Acrosser Technology AR-B1622 User Manual

Amd gx3, vga, lan, pc104+, 2 com, 4 usb
Hide thumbs Also See for AR-B1622:

Advertisement

Quick Links

AR-B1622 User's Guide
AR-B1622
AMD GX3 , VGA , LAN ,
PC104+ , 2 COM , 4 USB
User' s Guide
Edition: 1.1
1

Advertisement

Table of Contents
loading

Summary of Contents for Acrosser Technology AR-B1622

  • Page 1 AR-B1622 User’s Guide AR-B1622 AMD GX3 , VGA , LAN , PC104+ , 2 COM , 4 USB User’ s Guide Edition: 1.1...
  • Page 2 In addition, the AR-B1622 provides on chip VGA. The VGA, which provides up to True Color (32 bit) 1024x768, or High Color (16 bit) 1280x1024 resolution. The VGA memory is share main memory (2M, 4M, or 8M). AR-B1622 also has 24-bit LVDS function in the system.
  • Page 3: Specifications

    AR-B1622 User’s Guide SPECIFICATIONS CPU: GX3 Chipset: CS5536 RAM memory: Supports DDR-RAM, on-board 200-pin SO-DIMM up to 1GB DDR-RAM memory module Display Interface: CRT –10-pin pin-header. LVDS – for 24 bit TFT LCD Panel. Ultra ATA/33/66/100 IDE Interface: Series ports: On-board two 2x5x2.00mm pin-header connector for COM1, COM2.
  • Page 4: Setting Up System

    AR-B1622 User’s Guide 2. SETTING UP SYSTEM This chapter describes how to install the AR-B1622. At first, the layout of AR-B1622 is shown, and the unpacking information that you should be careful is described. Overview System Settings 2.1 AR-B1622 OVERVIEW...
  • Page 5 AR-B1622 User’s Guide Super I/O W83627 BOTTOM PLACEMENT...
  • Page 6: System Settings

    Press the jumper evenly onto the pins. Be careful not to bend the pins. We will show the locations of the AR-B1622 jumper pins, and the factory-default settings. CAUTION: Do not touch any electronic components unless you are safely grounded.
  • Page 7 AR-B1622 User’s Guide 2.2.2 VJP1 (LCD 3V or 5V) DEFINE 2.2.3 COM1&COM2 DEFINE DEFINE -DCD -DSR -RTS SOUT -CTS -DTR 2.2.4 JFRT1 DEFINE RESET PIN 3:5V(PWR LED) PIN 4:GND PIN 5:5V PIN 6:HD LED PIN 7:SPEAKER+ PIN 8:SPEAKER- 9-10 2.2.4...
  • Page 8 AR-B1622 User’s Guide 2.2.5 DIO1(GPIO) DEFINE DEFINE BIT 4 BIT 5 BIT 5 BIT 6 BIT 0 BIT 1 BIT 2 BIT 3 2.2.6 J5(PCI104) SERIR AD21 AD20 AD19 +3.3V AD23 AD22 +3.3V IDSEL0 IDSEL1 AD22 C/BE0# AD24 C/BE3# AD23...
  • Page 9 AR-B1622 User’s Guide 2.2.8 USB1&USB2 DEFINE DEFINE DATA- DATA- DATA+ DATA+ 2.2.9 DEFINE V+(3.3V) 2.2.10 JP2(SERIRQ) DEFINE close Connect SERIQR to PCI104 pin B1 open Disconnect SERIRQ 2.2.11 J4(LAN) DEFINE CONNECT RC CIRCUIT TO GROUND CONNECT RC CIRCUIT TO GROUND...
  • Page 10 AR-B1622 User’s Guide 2.2.12 IDE1 PIN DEFINE PIN DEFINE PIN DEFINE DEFINE RESET# IOW# DATA7 DATA8 IOR# DATA6 DATA9 BALE DATA5 DATA10 DATA4 DATA11 INTERRUPT IOCS16# DATA3 DATA12 DATA2 DATA13 DATA1 DATA14 CS0# CS1# DATA0 DATA15 ACTIVE# 5V LOGIC +5V MOTOR TYPE 2.2.13 CN2(Power)...
  • Page 11: Lcd Flat Panel Display

    AR-B1622 User’s Guide 3. LCD FLAT PANEL DISPLAY This chapter describes the configuration and installation procedures for LCD displays. TFT LCD Interface AR-B1622 Panel Backlight Power Inverter LCD Panel Block Diagram Please visit our web site or contact with our technical support department for supports of LCD connecting.
  • Page 12: Bios Console

