- Page 1 OWNER'S MANUAL High Definition Network Camera Please read this manual carefully before operating your set and retain it for future reference. MODEL LNB5100 series LNB3100 series LNV5100 series LND5100 series LND3100 series 1210 (V1.1)
-
Page 2: Table Of Contents
Accessing the LG IP device..............5 Reset setting .................41 LG Smart Web Viewer Overview ............6 Configuration menu overview ..........8 Reference ..................42 Configuring the LG Network Camera Device ......8 Troubleshooting .................42 Accessing the Configuration menu .........8 Open source software notice ............45 System settings ...............9 Specifications..................46... -
Page 3: Introduction
Introduction The LG Network Camera is designed to use on an Ethernet network and must be assigned an IP address to make it accessible. This manual contains instructions on how to install and manage the LG Network Camera in your networking environment. Some knowledge of networking environments would be beneficial to the reader. -
Page 4: Operation And Settings
Before using the system Recommended PC Requirements • Before using the LG IP device make sure the connections are The LG IP device can be used with most standard operating systems correct and verify whether proper power supply is used. and browsers. •... -
Page 5: Accessing The Lg Ip Device
The IP Utility shows the MAC address, IP address, Model 3.1 Start your Web browser. name and so on. 3.2 Enter the IP address of the LG IP device in the address Note: bar of the browse. The computer running the IP Utility must be on the same 3.3 Enter the user name and password set by the... -
Page 6: Lg Smart Web Viewer Overview
LG Smart Web Viewer Overview Click to display the check box of [Hostname],[Time](It displays time of Client PC),[Framerate] and [Bitrate] options. Text overlay is displayed on left top of the live view window in order of selecting options. Click to save the current image in JPEG format on your computer. - Page 7 Live view drop-down list. Displays the current surveillance live screen. You can monitor the camera image on the live view window of the LG Smart Web Viewer. Click this button and drag the area to use PTZ function. Right-clicking the screen will bring up the previous magnification.
-
Page 8: Configuration Menu Overview
Sub Menu Configuring the LG Network Camera Version Device Date & Time The features and options of the LG IP camera are configured System Maintenance through the Configuration menu. Log & Report Only administrator-level users have permission to access the Language Configuration menu. -
Page 9: System Settings
System settings Time zone Set the time difference from GMT in the area where the IP device is installed. Select the time zone in the area where the IP device is Version installed from the drop down list. Displays the current version of Firmware, Hardware, Software and Time mode Web Client. - Page 10 Maintenance Notes: • Backup and Restore can happen on IP device having the same version of firmware. This feature is not intended for multi-configurations or for firmware upgrades. • [Backup] function is allowed in HTTP protocol but not in HTTPS protocol. Firmware >...
- Page 11 Language list The System log provides a summary of the status of the IP device. Select a language for the LG Smart Web Viewer configuration menu The unit records the data of the software activity in a file. and information display.
-
Page 12: Audio & Video Settings
Audio & Video settings Notes: • It is recommended to select Sensor Framerate value to 30 in 60 Hz region, 25 in 50 Hz region to reduce flicker. Camera • Maximum FPS is set 25 when you select Sensor Framerate value 25. •... - Page 13 > Maximum frame rate: Set the frame rate of the image. Region Of Interest > GOP size: It means “Group of Pictures”. The higher the GOP, the better is the video quality of the camera. Edit the value of GOP from 1 to 30. This setting is valid for H.264 video format only.
- Page 14 Note: Motion detect ROI area can not overlap with each other. Audio (Optional) Audio In Preview > Enable: Click the check box if you want to send the audio You can preview the motion detection window on the preview from the microphone input connector. window.
- Page 15 Smart Analytics (Optional) How to set the motion detect window 1. Click the [Add] button. The motion detect window is • Preview: You can preview the camera image on the preview displayed. You can add the five windows maximum for window.
- Page 16 Note: 3. To complete the zone, move the mouse cursor from the selected points and click the mouse right button. • Double click the preview screen to maximize full screen. Notes: • To return to previous screen to double click full screen. •...
- Page 17 Notes: Streaming Metadata Send the VA Metadata where detected zone of the user’s setting for • When you select all of point, you can set up to 15 use from the Client. The camera do not conduct the VA detection. points and area is set automatically.
- Page 18 Notes: Trip Zone Detect the direction of object by dividing two of zone. • You can cancel the point by click the mouse right button near the other point. • If the path is intersected each other, area setting can not complete. 4.
- Page 19 • Width and Height of zone are displayed as percentage of Directionality: Select the movement direction of object. the screen automatically. • Basic Configuration • Save: Click this button to confirm the settings. > Sensitivity: Select the sensitivity from drop-down list to detect an object in motion.
