Installation Instructions

Installing Room Air Conditioners

Proper installation of a room air conditioner helps ensure
trouble free operation of the unit. Improper installation of
this device can result in problems ranging from noisy
operation to property or equipment damage.
The following paragraphs describe how to properly install
an Amana Room Air Conditioner. Before attempting to
install the unit:
• Carefully read all instructions pertaining to installation.
Make sure each step or procedure is understood and
any special considerations are taken into account.
• Assemble all tools and hardware needed to complete
installation. Some items may need to be purchased
locally. Make sure required tools and hardware are on
hand before starting.
• After deciding where to install unit, closely look the
location over, both inside and outside. Note any
potential obstacles or problems that might be
encountered. Choose a more suitable location if
necessary.

Electrical Requirements

!
WARNING
To avoid risk of electrical shock, personal injury, or
death:
•
Electrical earthing is required on this device.
•
DO NOT earth to gas line.
•
If cold water pipe is interrupted by plastic,
nonmetallic gaskets, or other insulating (non
conducting) materials, DO NOT use it for earth.
•
Check with a qualified electrician if you are not sure
this appliance is properly earthed.
•
DO NOT modify plug on power supply. If plug does
not fit electrical outlet, have a proper outlet installed
by a qualified electrician.
•
DO NOT have a fuse in the neutral or earth circuit.
A fuse in the neutral or earth circuit could result in
an electrical shock.
•
DO NOT use an extension cord with this appliance.
Observe all local codes and ordinances.
RS5100002 Rev. 0

Earthing Instructions

!
To avoid risk of electrical shock or property damage
due to overheating, do not under any circumstances
alter earthing plug. Do not bend or trim power
prongs on plug to make them fit a receptacle for
which they are not intended.
For your personal safety, air conditioner must be earthed.
This air conditioner includes a power supply cord with an
earthing plug. To minimize possible electrical shock
hazard, the power cord must only be plugged into a
matching earthing wall receptacle that complies with all
applicable codes and ordinances. If a matching earthing-
type wall receptacle is not available, it is the responsibility
of the consumer to have a properly earthed wall
receptacle installed by a qualified electrician.
If codes permit, and a separate earthing wire is used,
have a qualified electrician determine if earthing path is
adequate and uninterrupted by plastic, nonmetallic
gaskets, or other insulating (non conductive) materials.
Do not use an extension cord. If power cord supplied
with air conditioner is too short, have a qualified
electrician install an appropriate receptacle closer to unit.
Receptacle Wiring
Receptacle wiring should be 14 gauge, minimum. Use
copper wire only. It is the responsibility of the consumer
to provide proper and adequate receptacle wiring,
installed by a qualified electrician.

Electrical Connection

Electrical earth is required on this appliance.
Electrical Requirements
A separate circuit, serving only this appliance, MUST be
provided. Devices covered in this manual require a 50 Hz
supply. Refer to unit name plate or Technical Sheet for
exact voltage requirements.
6
