pipe and Quadra-Fire Outside Flashing Air Kit in mobile homes. Single wall pipe is 12 in. [305mm] Min approved for residential installations only. *NOTE: Clearance to combustibles are for Firestop standard pellet pipe. -
Page 16: Masonry
MT VERNON E2 E. Masonry Fireclay Flue Liner Concrete Cap with airspace Flashing 1 in [25mm] clearance 1 in [25mm] clearnance with firestop 3 in [76mm] min to 6 in combustible material [152mm] Sheathing Clean-out cover Airtight clean-out door Non-combustible Hearth Pad Figure 16.1 F. -
Page 17: Appliance Set-Up
MT VERNON E2 Appliance Set-Up A. Leg Leveling System B. Outside Air Kit Instructions 1. Thread Allen bolts through nuts until flush. Figure 17.1. The Allen bolts and nuts are included in the component pack CAUTION inside the appliance firebox. Never draw outside combustion air from: 2. Slide assembled nuts and bolts into slots on legs with the • Wall, floor or ceiling cavity nuts on the bottom. Figure 17.2. Use a 5/32 in. (3.96mm) • Enclosed space such as an attic or garage Allen wrench to adjust legs up and down to desired level. Figure 17.3. Included in Kit: 2 wire ties, 1 collar assembly, 1 termination cap assembly, 1 trim ring, fasteners. NOTE: 3 INCH ALUMINUM FLEX PIPE NOT INCLUDED. Tools Needed: Phillips head screw driver; wire cutters hole saw or jig saw. -
Page 18: Top Vent Adapter Installation
MT VERNON E2 C. Top Vent Adapter Installation 3 to 3 inch (76-76mm) Top Vent Adapter 3 to 6 inch (76-152mm) Top Vent Offset Adapter Installing the Top Vent Adapter Put a layer of high temperature silicone on the 3 inch (76mm) exhaust outlet. -
Page 19: Optional Log Set Placement Instructions
MT VERNON E2 E. Optional Log Set Placement Instructions 2 PIECE LOG SET INSTALLATION 1. Place the left log as shown. There are 2 indentations in the bottom of the log to fit over the screw heads in the firebox. Figures 19.1 and 19.2. 2. -
Page 20: Remote Thermostat Installation
MT VERNON E2 F. Remote Thermostat Installation G. Power Cord 1. When mounting the thermostat on the wall, be sure to 1. Prior to installing the power cord, turn the dial control follow your remote thermostat’s installation instructions “OFF”. carefully. 2. Make sure the wall receptacle has 120vac output. NOTE: Using a circuit protector can protect the appli- NOTE: The remote thermostat should be mounted ance circuits from power surges. on an inside wall and not in direct line with the ap- 3. -
Page 21: Mobile Home Installation
MT VERNON E2 Mobile Home Installation CAUTION You must use a Quadra-Fire Outside Air Kit for installation in a mobile home. THE STRUCTURAL INTEGRITY OF THE MOBILE HOME FLOOR, WALL AND CEILING/ROOF MUST BE An outside air inlet must be provided for the combustion MAINTAINED air and must remain clear of leaves, debris, ice and/or Do NOT cut through: snow. It must be unrestricted while the appliance is in • Floor joist, wall, studs or ceiling trusses. use to prevent room air starvation which causes smoke spillage. Smoke spillage can also set off smoke alarms. -
Page 22: Accessory List
Sienna Bronze TOUCHUP-CSB Power Cord 812-1180 MT VERNON E2 SRV7000-647 Heating Element Assembly 18”, 120 VAC, 300 Watt, (Wood Pellet Fuel Only) Pkg of 10 SRV7000-647/10 Accessory List Wing Thumb Screw 8-32 X 1/2 Pkg of 24 7000-223/24 Wire Clip Pkg of 10 7000-400/10 ACCESSORIES Collar, Offset, Top Vent 812-3570 Damper, 3 Inch - Tall Vertical Installs Only PEL-DAMP3 Damper, 4 Inch - Tall Vertical Installs Only PEL-DAMP4 Firescreen SCR-7005 Log Set, (Sold as Set only) 2 Pc LOGS-60-AE-B Outside Air Kit OAK-3 Top Vent Adapter TPVNT-3 Vent Adapter, 3-4”... - Page 23 MT VERNON E2 March 14, 2014 7080-131B...
- Page 24 CONTACT INFORMATION Hearth & Home Technologies 1445 North Highway Colville, WA 99114 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafire.com CAUTION DO NOT DISCARD THIS MANUAL Read, understand and Leave this manual with • •...
