GV-IPCam H.264
Box Camera
Ultra Box Camera
Arctic Box Camera
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
Hardware Manual
ICH264TIV301

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-IPCAM H.264 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision GV-IPCAM H.264

Summary of Contents for GeoVision GV-IPCAM H.264

  • Page 1 GV-IPCam H.264 Hardware Manual Box Camera Ultra Box Camera Arctic Box Camera Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. ICH264TIV301...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Table Of Contents

    Contents Contents ................i   Options ................iv   Note for Installing Camera Outdoor....... vi   Note for USB Storage and WiFi Adapter ...... vii   Chapter 1 Box Camera .............1     1.1 Packing List ................5   1.2 Features ...................6  ...
  • Page 4   1.6 I/O Terminal Block ..............19   1.6.1 Pin Assignment............19   1.6.2 Connecting to GV-Relay V2 (Optional).......20   1.7 Loading Factory Default............21 Chapter 2 IR Arctic Box Camera ........22     2.1 Packing List ................24   2.2 Features .................26   2.3 Overview ................28 2.3.1 GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E /  ...
  • Page 5   3.2 Features .................47   3.3 Overview .................48   3.4 Installation ................49   3.5 Connecting the Camera............51     Loading Factory Default ............52 Appendix................53       Supported Lenses for Box Camera..........53...

  • Page 6: Options

    Options Optional devices can expand your camera’s capabilities and versatility. Contact your dealer for more information. Device Description The power adapter is available for all Box Camera and Ultra Box Camera. The supported regions are listed below: • Power Adapter Box Camera (except GV-BX2500), GV-UBX Series: Australia, Europe, U.K, U.S.A •...
  • Page 7 Device Description The GV-WiFi Adapter is a plug-and-play device designed to connect GV-BX1200 Series / 1300 series / 1500 series / 2400 series / 2500 series / 3400 series / 5300 series and GV-MFD1501 series / GV-WiFi Adapter 2401 series / 2501 series / 3401 series / 5301 series to wireless network.

  • Page 8: Note For Installing Camera Outdoor

    Note for Installing Camera Outdoor When installing the IR Arctic Box Camera outdoor, be sure that: The camera is set up above the junction box to prevent water from entering the camera along the cables. Any PoE, power, audio and I/O cables are waterproofed using waterproof silicon rubber or the like.

  • Page 9: Note For Usb Storage And Wifi Adapter

    Note for USB Storage and WiFi Adapter Mind the following limitations and requirements for using USB storage and GV-WiFi Adapter: The USB hard drive must be of 2.5’’ or 3.5’’, version 2.0 or above. The USB hard drive’s storage capacity must not exceed 2TB. USB flash drives and USB hubs are not supported.

  • Page 10: Chapter 1 Box Camera

    Box Camera Chapter 1 Box Camera The Box Camera is a series of indoor IP cameras consisting of fixed focal and varifocal models in different resolutions. The Box Camera supports lens replacement and features an automatic infrared-cut filter for day and night surveillance.

  • Page 11: Specifications

    Model No. Specifications Description Auto Iris, f: 2.8 ~ 12 Varifocal 2 MP, H.264, GV-BX220D-3 mm, F/1.4, 1/3’’ CS Lens Lens Auto Iris, f:3.1 ~ 8 GV-BX320D-0 mm, F/1.2, 1/3” CS Lens 3 MP, H.264, Auto Iris, f: 2.8 ~ 6 Varifocal mm, F/1.3, 1/3’’...
  • Page 12 Box Camera Model No. Specifications Description 1.3 MP, H.264, GV-BX1200-2F Low Lux, D/N 1.3 MP, H.264, GV-BX1300-2F 1.3 MP, H.264, GV-BX1500-2F Super Low Fixed Iris, f: 12 mm, Lux, D/N Fixed Lens F/1.6, 1/2.5’’ CS 2 MP, H.264, Lens GV-BX2400-2F D/N, WDR Pro 2 MP, H.264, GV-BX2500-2F...
  • Page 13 Model No. Specifications Description 1.3 MP, H.264, GV-BX1500-8F Super Low Lux, D/N 2 MP, H.264, Fixed Iris, f: 2.8 mm, GV-BX2500-8F Super Low Fixed Lens F/1.8, 1/2.5’’ CS Lux, D/N Lens 3 MP, H.264, GV-BX3400-8F D/N, WDR Pro 5 MP, H.264, GV-BX5300-8F P-Iris Models (Coming) Model No.