-
Page 20: Network Settings
Network settings RTP stream RTP (Real-time Transport Protocol) is an internet protocol that allows programs to manage the real-time transmission of multimedia data, Basic via unicast or multicast. General Profile > MAC address: Displays the MAC address. > RTP unicast: When enabled the transmission of the data to Port &... - Page 21 Note: TCP/IP Each profile using multicast needs its own multicast IP address and port numbers to avoid address conflict. When more than 2 profiles use same multicast IP address, each [Base RTP port] number should be distinguished from the other port number more than 6 at least. >...
- Page 22 IPv4 address: Enter an IP address. Subnet mask: Enter a subnet mask address. This free service is very useful when combined with the LG DDNS Server. It allows the user to connect the IP device using the URL, Gateway: Enter the gateway address.
- Page 23 IP filtering Deny all: Deny all the IP address basically, but the IP addresses in the list are allowed. It needs at least one IP The access of the IP addresses in the list are allowed or denied address to activate this function. according to the choice made in the drop-down list of the Basic policy option.
-
Page 24: User Settings
User settings • Remove: Click this button to delete the IPv6 address. 1. Select the alias from the list. Basic 2. Click the [Remove] button. The IPv6 address will be deleted. The IP device is shipped with the login rights of administrator only. SNMP If others need to access the IP device excluding the configuration a login with viewer rights need to be created. - Page 25 4. Select the authority from the drop down list to provide Anonymous the access rights to each user and then click the [Save] to > Enable anonymous login confirm your selection. Check the box to enable anonymous user login allows the Administrator: Allows you to operate setup menus user access for only viewing the live stream image.
-
Page 26: Sd Card Settings
SD Card settings > Overwrite: If the micro SD card has insufficient space and this option will be activated. It will overwrite the oldest data. > DiskFull Notification: Sends an warning e-mail to the SMTP Basic server when the micro SD card has fully recorded. Select the SMTP server from the drop-down list. - Page 27 SD card has insufficient space. 2. Remove the micro SD card from the micro SD card slot of the camera. • The downloaded file can be played by using the LG File player. Note: > Remove: Delete file from the SD card.
-
Page 28: Event Settings
Event settings Move camera to(Optional): Go to the saved preset position when event runs. • Stream: Selects the stream of the connected camera. Event schedule • Programmable Alarm(Optional): When the sensor When an event (VA/ Motion detect/ Sensor Event) occurs, this unit event is activated, the camera will start the recording records the live images and routes as configured. - Page 29 Event Server Password: Type the password for the folder shared in the FTP Server. Event Servers are used to receive the recorded video clip and/or notification messages. Folder: Type the path with the folder that is shared in the FTP server. Test: Select [Test] to test the FTP server.
- Page 30 Sensor & Relay (Optional) Enable SSL: Check when use the SSL (Secure Socket Layer) protocol. SSL protocol is cryptographic protocols that provide secure communication on a network. Receiving address: Type the recipients e-mail address. You can specify only one recipient e-mail address. Administrator address: Type the e-mail address of the administrator.
-
Page 31: Osd Menu Setup
OSD Menu Setup 3D-DNR The following table shows the list of menu items and options. MIDDLE Main Sub Menu Contents Menu HIGH PRIVACY EXPOSURE ELC/ALC, WDR/BLC OFF/WDR/BLC/HSBLC ALC2 BRIGHTNESS 0 to 100 COLOR 0 to 255 OFF/LOW/MIDDLE/HIGH GREEN 0 to 255 (LND3100 SHUTTER ELC/ALC: x60,...,x2, OFF,... - Page 32 PRIVACY CIRCLE MASK AREA1 to SHARPNESS 0 to 68 NUMBER AREA2 COLOR OFF/ ON CIR. DISPLAY ON/OFF HEIGHT 1 to 15 WINDOW MOVE WIDTH 1 to 15 IMAGE MOVE MOVE Y 0 to 100 IMG SIZE MOVE X 0 to 100 EXIT RADIUS SIZE 0 to 100...
-
Page 33: General Operation
General Operation Notes: • button: Used to move upper direction on the menu screen. 1. Click the [OSD control] button on the LG Smart Web Viewer. • button: Used to move lower direction on the menu screen. 2. Click button on the OSD control window. - Page 34 WDR/BLC BRIGHTNESS Use WDR/BLC option to view the object clearly in backlight You can increase the brightness of the darkened video. If you set the conditions. brightness to lower value, the image gets darkened. If you set the brightness to higher value, the image gets bright. 1.
