- Page 1 AR-B5630 Socket P Intel® Core™2 Duo EPIC SBC with Intel® GME965 Express Chipset , DVI/LCD, Dual LAN and PCI-104 Eexpansion User Guide Edition: 1.0 Book Number: AR-B5630 08.10.17...
-
Page 2: Table Of Contents
Table of Contents 0. PREFACE..................................4 0.1 COPYRIGHT NOTICE AND DISCLAIMER .............................4 0.2 WELCOME TO THE AR-B5630 CPU BOARD..........................4 0.3 BEFORE YOU USE THIS GUIDE ..............................4 0.4 RETURNING YOUR BOARD FOR SERVICE..........................4 0.5 TECHNICAL SUPPORT AND USER COMMENTS ........................4 0.6 STATIC ELECTRICITY PRECAUTIONS ............................5 1. - Page 3 5.4 PNP/PCI SETUP ...................................29 Thus field allows you to determine whether to reset the configuration data or not. The default value is “Disabled”.29 5.5 PERIPHERALS SETUP ................................30 5.6 PC HEALTH SETUP ..................................31 5.7 BOOT SETUP ....................................31 5.8 EXIT SETUP....................................32 5.9 BIOS UPDATE ....................................33...
-
Page 4: Preface
0. PREFACE 0.1 COPYRIGHT NOTICE AND DISCLAIMER This document is copyrighted, 2008, by Acrosser Technology Co., Ltd. All rights are reserved. No part of this manual may be reproduced, copied, transcribed, stored in a retrieval system, or translated into any language or computer language in any form or by any means, such as electronic, mechanical, magnetic, optical, chemical, manual or other means without the prior written permission or original manufacturer. -
Page 5: Static Electricity Precautions
0.6 STATIC ELECTRICITY PRECAUTIONS Before removing the board from its anti-static bag, read this section about static electricity precautions. Static electricity is a constant danger to computer systems. The charge that can build up in your body may be more than sufficient to damage integrated circuits on any PC board. It is, therefore, important to observe basic precautions whenever you use or handle computer components. -
Page 6: Introduction
1. INTRODUCTION Welcome to the AR-B5630 ECIP AT/ATX Single Board Computer. The AR-B5630 is EPIC board with Socket P Intel Core™2 Duo or Core Duo or Core Solo and Celeron M processor and GM965 + Intel ICH8M Chipset. The memory contents one DDR2 SO-DIMM socket which supports up to 2GB of memory. -
Page 7: Specifications
1.2 SPECIFICATIONS Specifications (Proposed Specifications) Model Name AR-B5630 V 1.0 Product EPIC SBC support 65nm Intel uFC-PGA 478 Core 2 Duo/Core Duo/Core Solo/Celeron M Descriptions Processors with Dual Gigabit LANs / LCD / TV out / DVI General Note Socket for Intel uFC-PGA 478 Core 2 Duo/Core Duo/Core Solo/Celeron M, Coolers required. - Page 8 1 x RS-232 (COM1) Serial Port 2 x RS-232 (COM3/4) Pin Header 1 x RS-232/422/485 (COM2) Touch Screen Parallel Port GPIO 8 Independent TTL level I/O PinHeader (2x5x2.0) 2 x External ports Connector 2 x Internal ports Pin Header (1x5x2.0) IrDA 1XIR PinHeade...
-
Page 9: Block Diagram
1.3 BLOCK DIAGRAM... -
Page 10: Installation
2. INSTALLATION This chapter describes how to install the AR-B5630. At first, the layout of AR-B5630 is shown, and the unpacking information that you should be careful is described. The jumpers and switches setting for the AR-B5630’s configuration are as below. -
Page 11: Connection
3. CONNECTION The connectors on AR-B5630 allows you to connect external devices such as USB devices, serial port drives, hard disk devices, etc. The following table lists the connectors on AR-B5630 and their respective functions. 1. AT 2. ATX 3. SATA POWER 4. - Page 12 1.DDR2ONNECTOR 2.CF CONNECTOR...
