Servicing:
• This Pump, like all mechanical equipment, requires maintenance.
• Every six months the pump should be removed, and the top (pump unit) should be
unclipped from the reservoir. Care should then be taken to clean the filter, float and
reservoir thoroughly prior to reassembly. We recommend this is done in the Spring
and the Autumn, using an anti-bacterial wash.
• Take great care to replace the float with the magnet
facing upwards:
Troubleshooting:
Fault: The Pump runs all the time.
1. Is the float positioned with the magnet uppermost?
2. Is the pump located firmly onto the reservoir, with the float located inside the
reservoir, around the sensor column?
3. Is there any sludge inside the reservoir, preventing the float from resting on the
bottom? (This may be the case if the pump has been in operation for some time.
Clean using an anti-bacterial wash).
Please note:
The pump will only switch off when the float is at the bottom of the reservoir.
Fault: The Pump stops and starts, and makes a loud noise.
1. The water is siphoning back through the pump. Follow advice in section on
preventing siphoning.
Fault: The Pump runs but does not pump any water.
1. Are there any air-leaks in the pipe running to the pump?
2. Are the pump reservoir and the inlet tube free from sludge and debris?
Fault: The Pump isn't operating at all.
1. Is power reaching the pump? Is it correctly wired? Is the voltage correct?
2. Is the pump very hot? A thermal cut-out may have been activated, which will
reset automatically once the pump has cooled down.
Aspen Pumps Limited, Apex Way, Hailsham, East Sussex, BN27 3WA, United Kingdom
Email: sales@aspenpumps.com Web: www.aspenpumps.com
Tel: +44 (0) 1323 848 842 Fax: +44 (0) 1323 848 847
mini lime pump
Thank you for buying your new Mini Lime Pump.
This manual gives instructions on the correct installation, so it is important that you follow these
instructions carefully. Please record the following information for your future reference:
Serial No.:
Date installed:
Location of System:
sales@aspenpumps.com www.aspenpumps.com
I N S T R U C T I O N G U I D E
•
Completely reversible
•
Quick and easy to install
•
3 trunking range options available
•
Box contains the pump, elbow,
800mm conduit & ceiling plate
•
The Mini Lime will quietly and
reliably pump condensation water
to a maximum height of 8 metres
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aspen mini lime
Summary of Contents for Aspen mini lime
-
Page 1: Troubleshooting
Serial No.: Date installed: Aspen Pumps Limited, Apex Way, Hailsham, East Sussex, BN27 3WA, United Kingdom Location of System: Email: sales@aspenpumps.com Web: www.aspenpumps.com Tel: +44 (0) 1323 848 842 Fax: +44 (0) 1323 848 847... -
Page 2: Technical Data
You will also need several metres of 9mm o/d x 6mm i/d vinyl tube Product Safety: • The Mini Lime Pump has been evaluated for use with water only. • For correct and safe electrical installation please refer to the instruction manual. •... - Page 3 Preventing Siphoning: advice Installation: • Cut discharge tube above water level of evaporator tray and direct end into Decide whether right or left handed system is required large pipe FALSE CEILING END OF DISCHARGE TUBE WATER LEVEL IN TRAY Disassemble system. Hold ‘Elbow back’, ‘Internal conduit sleeve’ and ‘Conduit back’ against the wall, squaring up to th ceiling and the evaporator unit.
- Page 4 NORMALLY CLOSED: Purple NORMALLY OPEN: Orange Wire the Mini Lime Pump to the permanent Live, Neutral and Earth terminals of the Evaporator. Install a 1.0 amp in-line fuse between the Mini Lime Pump and the Evaporator. A high-level alarm switch should be wired into the cooling signal wire, to prevent the continued operation of the Air-conditioning unit in the event of the pump failing.
