XT200i QUICK SETUP GUIDE
Description
The XT control panel is a Videofied wireless, battery operated hybrid alarm system.
It is designed for residential and small business security applications, as well as both
indoor and outdoor commercial applications (construction sites, cell tower, remote
sites, substations...).
XT can be used as a standalone alarm system or can be integrated into an existing
alarms system as an upgrade to Videofied features and technology.
XT has programmable inputs and outputs (outputs available Q1 2011). Programmable
inputs and certain event types can be configured to capture video from a
MotionViewer device using the mapping feature.
The control panel has two easy to access external connectors for upgrading GPRS and
RF antenna connections.

Advertisement

loading
Need help?

Need help?

Do you have a question about the XT200i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Videofied XT200i

Summary of Contents for Videofied XT200i

  • Page 1 XT200i QUICK SETUP GUIDE Description The XT control panel is a Videofied wireless, battery operated hybrid alarm system. It is designed for residential and small business security applications, as well as both indoor and outdoor commercial applications (construction sites, cell tower, remote sites, substations...).
  • Page 2 In Standalone mode, the XT Panel work as full standalone alarm system with 25 wireless Videofied devices, 3 programmable inputs and 2 programmable outputs. XTender Mode In XTender mode, the XT Panel will extend the existing alarm system to include Videofied as video verification and can also work as GPRS cell back-up.
  • Page 3 XT PANEL INSTALLATION 1. Unscrew the 2 screws at the side of the panel to open the control panel. 2. Insert the sim card into the provided slot. Note: Do not insert or remove the sim card when the panel is...
  • Page 4 3. Mount the back casing to the wall with 3 screws to 3) *mounting is not necessary in order to program the panel. 4. Powering the XT Panel Option 1 Option 2 4 x LSH20 Lithium D-Cell 4 x E95 Alkaline D-Cell + 12DC power Used for Standalone or Xtender mode supply without Programmable Inputs.
  • Page 6 XT PANEL PROGRAMMING 1. Reset the XT Panel. Press and hold the Programming Button for 10 seconds until the LED blinks twice. Press and release the Programming Button again. The LED will blink once. The panel is now waiting to pair with CMA200W Wireless keypad. 2.
  • Page 7 6. Key in 4-6 digits installer code and press the YES key. Key in the same 4-6 digits installer code to verify and press the YES key. You may name the installer code. Leave blank for default (ACCESS 1) and press the YES key. 7.
  • Page 8 Key in 4-8 digit account number provided by the Central Station. Press the YES key. Use the left and right arrow keys to select the frequency of periodic test and press the YES key to continue. Use the left and right arrow keys to select the hour the periodic test will happen.
  • Page 9 9-12V on the arming input. STANDALONE: The XT Panel will be a single system. Arm/disarm will be controlled by Videofied devices (Wireless keypad, remote control etc). Press the YES key to continue. *If you selected ‘FROM THE HOST’, please skip...
  • Page 10 Use the left and right arrow keys to set the Exit Delay time and press the YES key to continue. Repeat the same step for Entry Delay. *Proceed to step 16.
  • Page 11 XTender Mode In XTender Mode, control panel will only arm/ disarm by latching 9-12V to one of the two inputs. Arming input 1: Arming/disarming Area 1 & 2. Entry delay on Area 1. Arming input 2: Arming/disarming Area 3 & 4. Entry delay on Area 3.
  • Page 12 The keypad will display ‘GPRS Parameters?’ Press the YES key. Enter the APN code (Access Point Name) as given by the SIM card provider and press the YES key to confirm. Use the left and right arrow keys to scroll to scroll to other parameters. Repeat the above steps for Username, Password, IP1 address and Port 1.
  • Page 13 The keypad will display ‘PRESS PROGRAM BUTTON OF DEVICE’. Press the Programming Button on the device you want to pair. The keypad will display ‘CAMREA 1 RECORDED’. Press the YES key. They keypad will display ‘RADIO RANGE TEST?’. Press the ESC/NO key. Select AREA: 1 for Area Allocation.
  • Page 14 1. Press the Right arrow key until you reach ‘BADGES ACCESS CODES’ and presses the YES key. 2. Key in the installer code and press the YES key. 3. The keypad will display ‘ENTER A BADGE/CODE’. Press the YES key. 4.
