AND-APL1N1FL-XX Series User Manual
AND-APL1N1FL-XX
®
Intel
Apollo Lake series Networking Microbox
®
powered by SoC Celeron
CPU
J-Series/N-Series/E-Series
6x GbE LAN (3-pair Bypass)
User Manual
Acrosser Technology Co., Ltd.
www.acrosser.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AND-APL1N1FL Series and is the answer not in the manual?

Questions and answers

Related Manuals for Acrosser Technology AND-APL1N1FL Series

Summary of Contents for Acrosser Technology AND-APL1N1FL Series

  • Page 1 AND-APL1N1FL-XX Series User Manual AND-APL1N1FL-XX ® Intel Apollo Lake series Networking Microbox ® powered by SoC Celeron J-Series/N-Series/E-Series 6x GbE LAN (3-pair Bypass) User Manual Acrosser Technology Co., Ltd. www.acrosser.com...
  • Page 2 Acrosser Technology Co., Ltd. In no event will Acrosser Technology Co., Ltd. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 3: Table Of Contents

    AND-APL1N1FL-XX Series User Manual Table of Contents 1. System Introduction ..............5 1.1. Specifications ......................5 1.2. Package Contents ...................... 7 1.3. Dimensions ......................... 8 1.4. Front Panel ......................... 9 1.5. Rear Panel........................ 10 2. Components Assembly ..............11 2.1. 2.5” SATA SSD Installation ..................11 2.2.
  • Page 4 5.3. API List and Descriptions ..................53 5.3.1. GPIO ......................53 5.3.2. Watchdog ...................... 54 5.3.3. LAN Bypass Subsystem ................54 5.3.4. Notes ......................56 6. FAQ ....................57 Q 1. Where is the serial number located on my system? ..........57 Acrosser Technology Co., Ltd.

  • Page 5: System Introduction

    AND-APL1N1FL-XX Series User Manual System Introduction 1.1. Specifications System Thermal Solution • 1x Fanless Heatsink ® ® • Intel Apollo Lake SoC Celeron J-Series CPU ® ® • Intel Apollo Lake SoC Celeron N-Series CPU ® ® • Intel Apollo Lake SoC Celeron E-Series CPU System Memory •...
  • Page 6 Storage Temperature • -20 ~ 80°C (-4 ~ 176°F) Relative Humidity • 0 ~ 90% @40°C, non-condensing EMC & Safety • CE, FCC Class A Vibration Test • IEC 60068-2-64, 5~500Hz, 3GRMS Drop Test • ISTA-2A 2006 Acrosser Technology Co., Ltd.

  • Page 7: Package Contents

    AND-APL1N1FL-XX Series User Manual 1.2. Package Contents Check if the following items are included in the package. Item Q’ty AND-APL1N1FL-XX Series System � SATA Power Cable � SATA Cable � Driver CD � Console Cable (RJ45) � Power Adapter � Power Cord �...

  • Page 8: Dimensions

    AND-APL1N1FL-XX Series User Manual 1.3. Dimensions (Unit: mm) 48.4 Acrosser Technology Co., Ltd.

  • Page 9: Front Panel

    AND-APL1N1FL-XX Series User Manual 1.4. Front Panel Link Blinking • USB 3.0 connector. • Power Indicator. • HDD Indicator. PWR: Green, HDD: Yellow. • BYP 1, BYP 2, BYP 3 Bypass LED. ln-active: Green, Active: Red. • LAN1 ~ LAN6 LAN LED.

  • Page 10: Rear Panel

    USB3.0 connectors. • LAN1 ~ LAN6 LAN connectors. Light Status Green Blinking Link w/ Act LED1 Green On Link w/o Act No Link 10Mbps LED2 Orange On 100Mbps Green On 1000Mbps • ANT1 ~ ANT3 Antenna Hole Acrosser Technology Co., Ltd.

  • Page 11: Components Assembly

    AND-APL1N1FL-XX Series User Manual Components Assembly 2.1. 2.5” SATA SSD Installation Step 1: Unscrew the front cover plate. Step 2: Insert your SSD into the tray. (The contact pins face inward.) www.acrosser.com...
  • Page 12 AND-APL1N1FL-XX Series User Manual Step 3: Connect the SATA cable. Step 4: Lock the cover plate with screws. Acrosser Technology Co., Ltd.