  • Page 14: Packing List

    • Camera Holder • Holder Screw x 2 • Power Adapter • GV-IPCAM H.264 Software DVD • GV-IPCAM H.264 Quick Start Guide • GV-NVR Software DVD • GV-NVR Quick Start Guide Note: The power adapter can be excluded upon request.

  • Page 15: Features

    1.2 Features • Image sensor Camera Model Image Sensor GV-BX120D 1/3’’ progressive scan low lux CMOS GV-BX1200 Series GV-BX130D Series GV-BX1300 Series GV-BX220D Series 1/2.5’’ progressive scan CMOS GV-BX320D Series GV-BX520D GV-BX5300 Series GV-BX140DW 1/3’’ progressive scan CMOS GV-BX1500 Series 1/3’’...
  • Page 16 Box Camera  Dual streams from H.264 or MJPEG  Day / Night function (with removable IR-cut filter)  Wide Dynamic Range Pro (GV-BX140DW / 2400 Series / 2500 Series / 3400 Series only  P-Iris for auto iris adjustment (Coming, for GV-BX1500-3V / 2500-3V / 3400-3V / 5300-6V only) ...

  • Page 17: Wide Dynamic Range Pro

    An example of WDR Pro in action is shown below. No WDR: underexposure WDR: perfect exposure For GV-IPCam H.264 models that support WDR, the WDR effect is achieved through software programming.

  • Page 18: Overview

    Box Camera 1.3 Overview 1.3.1 GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D 12 13 Figure 1-1 Note: 1. The Auto Iris connector (No. 7) is only functional in GV-BX120D, GV-BX130D-0, GV-BX220D and GV-BX320D. 2.

  • Page 19: Led Description

    Name Description Audio Out Connects a speaker for audio output. Audio In Connects a microphone for audio input. I/O Terminal For details, see 1.6 I/O Terminal Block. Block Indicates the power is supplied. For detail, see Power LED the table below. Auto Iris Plug the iris control cable to the connector.

  • Page 20: Gv-Bx1200 Series / 1300 Series / 1500 Series / 2400

    Box Camera 1.3.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series Figure 1-2 Note: The Auto Iris Connector (No. 8) is only functional for varifocal models of GV-BX1200 / 1300 / 1500 / 2400 / 2500 / 3400. The Iris Screw (No.
  • Page 21 Name Description Audio Out Connects a speaker for audio output. Audio In Connects a microphone for audio input. I/O Terminal Connects to I/O devices. For details, see 1.6 Block I/O Terminal Block. Indicates the power is supplied. For detail, Power LED see the table below.

  • Page 22: Connecting The Camera

    Optionally connect a speaker and an external microphone. Optionally connect a monitor using a Video Out wire. Enable this function by selecting your signal format at the TV Out field on the Web interface. See 4.1.1 Video Settings, GV-IPCam H.264 Firmware Manual.
  • Page 23 Optionally connect to input / output devices or an infrared illuminator. For details, see 1.5.2 Infrared Illuminator and 1.6 I/O Terminal Block. Connect power using one of the following methods: • plugging the power adapter to the power port. • using the Power over Ethernet (PoE) function and the power will be provided over the network cable.