-
Page 13: At Power Input (Pwr2)
3.1 AT POWER INPUT (PWR2) SIGNAL +12V +12V 3.2 ATX FUNCTION CONNECTOR (CON2) SIGNAL PS_ON +5V_SUS 3.3 SATA POWER (CON3) 3.4 SERIRQ CONNECTOR (JP2) SIGNAL SHORT SERIRQ OPEN NOT SERIRQ... -
Page 14: Cpu Fan (Fan1)
3.5 CPU FAN (FAN1) SIGNAL +12V SENSE 3.6 PCI104 (J10) 3.7 SATA CONNECTOR (SATA1) SIGNAL SIGNAL... -
Page 15: Pata Connector (Ide1)
3.8 PATA CONNECTOR (IDE1) Signal Signal -RESET GROUND DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14 DATA 0 DATA 15 GROUND PDDREQ GROUND... -
Page 16: Battery Connector (Bat1)
3.11 BATTERY CONNECTOR (BAT1) 3.12 COMS CLAER CONNECTOR(J5) 3.13 EYBOARD/MOUSE CONNECTOR (KM1) 1 KDT 2 MDT 3 GND 4 VCC 5 KCLK Front View 6 MCLK 3.14 INTERNAL USB CONNECTOR (USB2) SIGNAL SIGNAL USB0- USB1- USB0+ USB1+ 3.15 EXTERNAL USB (USB1) SIGNAL SIGNAL USB0-... -
Page 17: Rj45 Connector (Lan2)
3.16 RJ45 CONNECTOR (LAN2) PIN (LAN1 FUNCTION TPTX+ TPTX - TPRX+ Not Used Not Used TPRX - Not Used Not Used 3.17 RJ45 CONNECTOR (LAN1) PIN (LAN1 FUNCTION TPTX+ TPTX - TPRX+ Not Used Not Used TPRX - Not Used Not Used 3.18 DB-15 VGA CONNECTOR (VGA1) -
Page 18: Dvi-I Connector (Dvi1)
SIGNAL SIGNAL GREEN BLUE HSYNC VSYNC 3.19 DVI-I CONNECTOR (DVI1) SIGNAL SIGNAL TD0+ TD0- TD1+ TD1- TD2+ TD2- TCK+ TCK- SCL1 SDATA1 GREEN BLUE VSYNC SCL2 HSYNC SDATA2 3.20 TV-OUT (TVCON1) SIGNAL SIGNAL CVBS/Pb-G C/Pr-G... -
Page 19: Com2 (Com1)
3.21 COM2 (COM1) SIGNAL SIGNAL /DCDB /DSRB RXDB /RTSB TXDB /CTSB /DTRB /RIB 3.22 COM1 (CON1) SIGNAL SIGNAL /DCDB /DSRB RXDB /RTSB TXDB /CTSB /DTRB /RIB 3.23 COM3 (COM2) SIGNAL SIGNAL /DCDB /DSRB RXDB /RTSB TXDB /CTSB /DTRB /RIB... -
Page 20: Com4 (Com3)
3.24 COM4 (COM3) SIGNAL SIGNAL /DCDB /DSRB RXDB /RTSB TXDB /CTSB /DTRB /RIB 3.25 SYSTEM FAN (FAN2) SIGNAL CONTROL SENSE 3.26 AUDIO CONNECTOR (AUDIO1) SIGNAL SIGNAL LINE LINE OUT R OUT L LINE IN LINE IN MIC IN... -
Page 21: Panel Power Selector (J1)
3.27 PANEL POWER SELECTOR (J1) SIGNAL 3.3V 3.28 GPIO (GPIO1) SIGNAL SIGNAL GPIO0 GPIO1 GPIO7 GPIO2 GPIO6 GPIO3 GPIO5 GPIO4 3.29 RS232/422/485 SWITCH (JP1) SIGNAL RS232 RS422 RS485... -
Page 22: Rs422/Rs485 Connector (J9)
3.30 RS422/RS485 CONNECTOR (J9) SIGNAL 3.31 IR CONNECTOR (IR1) 3.32 PANEL POWER SELECTOR (J1) SIGNAL 3.3V 3.33 LVDS POWER (LCDPW1) SIGNAL SIGNAL +12V +12V BKLTEN BKLTCTL... -
Page 23: Lvds Connector (Lcd1)
3.34 LVDS CONNECTOR (LCD1) 3.35 DDR2 SO-DIMM (DDR1) 3.36 CF SOCKET (CN3) -
Page 24: Watchdog Timer Configuration
4. WATCHDOG TIMER CONFIGURATION 4.1 WATCHDOG TIMER SETTING The WDT (Watch Dog Timer) is used to generate a variety of output signals after a user programmable count. The WDT is suitable for use in the prevention of system lock-up, such as when software becomes trapped in a deadlock. - Page 25 // Set Watchdog outportb(IO_Port_Address,0x07); // Point to Logical Device Number Reg. outportb(IO_Port_Address+1,0x07); // Select logical device 7, (Watchdog Function) outportb(IO_Port_Address,0x23); // Select Watchdog use CLKIN outportb(IO_Port_Address+1,inportb(IO_Port_Address+1)|0x10); outportb(IO_Port_Address,0x72); // Select Watchdog use keyboard reset outportb(IO_Port_Address+1,0x40); outportb(IO_Port_Address,0x72); // Select Watchdog count mode seconds or minutes outportb(IO_Port_Address+1,inportb(IO_Port_Address+1)|0x80);...