  • Page 13: Dimm Card Installation

    AND-APL1N1FL-XX Series User Manual 2.2. DIMM Card Installation Step 1: Unscrew the front cover plate. Step 2: Install your DIMM card into the DIMM slot on the mainboard. Pay attention to its orientation, and do not scratch the contacts. Step 3: Lock the cover plate with screws.

  • Page 14: Antenna Connection

    After having installed your wireless module into the mainboard and the antenna socket, you may connect your antennas needed according to your system configuration. Step 1: Make sure your antenna type matches with the antenna socket. Step 2: Insert the antenna plug into the antenna socket. Acrosser Technology Co., Ltd.
  • Page 15 AND-APL1N1FL-XX Series User Manual Step 3: Turn the antenna body upright. Step 4: Connect your antennas needed according to your system configuration. www.acrosser.com...

  • Page 16: Bios Settings

    Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc. Note: Listed at the bottom of the menu are the control keys. If you need any help with the item fields, you can press <F1> key, and it will display the relevant information. Acrosser Technology Co., Ltd.

  • Page 17: Advanced Setup

    AND-APL1N1FL-XX Series User Manual • System Date Set the system date. Use Tab to switch between Date elements. • System Time Set the system time. Use Tab to switch between Time elements. 3.2. Advanced Setup Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Main Advanced Chipset...

  • Page 18: Trusted Computing

    Enables or Disables BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. • SHA-1 PCR Bank Enables or Disables SHA-1 PCR Bank. • SHA256 PCR Bank Enables or Disables SHA256 PCR Bank. Acrosser Technology Co., Ltd.

  • Page 19: Acpi Settings

    AND-APL1N1FL-XX Series User Manual • Pending Operation Schedule an Operation for the Security Device. NOTE: Your Computer will reboot during restart in order to change State of Security Device. • Platform Hierarchy Enables or Disables Pateform Hierarchy. • Storage Hierarchy Enables or Disables Storage Hierarchy.

  • Page 20: Super Io Configuration

    F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc. • COM1 Set Parameters of Serial Port 1. • COM2 Set Parameters of Serial Port 2. Acrosser Technology Co., Ltd.

  • Page 21: Hardware Monitor

    AND-APL1N1FL-XX Series User Manual 3.2.4. Hardware Monitor Dsiplay hardware monitor status. Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Advanced PC Health Status CPU Temp : +35°C SYS Temp : +25°C SYS_FAN1 : N/A VCC_CPU : +0.869 V VCC_DDR : +1.364 V : +12.276 V...

  • Page 22: Hardware Monitor

    PIC 1-3 WDT [PASS] →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc. Acrosser Technology Co., Ltd.

  • Page 23: Power Button & Pxe Control

    AND-APL1N1FL-XX Series User Manual 3.2.7. Power Button & PXE Control Set Power Button & PXE Control. Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Advanced PowerOn after PowerFail [Power Off] Specify what state to go to Soft-Off by PWR-BTTN [Instant-Off] when power is re-applied LAN PXE BOOT...

  • Page 24: Sata Drivers

    F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc. • Chipset SATA Enables or Disables the Chipset SATA Controller. • SATA Mode Selection Determines how SATA controller(s) operate. Acrosser Technology Co., Ltd.

  • Page 25: S5 Rtc Wake Settings

    AND-APL1N1FL-XX Series User Manual 3.2.9. S5 RTC Wake Settings Enable system to wake from S5 using RTC alarm. Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Advanced Wake system from S5 [Disabled] Enable or Disable system wake on alarm event. Select FixedTime, system will wake on the hr::min::sec specified.

  • Page 26: Serial Port Console Redirection

    Console Redirection Enable/Disable Consol Redirection. • Console Redirection Settings The settings specify how the host computer and the remote computer (which the user is using) will exchange data. Both computers should have the same or compatible setttings. Acrosser Technology Co., Ltd.

  • Page 27: Cpu Configuration

    AND-APL1N1FL-XX Series User Manual 3.2.11. CPU Configuration Set CPU configuration parameters. Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Advanced CPU Configuration Socket specific CPU Information Socket 0 CPU Information Speed 1600 MHz 64-bit Supported CPU Power Management Active Processor Core [Disabled] Intel Virtualization Technology...