  • Page 24: Gv-Bx1200 Series / 1300 Series / 1500 Series / 2400

    Box Camera 1.4.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series Figure 1-4 If you are using an auto iris model, plug the iris control cable to the Auto Iris Connector on the camera.
  • Page 25 See 4.1.1 Video Settings, GV-IPCam H.264 Firmware Manual. Optionally connect to input / output devices or an infrared illuminator. For details, see 1.5.2 Infrared Illuminator and 1.6 I/O Terminal Block. Connect power using one of the following methods: •...

  • Page 26: Accessory Installation

    Box Camera 1.5 Accessory Installation 1.5.1 C-Mount Lenses If you use a C-mount lens, it requires a certain distance from the camera’s imaging chip to focus the lens. Mount the supplied C-mount lens adapter / lens ring to the camera, and then secure the lens onto the camera body. Three types of C-mount lens rings are provided for Box Camera: •...

  • Page 27: Infrared Illuminators (Optional)

    1.5.2 Infrared Illuminators (Optional) If you use an infrared (IR) illuminator with I/O function, follow the steps below to install it. Connect the infrared illuminator to the terminal block on the camera. See 1.6 The I/O Terminal Block. Access the Web interface of the camera. Select Video and Motion, select Video Settings, select Streaming 1 and set the IR Check Function setting to Trigger by Input.

  • Page 28: I/O Terminal Block

    The Box Camera support one digital input and one digital output of dry contact. Function Digital Input Digital Output Figure 1-6 For details on how to enable an installed I/O device, see 4.2 I/O Settings, GV-IPCam H.264 Firmware Manual.

  • Page 29: Connecting To Gv-Relay V2 (Optional)

    1.6.2 Connecting to GV-Relay V2 (Optional) The Box Camera can only drive a maximum load of 200mA 5V DC. To expand the maximum voltage load to 10A 250V AC, 10A 125V AC or 5A 100V DC, connect the camera to a GV-Relay V2 module (optional product). Refer to the figure and table below.

  • Page 30: Loading Factory Default

    Box Camera 1.7 Loading Factory Default Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the back panel of the camera. Default button Figure 1-8 Release the default button when the status LED blinks. This shall take about 8 seconds.

  • Page 31: Chapter 2 Ir Arctic Box Camera

    Chapter 2 IR Arctic Box Camera The IR Arctic Box Camera is a series of outdoor cameras designed for environments of extreme temperatures. The cameras adhere to IP67 and IK10 protection standards, and are equipped with IR LEDs and removable IR-cut filter for day and night surveillance.
  • Page 32 IR Arctic Box Camera Model No. Specifications Description P-Iris, f: 3.7 ~ 9 mm, 2 MP, H.264, GV-BX2510-E F/1.2, 1/2’’, ø 14 Super Low Lux, mm mount Motorized Varifocal Lens P-Iris, f: 4.5 ~ 9 mm, 5 MP, H.264 GV-BX5310-E F/1.2, 1/2’’, ø...

  • Page 33: Packing List

    • Silica Gel Bag x 2 • Adhesive Tape x 2 • GV-IPCAM H.264 Software DVD • GV-IPCAM H.264 Quick Start Guide • GV-NVR Software DVD • GV-NVR Quick Start Guide Note: Optionally purchase a GV-PA481 PoE Adapter for GV-BX1500-E...
  • Page 34 • Adhesive Tape • Power Adapter (DC 48V, 2.5A, 120 W max.) • GV-IPCAM H.264 Software DVD • GV-IPCAM H.264 Quick Start Guide • GV-NVR Software DVD • GV-NVR Quick Start Guide Note: Optionally purchase a GV-PA482 PoE Adapter for GV-BX2510-E...

  • Page 35: Features

    2.2 Features • Image sensor Camera Model Image Sensor GV-BX120D-E 1/3" progressive scan low lux CMOS GV-BX1500-E 1/3" progressive scan super low lux CMOS GV-BX220D-E GV-BX320D-E 1/3.2" progressive scan CMOS GV-BX520D-E GV-BX5300-E GV-BX2510-E 1/2.8” progressive scan super low lux CMOS GV-BX2400-E GV-BX3400-E 1/2.5”...
  • Page 36 IR Arctic Box Camera • P-Iris for auto iris adjustment (for GV-BX2510-E / 5310-E) • Vandal resistance (IK10 for metal casing) • Built-in heater and fan • Support for TV-out • Micro SD card slot (SD/SDHC) for local storage (for GV-BX2510-E / 5310-E) •...