-
Page 26: Bios Console
5. BIOS CONSOLE This chapter describes the AR-B5630 BIOS menu displays and explains how to perform common tasks needed to get up and running, and presents detailed explanations of the elements found in each of the BIOS menus. The following topics are covered:... -
Page 27: The Field Determines Whether Or Not The System Will Halt If An Error Is Detected During The Power Up
Time Setup The time format is： Hour：0 to 24 Minute：00 to 59 Second：00 to 59 To set the time, highlight the “Time” field and use the 【PageUp】/【PageDown】or 【+】/【-】keys to set the current time. IDE Primary HDDs⁄IDE Secondary HDDs The onboard PCI IDE connectors provide primary and secondary channels for connecting up to four IDE hard disks or other devices. -
Page 28: When Enabled, This Field Speeds Up The Power On Self Test (Post) After The System Is Turned On. If It Is Set To Enable, Bios Will Skip Some Items
Hyper-Threading Technology To enable HT Function Quick Power On Self Test When enabled, this field speeds up the Power On Self Test (POST) after the system is turned on. If it is set to Enable, BIOS will skip some items. Full Screen LOGO Show The options for this field are “Enabled”... -
Page 29: Enable This Function To Support Acpi (Advance Configuration And Power Interface)
ACPI Function Enable this function to support ACPI (Advance Configuration and Power Interface) ACPI Suspend Type This options for this field are S1 (POS) and S3 (STR). By default, the field is set to S1 (POS) PWRON After PWR-Fail The field sets the system power status whether on or off when power returns from a power failure. Power –Supply Type This item allows you to choose the Type of Power Supply in use.The Choice: AT, ATX. -
Page 30: Peripherals Setup
5.5 PERIPHERALS SETUP This option controls the configuration of the board’s chipset. Control keys for this screen are the same as for the previous screen. Peripherals Setup Onboard Serial Port 1 Onboard Serial Port 2 Onboard Serial Port 3 Onboard Serial Port 4 These fields allow you to select the on board serial ports and their addresses. -
Page 31: Pc Health Setup
5.6 PC HEALTH SETUP This section shows the parameters in determining the PC Health Status. These parameters include temperatures, fan speeds, voltages. PC Health Status Temperature / Voltage These fields are parameters of the hardware monitoring function feature of the motherboard. The values are read-only values as monitored by the system and show the PC health status. -
Page 32: Exit Setup
First / Second / Third Boot Device These fields determine the device that the system searches first for an operating system. The option available include Hard Disk, CDROM, USB-FDD, USB-CDROM and Disable. Boot Other Device These fields allow the system to search for an OS from other devices other than the ones selected in the First / Second / Third Boot Device. -
Page 33: Bios Update
The chips can be electronically reprogrammed, allowing you to upgrade your BIOS firmware without removing and installing chips. The AR-B5630 provides the FLASH BIOS update function for you to easily to update to a newer BIOS version. Please follow these operating steps to update to new BIOS：...