  • Page 28: Csm Configuration

    BIOS reaction on INT19 trapping by Option ROM. [IMMEDIATE]: Execute the trap right away. [POSTONED]: Execute the trap during legacy boot. • Boot option filter This option controls Legacy/UEFI ROMs priority. • Network Controls the execution of UEFI and Legacy PXE OpROM. Acrosser Technology Co., Ltd.

  • Page 29: Usb Configuration

    AND-APL1N1FL-XX Series User Manual • Storage Controls the execution of UEFI and Legacy Storage OpROM. • Video Controls the execution of UEFI and Legacy Video OpROM. • Other PCI devices Determines OpROM execution policy for devices other than Network, Storage, or Video.

  • Page 30: Chipset Setup

    F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc. • North Bridge North Bridge Parameters. • South Bridge South Bridge Parameters. • South Cluster Configuration South Cluster Configuration. Acrosser Technology Co., Ltd.

  • Page 31: North Bridge

    AND-APL1N1FL-XX Series User Manual 3.3.1. North Bridge Set North Bridge configuration parameters. Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Chipset Memory Information Maximum Value of TOLUD. Total Memory 4096 MB (LPDDR3) Memory Slot0 4096 MB (LPDDR3) Max TOLUD [2 GB] Above 4GB MMIO BIOS assignment [Disabled]...

  • Page 32: South Bridge

    F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc. • Serial IRQ Mode Configure Serial IRQ Mode. • OS Selection Select the target OS. Acrosser Technology Co., Ltd.

  • Page 33: South Cluster Configuration

    AND-APL1N1FL-XX Series User Manual 3.3.3. South Cluster Configuration Set South Cluster configuration parameters. Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Chipset PCI Express Configuration PCI Express Configuration USB Configuration Settings →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt.

  • Page 34: Security Setup

    F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc. • Setup Administrator Password Set Setup Administrator Password. • User Password Set User Password. Acrosser Technology Co., Ltd.

  • Page 35: Boot Setup

    AND-APL1N1FL-XX Series User Manual 3.5. Boot Setup Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Boot Configuration Number of seconds to wait Setup Prompt Timeout for setup activation key. Bootup NumLock State [On] 65535(0xFFFF) means Quiet Boot...

  • Page 36: Save & Exit Setup

    Reset system setup without saving any changes. • Restore Defaults Restore/Load Default values for all the setup options. • Launch EFI Shell from filesystem device Attemps to Launch EFI Shell application (shell.efi) from one of the available filesystem devices. Acrosser Technology Co., Ltd.

  • Page 37: Driver And Utility Installation

    AND-APL1N1FL-XX Series User Manual Driver and Utility Installation 4.1. Driver CD Interface Introduction Acrosser provides a Driver CD compiled with all the drivers, utilities, applications and documents this product may need. Put the Driver CD into your CD-ROM drive. The Driver CD will automatically detect the mainboard information to see if they are matched.

  • Page 38: Windows Installation

    4.2. Windows Installation Put the correct Driver CD of your mainboard into your CD-ROM drive. The following installation screen should appear. If not, enter the root folder of the Driver CD, run the excution file “Setup.exe“. Acrosser Technology Co., Ltd.

  • Page 39: Driver Installation Page

    AND-APL1N1FL-XX Series User Manual 4.2.1. Driver Installation Page Step 1: Select the “Driver” tab. Step 2: Click the “Select All” button to select all the driver checkboxes, and then click “Install” button to start installing all the selected drivers. www.acrosser.com...
  • Page 40 Select the “Clear All“ button will clear all the selections, and then you can select the Note: driver you want to install one by one, but the “Chipset” driver has to be installed before installing all the others. Acrosser Technology Co., Ltd.

  • Page 41: Utility Page

    AND-APL1N1FL-XX Series User Manual 4.2.2. Utility Page Before launching the utility, you should run the Windows test mode by running the command “BCDEdit /set testsigning on”, and restart the system. If you want to call this AcrosserLib.dll API file to initiate peripherals function, e.g. GPIO, PIC, or WatchDog, also run this command first, and restart the system.
  • Page 42 AND-APL1N1FL-XX Series User Manual Step 2: The “Test Utility” screen appears. Click Test Item: Acrosser Technology Co., Ltd.
  • Page 43 AND-APL1N1FL-XX Series User Manual Select (1) GPIO TEST Utility: Select (2) WatchDog TEST Utility: www.acrosser.com...
  • Page 44 AND-APL1N1FL-XX Series User Manual Select (3) LanBypass TEST: Acrosser Technology Co., Ltd.