  • Page 37: Overview

    2.3 Overview 2.3.1 GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400 -E / 3400-E / 5300-E Figure 2-1 Note: The Iris Screw (No. 7) is only available in GV-BX520D-E and GV- BX5300-E. Name Description Silica gel bag Desiccant that keeps the camera housing dry.

  • Page 38: Gv-Bx2510-E / 5310-E

    IR Arctic Box Camera 2.3.2 GV-BX2510-E / 5310-E Figure 2-2 Name Description Silica gel bag Desiccant that keeps the camera housing dry. Memory Card Inserts a micro SD card (SD/SDHC, version Slot 2.0, Class 10) to store recording data. Turns on when the camera is supplied with Power LED power.

  • Page 39: Installation

    2.4 Installation The IR Arctic Box Camera is designed for outdoor use. Follow the steps below to install your camera. Mark the installation site and drill four holes for screw anchors. Insert the supplied screw anchors. Secure the camera to the wall using the supplied washers and screws. Figure 2-3 Connect the camera with wires and cables.
  • Page 40 IR Arctic Box Camera Tilt Adjustment Figure 2-5 Pan Adjustment Figure 2-6 For GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E , adjust for image clarity based on the live view. A. Unscrew the cover with the supplied 4 mm torx wrench. Figure 2-7...
  • Page 41 C. Adjust the focus, zoom and iris screws. For a more precise focus, use GV-IP Device Utility. For details, see 2.2 Adjusting Image Clarity, GV-IPCam H.264 Firmware Manual. Figure 2-9 Note: Only GV-BX520D-E and GV-BX5300-E contain an iris screw.
  • Page 42 IR Arctic Box Camera D. Replace the silica gel bag. Paste the sticker to the silica gel bag. Press the sticker several times onto the camera cover to make sure it adheres properly. Figure 2-10 E. Follow steps 7B and 7A to plug the connector back and close the camera cover.
  • Page 43 B. Insert a memory card to the card slot. Memory card slot Figure 2-12 C. Replace the silica gel bag. Paste the sticker to the silica gel bag. Press the silica gel bag several times onto the camera cover to make sure it adheres properly.
  • Page 44 IR Arctic Box Camera IMPORTANT: The gel bag loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera, and conceal the silica gel bag in the camera within 2 minutes of exposing to open air.

  • Page 45: Connecting The Camera

    2.5 Connecting the Camera 2.5.1 GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E Figure 2-14 Wire Definition RJ-45 Black BNC TV out Green RCA Audio Out Pink RCA Audio In...
  • Page 46 Optionally connect a monitor using a Video Out wire. Enable this function by selecting your signal format at the TV Out field on the Web interface. See 4.1.1 Video Settings, GV-IPCam H.264 Firmware Manual. Connect the camera to a GV-PA481 PoE Adapter as illustrated to supply power and network access.

  • Page 47: Gv-Bx2510-E / 5310-E

    (brown), digital input (yellow), and GND. 2. Optionally connect a monitor using a Video Out wire. Enable this function by selecting your signal format at the TV Out field on the Web interface. See 4.1.1 Video Settings, GV-IPCam H.264 Firmware Manual.
  • Page 48 IR Arctic Box Camera 3. Supply the camera with power and network access using one of the following methods: • Use a GV-PA482 Power over Ethernet adapter to connect the camera to power and network as illustrated below. GV-PA482 PoE adapter is an optional accessory.
  • Page 49 Note: The camera also supports AC 24V and a separate power cord is required. 4. You are ready to access the live view.