-
Page 35: White Balance Settings
SENS-UP White Balance settings If pictures are not clear due to darkness, this SENS-UP operation Select the method by which the camera shifts its output colors to would increase the sensitivity of picture. compensate for the color of a light source. 1. -
Page 36: Day/Night Settings
3D-DNR setting > RED: Set the desired red value. > BLUE: Set the desired blue value. Day/Night settings 1. Select [3D-DNR] option. If pictures are not clear due to noise, this option would reduce the noise of picture. 1. Select [DAY/NIGHT] option. 2. -
Page 37: Privacy Setting
Privacy setting MOVE Y: Moves vertical position of the mask. MOVE X: Moves horizontal position of the mask. This function is aiming at the protection of personal privacy. The • CIRCLE : selected part is not displayed on the screen. >... -
Page 38: Special Menu Settings
Special menu settings D-EFFECT (Digital effect) You can select the digital effect. 1. Select the [D-EFFECT] option on the [SPECIAL] menu. 2. Use button to select a digital effect. • V-FLIP: Flip the picture vertically. • MIRROR: Turn on the mirror effect. •... - Page 39 USER TITLE You can view an image in PIP(picture in picture) mode. You can use the camera identification to assign a number and character to the camera. 1. Select the [PIP] option on the [SPECIAL] menu. To disappear the user title, select [OFF]. 2.
-
Page 40: Scene Mode Setting (Optional)
SCENE mode setting Notes: (Optional) • Set each value of option as selected option on the [SCENE You can set value installed camera environment properly using this MODE] like as below table. function. Several configuration value is set automatically to select option. -
Page 41: Reset Setting
Reset setting OPTION INDOOR TRAFFIC USER Shutter speed AUTO Manual(1/120) MIDDLE HIGH White Balance Manual (Indoor) WDR/BLC 3D-DNR MIDDLE MIDDLE DAY/NIGHT AUTO AUTO SHARPNESS 1. Select the [RESET] option. BRIGHTNESS 2. Click button and the RESET menu appears. SENS-UP 3. Use button to select option. -
Page 42: Reference
• IP Conflicts: If the LG network device is set with a static IP address and if the DHCP option is set then there may be IP’s same as the network device and other network partner. Hence set the static IP address to 0.0.0.0 to resolve this conflict. - Page 43 After the factory settings login using the default user name and password. Video Streaming problems • If the video streaming does not start on the Web browser, install the LG Web Client ActiveX program on your computer following the instructions on the Web browser. •...
- Page 44 • If we obtain lower frame rate than set we need to check from the system administrator for sufficient bandwidth available or reduce the number of applications running on the client computer. • If the client PC’s are unable to access the multicast stream, check with the system administrator for the use of a valid multicast address or check if the router is supporting multicasting.
-
Page 45: Open Source Software Notice
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com. -
Page 46: Specifications
Specifications Item LNB5100 LND5100 LNV5100 Image Device 6 mm (1/3 type) Progressive Scan CMOS (1.3 Mega Pixels) Lens Type DC-Iris, CS Mountable F1.2 Varifocal Lens (2.8 mm to 10 mm) (Optimization of 6 mm (1/3 type) Lens of 1.3 Mega Pixels or above) Day/Night Minimum Color... - Page 47 IPv4 and IPv6 TCP/IP, UDP, HTTP, HTTPS, RTP, RTSP, DHCP, ICMP Protocol IPv4 FTP, SMTP, NTP, ARP, SNMP v1/v2c/v3, DDNS(LG) Operation Temperature/Humidity -10 ºC to 50 ºC / 0 % RH to 80 % RH Power Source PoE (IEEE 802.3af ), DC 12 V (±20 %) Power Consumption 5.9 W...
- Page 48 Item LNB3100 LND3100 Image Device 6 mm (1/3 type) Progressive Scan CMOS (1.3 Mega Pixels) Lens Type DC-Iris, CS Mountable (Optimization of 6 F2.0 Fixed Lens (3 mm) mm (1/3 type) Lens of 1.3 Mega Pixels or above) Day/Night Digital Minimum Illumination 0.3 lx (F1.2, Gain : High) 0.7 lx (F2.0, Gain : High)
- Page 49 IPv4 and IPv6 TCP/IP, UDP, HTTP, HTTPS, RTP, RTSP, DHCP, ICMP Protocol IPv4 FTP, SMTP, NTP, ARP, SNMP v1/v2c/v3, DDNS(LG) Operation Temperature/Humidity -10 ºC to 50 ºC / 0 % RH to 80 % RH Power Source PoE (IEEE 802.3af ), DC 12 V (±20 %) Power Consumption 5.9 W...