  • Page 45: Application Installation Page

    AND-APL1N1FL-XX Series User Manual 4.2.3. Application Installation Page Select the “Application” tab. Click the “Drivers for Optional Modules” box. Step 1: Step 2: Select the driver you want to install. www.acrosser.com...
  • Page 46 AND-APL1N1FL-XX Series User Manual Step 3: Select the “Application” tab. Click the “Audio Driver” box. Step 4: Click “Setup.exe” to install audio driver. Acrosser Technology Co., Ltd.
  • Page 47 AND-APL1N1FL-XX Series User Manual Step 5: Select the “Application” tab. Click the “Fintek Serial” box. Step 6: Click “FintekSerial.exe” to install COM Port driver. www.acrosser.com...

  • Page 48: Document Page

    AND-APL1N1FL-XX Series User Manual 4.2.4. Document Page The user manual is stored in the “Document” folder. Acrosser Technology Co., Ltd.

  • Page 49: Linux Configuration

    AND-APL1N1FL-XX Series User Manual 4.3. Linux Configuration Step 1: Before running the shell script file install_driver to complete the utiltiy, make sure to have Internet access. Run the sudo mono TestUtility.exe. Step 2: The “Test Utility” screen appears. www.acrosser.com...
  • Page 50 AND-APL1N1FL-XX Series User Manual Click Test Item: Select (1) GPIO TEST Utility: Acrosser Technology Co., Ltd.
  • Page 51 AND-APL1N1FL-XX Series User Manual Select (2) WatchDog TEST Utility: Select (3) LanBypass TEST: www.acrosser.com...

  • Page 52: Software Installation And Programming Guide

    4. Get bypass wdt action. 5. Set bypass power on action. 6. Get bypass power on action. 7. Set bypass power off action. 8. Get bypass power off action. 9. Set bypass current action. 10. Get bypass current action. Acrosser Technology Co., Ltd.

  • Page 53: File Descriptions

    AND-APL1N1FL-XX Series User Manual 5.2. File Descriptions 5.2.1. GPIO/Watchdog/LAN Bypass Subsystem 1. TestUtility.exe The Watchdog, LAN Bypass Subsystem, GPIO, and Graphic user interface bin binary. 2. Libw83627.h This file includes the declarations of the APIs and macro definitions. 3. Libw83627.a The static library for linux.

  • Page 54: Watchdog

    Return Value: 0: Successful, -1: fail. Syntax: int set_bypass_wdt(int pair, int time) Description: This function can set which pair bypass Wdt timer. Parameters: pair: 1-4 , time: 1-255(sec), 0: stop. Return Value: 0: Successful, -1: fail. Acrosser Technology Co., Ltd.
  • Page 55 AND-APL1N1FL-XX Series User Manual Syntax: int set_bypass_wdt_action(int pair, int action) Description: This function can set which pair bypass Wdt time up action. Parameters: pair: 1-4, action: 0: bypass, 1: normal. Return Value: 0: Successful, -1: fail. Syntax: int get_bypass_wdt_action(int pair) Description: This function can get which pair bypass Wdt time up action.

  • Page 56: Notes

    Before using the watchdog, gpio function, must call this function first. Parameters: None. Return Value: 0: Successful, -1: fail. Syntax: void lib_close(void) Description: If watchdog and gpio fuction are not used in your program, please call this function. Parameters: None. Return Value: None. Acrosser Technology Co., Ltd.

  • Page 57: Faq

    AND-APL1N1FL-XX Series User Manual Q 1. Where is the serial number located on my system? • The serial number (S/N) is an alpha-numeric character located on the bottom or side chassis. (for reference only) www.acrosser.com...
  • Page 58 AND-APL1N1FL-XX Series User Manual Technical Support Form We deeply appreciate your purchase of Acrosser products. Please find the “tech_form. doc” file in our utility CD. If you have any questions or problems about Acrosser products, please fill in the following information. We will answer your questions in the shortest time possible.