  • Page 50: Notice For Using The Ir Arctic Box Camera

    IR Arctic Box Camera 2.6 Notice for Using the IR Arctic Box Camera For GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E , make sure that you: • enable IR LED function on the Web interface after loading the default settings.

  • Page 51: Enabling Ir Led After Loading Default

    2.6.1 Enabling IR LED after Loading Default Each GV-IR Arctic Box Camera is equipped with 4 IR LEDs to provide infrared illumination at night. The factory-loaded setting for the IR LED function is enabled . If you have restored the camera to default settings, please follow the steps below to enable the IR LED function.

  • Page 52: Disabling Status Led Under Low Light Conditions

    IR Arctic Box Camera 2.6.2 Disabling Status LED under Low Light Conditions If you have a green light spot on the live view, this is likely due to insufficient light at the installation site, which causes the status LED to reflect on the camera cover.

  • Page 53: Loading Factory Default

    BX5310-E . To restore default settings for other IR Arctic Box Camera, access the load default function from its Web interface. For details, see Tools, Administrator Mode, Chapter 4, GV-IPCam H.264 Firmware Manual. Keep the power and network cables (or PoE) connected to the camera.

  • Page 54: Chapter 3 Ultra Box Camera

    Ultra Box Camera Chapter 3 Ultra Box Camera The Ultra Box Camera is a series of light-weighted cameras designed for indoor usage. Equipped with IR-cut filter and built-in IR LEDs, the Ultra Box Camera provides excellent image quality. The camera supports PoE and can be installed intuitively.

  • Page 55: Packing List

    • Screw x 3 • Screw anchor x 3 • Power Adapter • GV-IPCAM H.264 Software DVD • GV-IPCAM H.264 Quick Start Guide • GV-NVR Software DVD • GV-NVR Quick Start Guide Note: The power adapter can be excluded upon request.

  • Page 56: Features

    Ultra Box Camera 3.2 Features  1/2.5’’ progressive scan CMOS  Dual streams from H.264 or MJPEG  Frame rate Camera Model Frame Rate GV-UBX1301 Series Up to 30 fps at 1280 x 1024 GV-UBX2301 Series Up to 30 fps at 1920 x 1080 GV-UBX3301 Series Up to 20 fps at 2048 x 1536 ...

  • Page 57: Overview

    3.3 Overview Figure 3-1 Name Description Audio Out Connects a speaker for audio output. Resets the camera to factory default. Default For details, see 3.6 Loading Factory Default. LAN / PoE Connects to a 10/100 Ethernet or PoE. Microphone Records sounds. Inserts a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10) to store...

  • Page 58: Installation

    Ultra Box Camera 3.4 Installation You can stand the Ultra Box Camera on a plain surface or install it to wall and ceiling. Follow the steps below to install, connect and adjust your Ultra Box Camera. To install the device on the wall/ceiling, put the supporting rack on the desired location and make marks for screw anchors.
  • Page 59 Connect the network and power cables to the camera. See 3.5 Connecting the Camera. Access the live view. See 2.1 Accessing the Live View, GV-IPCam H.264 Firmware Manual. Adjust the angle of the camera based on live view and fasten the indicated screw.

  • Page 60: Connecting The Camera

    Ultra Box Camera 3.5 Connecting the Camera Figure 3-5 Connect power using one of the following methods: • Plug the power adapter to the 5V terminal block. The power adapter is an optional device. For detail, see Options in the manual.

  • Page 61: Loading Factory Default

    3.6 Loading Factory Default Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the back panel of the camera. Default button Figure 3-6 Release the default button when the status LED blinks. This shall take about 8 seconds.

  • Page 62: Appendix

    Ultra Box Camera Appendix A. Supported Lenses for Box Camera Provider Model No. RV0409D.IR Fujian Forecam Optics RV0515D.IR RV0820D.IR EVD03618F-IR EVD04218F-IR EVD06018F-IR EVETAR EVD08018F-IR EVD12018F-IR EVD16018F-IR Pentax TS3VP213ED-M...