    AR-B1622 User’s Guide 4. BIOS CONSOLE This chapter describes the AR-B1622 BIOS menu displays and explains how to perform common tasks needed to get up and running, and presents detailed explanations of the elements found in each of the BIOS menus. The...
  • Page 13 AR-B1622 User’s Guide Date & Time Setup Highlight the <Date> field and then press the [Page Up] /[Page Down] or [+]/[-] keys to set the current date. Follow the month, day and year format. Highlight the <Time> field and then press the [Page Up] /[Page Down] or [+]/[-] keys to set the current date.
  • Page 14 AR-B1622 User’s Guide 【 】 Console Redirection Enable This allows you to enable the console function or not. 【 】 Baud Rate 115200 This allows you to set up the transfer speed for console. 【 】 Agent after boot Disabled This allows you to open the Agent after boot function or not.
  • Page 15 AR-B1622 User’s Guide 4.3 PERIPHERALS Peripherals Onboard Serial Port 1 [3F8/IRQ4] Choose serial port 1 I/O address. Do not set port 1, 2, 3 and 4 to the same address except for Disabled or Auto. Onboard Serial Port 2 [2F8/irq3] Choose serial port 2 I/O address.
  • Page 16 AR-B1622 User’s Guide 4.4PnP/PCI PnP/PCI Reset Configuration Data [Disable] Normally, you leave this field Disabled. Select Enabled to reset Extended System Configuration Data (ESCD) when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system cannot boot.
  • Page 17 AR-B1622 User’s Guide 4.5 BOOT BOOT First/Second/Third Boot Device HDD-0 SCSI CDROM HDD-1 USB-FDD USB-ZIP USB-CDROM USB-HDD Disabled Boot Other Device [Enabled] Configuration options: [Enabled] [Disabled]. LAN Boot Select [Disabled] This allows you to enable or disable the LAN Boot function..
  • Page 18 AR-B1622 User’s Guide 4.6 BIOS EXIT Exit When you have made all of your selections from the various menus in the Setup program, save your changes and exit Setup. Select Exit from the menu bar to display the following menu.
  • Page 19 AR-B1622 User’s Guide 5. I/O address、IRQ and Memory Mapping 5.1 I/O address Mapping...
  • Page 20 AR-B1622 User’s Guide 5.2 IRQ Mapping 5.3 Memory Mapping...
  • Page 21: Gpio Sample Code

    AR-B1622 User’s Guide 6. GPIO Sample Code /*[]======================================================================[]*/ /*|| GPIO Test utility for W83627HF. ||*/ /*|| Date : 10/18/2005 ||*/ /*|| Author : Willy ||*/ /*[]======================================================================[]*/ /*[]======================================================================[]*/ /*|| Include files ||*/ /*[]======================================================================[]*/ #include <conio.h> #include <stdio.h> /*[]======================================================================[]*/ /*|| Assember Types Define...
  • Page 22 AR-B1622 User’s Guide if(Read_Byte&0x01) //GPI10 Show_Byte=Show_Byte|0x01; else Show_Byte=Show_Byte&0xFE; if(Read_Byte&0x02) //GPI11 Show_Byte=Show_Byte|0x02; else Show_Byte=Show_Byte&0xFD; if(Read_Byte&0x04) //GPI12 Show_Byte=Show_Byte|0x04; else Show_Byte=Show_Byte&0xFB; if(Read_Byte&0x08) //GPI13 Show_Byte=Show_Byte|0x08; else Show_Byte=Show_Byte&0xF7; if(Read_Byte&0x10) //GPI14 Show_Byte=Show_Byte|0x10; else Show_Byte=Show_Byte&0xEF; if(Read_Byte&0x20) //GPI15 Show_Byte=Show_Byte|0x20; else Show_Byte=Show_Byte&0xDF; if(Read_Byte&0x40) //GPI16 Show_Byte=Show_Byte|0x40; else Show_Byte=Show_Byte&0xBF; if(Read_Byte&0x80) //GPI17 Show_Byte=Show_Byte|0x80;...
  • Page 23 AR-B1622 User’s Guide printf("\n>>>>> GPI Test End <<<<<\n"); return 0; // return pass /*[]======================================================================[]*/ /*|| Function : GPO_TEST() ||*/ /*|| Input : BYTE IO_PORT_BASE ||*/ /*|| Change ||*/ /*|| Return : Pass return "0", Fail return "1". ||*/ /*|| Description: Test GPO Pins status.
  • Page 24 AR-B1622 User’s Guide { Show_Title(); return 1; } clrscr(); // Enter W83627HF Config Enter_Config(IO_PORT_BASE); Init_SIO(IO_PORT_BASE); switch(argv[1][0]) case 'i': case 'I': //I Key result=GPI_TEST(IO_PORT_BASE); if(result==0) printf("Test Result is Pass."); else printf("Test Result is Fail."); break; case 'o': case 'O': //O Key result=GPO_TEST(IO_PORT_BASE);...
  • Page 25 AR-B1622 User’s Guide int X_Axis,Y_Axis; char y_n; X_Axis=wherex(); /* Get Cursor X Axis */ Y_Axis=wherey(); /* Get Cursor Y Axis */ while(1) { y_n=getche(); if(y_n=='y' || y_n=='Y') return('y'); else if(y_n=='n' || y_n=='N') return('n'); else gotoxy(X_Axis,Y_Axis); /*[]======================================================================[]*/ /*|| Function : Enter_Config()
  • Page 26 AR-B1622 User’s Guide outportb(IO_PORT_BASE+1,0x07); // Set GPIO Port Active outportb(IO_PORT_BASE,0x30); outportb(IO_PORT_BASE+1,0x01);...
