Acrosser Technology AR-ES6050FLD System Manual

Fan-less embedded system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Revision: 1.0
AR-ES6050FLD
System Guide
Revision
Description
Date
1.0
Release
2010/08/20
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AR-ES6050FLD and is the answer not in the manual?

Questions and answers

Related Manuals for Acrosser Technology AR-ES6050FLD

Summary of Contents for Acrosser Technology AR-ES6050FLD

  • Page 1 Revision: 1.0 AR-ES6050FLD System Guide Revision Description Date Release 2010/08/20...

  • Page 2: Table Of Contents

    Revision: 1.0 Contents 1 Introduction to AR-ES6050FLD..........3 1.1 Specifications..................3 1.2 Packing List..................3 1.3 System Dissection ................4 2 Procedures of Assembly/Disassembly ........7 2.1 Installing the CF card ............... 7 2.2 Installing the Mini PCI-e interface card........... 9 2.3 Installing the DDR2 SO-DIMM procedures ........12 2.4 Assemble/Disassemble the DIN mounting bracket.

  • Page 3: Introduction To Ar-Es6050Fld

    Revision: 1.0 1 Introduction to AR-ES6050FLD AR-ES6050FLD is a fan-less embedded system that could be used by DIN mount for factory uses, VESA mount for medical/multimedia display and wall mount for automatic control. It is designed with Intel Atom N450 and supports up to 2GB of DDR2 memory.

  • Page 4: System Dissection

    Revision: 1.0 1.3 System Dissection Dimensions (2) Front Panel ANTENNA HOLE AUDIO LAN 1~2 USB 1~4 Power switch (3)System Configuration CF BKT Power LED TERMINAL BLOCK...
  • Page 5 Revision: 1.0 (3) System Configuration...
  • Page 6 Revision: 1.0 Item Description Quantity LEFT COVER PCI-104 CARD DIN MOUNTING BRACKET PCI-104 TAIL CONNECTOR BASE AR-B6050 HEAT COLUMN POWER BOARD BRACKET AR-PW9427B 10 HEAT PLATE 11 SWITCH BUTTON 12 CF CARD BRACKET 13 BASE DDR DOOR...

  • Page 7: Procedures Of Assembly/Disassembly

    Revision: 1.0 2 Procedures of Assembly/Disassembly 2.1 Installing the CF card 1. Unfasten two screws of CF bracket and then take out the CF card bracket. Figure 1 2. Put the CF card into CF bracket (figure 2). Please note that the direction of CF card and CF bracket (figure 3). Figure 2 figure 3...
  • Page 8 Revision: 1.0 3. Push CF card to the bottom of bracket to stop the forwarding at the bend of bracket. Figure 4 4. Push them into the CF slot of system machine and then fasten the two original screws to fix CF bracket.

  • Page 9: Installing The Mini Pci-E Interface Card

    Revision: 1.0 2.2 Installing the Mini PCI-e interface card 1. Unfasten the six screws to take out the heat sink cover. Figure 6 2. Maybe you need to force open the heat sink cover. Figure 7...
  • Page 10 Revision: 1.0 3. Align the notch key on the Mini PCI-e card with rib on the slot. Figure 8 4. Push Mini PCI-e card horizontally Figure 9...
  • Page 11 Revision: 1.0 5. Using two M2 screws to fasten Mini PCI-e card. Figure 10 6. Close the heat sink cover using the original screws to fasten heat sink cover and base. (Please refer to figure 6)

  • Page 12: Installing The Ddr2 So-Dimm Procedures

    Revision: 1.0 2.3 Installing the DDR2 SO-DIMM procedures 1. Unfasten the screw of the DDR cover and open the cover. Figure 11 2. Align the notch key on DDR2 SO-DIMM with rib on the DDR2 socket. Figure 12...
  • Page 13 Revision: 1.0 3. Push DDR2 SO-DIMM horizontally and make sure it is locked by hooks of two sides of DDR2 socket. Figure 13 4. Recover the DDR cover and fasten it with the screw.

  • Page 14: Assemble/Disassemble The Din Mounting Bracket

    2.4 Assemble/Disassemble the DIN mounting bracket. 1. Hook the spring of the DIN mounting bracket onto the upper of DIN rail. Figure 14 2. Press down the AR-ES6050FLD system machine and push it forward lightly. STEP 1 STEP 2 Figure 15...
  • Page 15 Revision: 1.0 3. Make sure they are locked together. Figure 16 4. Disassemble the DIN mounting bracket of AR-ES6050FLD system. Press down the AR-ES6050FLD system machine and pull it back lightly. STEP 1 STEP 2 Figure17...

