Basic Tools Detail:
Table 2(Installer Setup):
Item
1. ID Code
2. Unlock Timing
3. Unlock Output
4. Monitor Timing
5. Doorplate Mode
6. Waiting Timing
7. Talking Timing
8. Installer Code ...
9. Default ...
* Note that you can use another way(#+8001+66666666) to enter the Installer Setup
mode.
Description
1. When there is only one door station and no C5-IPC,
set to 0. And set the type of distributor used with it.
When C5-IPC is connected, must not be set to 0.
2. When C5-MDS is connected, be set to from 1~8
according to which port it is connected on the C5-MDS
3. When used as common door station, set to 9
To set the time that how long the door keeps open
when door is released. Range from 01 to 99 seconds.
To set the unlock mode to match the corresponding
lock.Range from 0 to 1.
0:Power-on-to-Unlock Mode(Normally Open Mode)
1:Power-off-to-Unlock Mode(Normally Closed Mode)
To show the monitor time,Range from 6s to 600s
To set the calling mode.If set to 0,it's the auto
mode,that means the calling will be activated directly
after inputting 4 digits code.If set to 1,it's the manual
mode,that means you should press "#" button to acti-
vate the calling after inputting the code.
To show the calling wait time,Range from 6s to 600s
To show the limitation time of talking,Range from 6s to
600s
To change door station administrator code
Note this operation is irreversible. Once restore is
activated, all parameters will return to factory default
setting except the information of access card.
Factory
set
[0]
Single
[01]
1 seconds
0
600s
[0]
Auto mode
40s
90s
[66666666]
-7-