  • Page 16: Appendix

    Revision: 1.0 3 Appendix Cable Pin Define 1. Com cable 110mm 2. Power Cable BLACK BLACK YELLOW YELLOW...
  • Page 17 Revision: 1.0 3. Switch Cable...

  • Page 18: Ar-B6050 Board Guide

    Revision: 1.0 4 AR-B6050 Board Guide 4.1 Block Diagram...
  • Page 19 Revision: 1.0 AR-B6050 Board Specifications  Intel Atom N450 1.66GHz  Intel Graphics Media Accelerator 950  1 x SO-DIMM supports DDRII up to 2GB(Memory DDR2 data transfer rates of 667 MT/s) 1 x VGA   4 x USB2.0 ...

  • Page 20: Ar-B6050 H/W Information

    Revision: 1.0 4.2 AR-B6050 H/W Information This section describes the installation of AR-B6050. At first, it shows the Function diagram and the layout of AR-B6050. It then describes the unpacking information which you should read carefully, as well as the jumper/switch settings for the AR-B6050 configuration.
  • Page 21 Revision: 1.0 4.2.2 AR-B6050 LAYOUT (Bottom side) SODIMM1...

  • Page 22: Components And Jumps Setting List

    Revision: 1.0 4.3 Components and Jumps Setting List 1. JP1: LCD panel driving 2. ATX1: AT power input 3. BAT1: CMOS battery holder. voltage selection. connector. SETTING STATUS SETTING +3.3V CMOS battery holder. (Default). +12V +12V 4. SYSFAN1: System DC 5.
  • Page 23 Revision: 1.0 10. COM1: RS232 signal 11. COM2: RS232 signal 12. SATA1: SATA device connector for port #1. connector for port #2. connector #1. PIN SETTING PIN SETTING PIN SETTING PIN SETTING DCD #1 DSR #1 DCD #2 DSR #2 RX #1 RTS #1 RX #2...
  • Page 24 Revision: 1.0 19. VGA1: D-SUB-15 female 20. J1: CMOS data clear 21. USB3: Internal USB2.0 connector for VGA output. connector PIN SETTING PIN SETTING D-SUB-15 female connector USB5- USB6- SHORT CMOS data clear USB5+ USB6+ for VGA output. 22. USB1: USB connector 23.
  • Page 25 Revision: 1.0 27. DIMM1: DDR-II SODIMM 28. CF1: Type-II compact flash Socket. card socket. DDR-II SODIMM +3.3V CF card only and Socket. UDMA mode supported.

  • Page 26: Bios Setting

    Revision: 1.0 4.4 BIOS Setting The BIOS Setup Utility is a hardware configuration program built into your computer’s BIOS. To activate the BIOS Utility, press F2 during POST (when “Press <F2> to enter Setup” message is prompted on the bottom of screen). Press <F12> during POST to enter multi-boot menu.
  • Page 27 Revision: 1.0 4.4.1 Main Setup Once you enter the InsydeH2O BIOS™ Setup Utility, the Main Menu will appear on the screen. Use the arrow keys to highlight the item and then use the <F5> <F6> keys to select the desired value in each item. Note: The control keys are listed at the bottom of the menu.
  • Page 28 Revision: 1.0 This field displays the cache ram of the Cache RAM CPU. Displays the total memory available. Total Memory This field displays the memory of the SODIMM 0 SODIMM0. Displays system BIOS version. BIOS Revision...
  • Page 29 Revision: 1.0 4.4.2 Advanced Chipset Setup Note: The control keys are listed at the bottom of the menu. If you need any help with the item fields, you can press the <F1> key, and the relevant information will be displayed. Item Option Description...
  • Page 30 Revision: 1.0 4.4.3 Security Setup Note: The control keys are listed at the bottom of the menu. If you need any help with the item fields, you can press the <F1> key, and the relevant information will be displayed. Item Option Description Not Installed...
  • Page 31 Revision: 1.0 Setting a Password Follow these steps as you set the user or the supervisor password: 1. Use the ↑ and ↓ keys to highlight the Set Supervisor Password parameter and press the Enter key. The Set Supervisor Password box appears: 2.
  • Page 32 Revision: 1.0 4.4.4 Power Setup Note: The control keys are listed at the bottom of the menu. If you need any help with the item fields, you can press the <F1> key, and the relevant information will be displayed. Item Option Description Enabled...
  • Page 33 Revision: 1.0 4.4.5 Boot Setup Note: The control keys are listed at the bottom of the menu. If you need any help with the item fields, you can press the <F1> key, and the relevant information will be displayed. Item Option Description Select Boot Devices to select specific...
  • Page 34 Revision: 1.0 4.4.6 Exit Setup Note: The control keys are listed at the bottom of the menu. If you need any help with the item fields, you can press the <F1> key, and the relevant information will be displayed. Item Option Description Exit Saving...

  • Page 35: Watchdog, Gpio, And Bypass Programming

    Revision: 1.0 4.5 WATCHDOG, GPIO, AND BYPASS PROGRAMMING 4.5.1 Watchdog Programming This section describes the usage of WATCHDOG. AR-B6050 integrated the WATCHDOG that enable user to reset the system after a time-out event. User can use a program to enable the WATCHDOG and program the timer in range of 1~255 second(s)/minute(s).
  • Page 36 Revision: 1.0 The WATCHDOG sample code of C language as below: //==================================================================== ======= // Rev Date Name Description //==================================================================== ======= // 1.0 12/16/2009 Willy W83627EHF WatchDog timer test //==================================================================== ======= //==================================================================== ======= // Language include files //==================================================================== ======= #include <conio.h> #include <stdlib.h>...
  • Page 37 Revision: 1.0 outportb(IO_Port_Address,0x2D); // Point to Global Reg. // Select Multi-Function pin, (Bit0=0 Watchdog Function) outportb(IO_Port_Address+1,(inportb(IO_Port_Address+1)&0xFE)); outportb(IO_Port_Address,0x07); // Point to Logical Device Number Reg. outportb(IO_Port_Address+1,0x08); // Select logical device 8, (Watchdog Function) outportb(IO_Port_Address,0x30); // Device Active register outportb(IO_Port_Address+1,0x01); outportb(IO_Port_Address,0xF5); // Select Watchdog count mode seconds or minutes outportb(IO_Port_Address+1,0x02);...
  • Page 38 Revision: 1.0 printf("( For 10 seconds to reset. )\n"); //==================================================================== =======...
  • Page 39 Revision: 1.0 4.5.2 GPIO Programming This section describes the usage of GPIOs. AR-B6050 integrated eight bits, 5V TTL level, bidirectional, and software programmable GPIOs for user’s application. They are all capable of 5 mA source current for output and 8 mA sink current for input individually. The electrical characteristics of GPIOs as following table: PIN SIGNAL PIN SIGNAL GPO0...
  • Page 40 ( argc > 1 ) { Show_Help(); return 1; } clrscr(); textcolor(WHITE); gotoxy(1, 1); cprintf("<>============================================================= =============<>"); gotoxy(1, 2); cprintf("|| W83627EHF GPIO Test Utility %s Acrosser Technology Co., Ltd. ||",Version); gotoxy(1, 3); cprintf("<>============================================================= =============<>"); gotoxy(1, 4); cprintf("<>============================================================= =============<>"); gotoxy(1, 5); cprintf("|| Model Name : ||");...
  • Page 41 Revision: 1.0 outportb(IO_PORT_BASE+1,(inportb(IO_PORT_BASE+1) | 0x01)); // Select GPIO Port device outportb(IO_PORT_BASE,0x07); outportb(IO_PORT_BASE+1,0x07); // Set GPIO Port Active outportb(IO_PORT_BASE,0x30); outportb(IO_PORT_BASE+1,0x01); // Set GPIO I/O Register to 00h outportb(IO_PORT_BASE,0xF3); outportb(IO_PORT_BASE+1,0x00); // Set W83627EHF GPIO10~13 to Output, GPIO14~GPIO17 to Input outportb(IO_PORT_BASE,0xF0); outportb(IO_PORT_BASE+1,0xF0); // Set W83627EHF GPIO10~13 to High outportb(IO_PORT_BASE,0xF1);...
  • Page 42 Revision: 1.0 // Exit W83627EHF Config outportb(IO_PORT_BASE,0xAA); if(result) Show_Fail(); else Show_Pass(); return result; //==================================================================== ======= // Function : Show_Help() // Input : - // Change // Return : - // Description : Show Title string. //==================================================================== ======= void Show_Help() clrscr(); printf("GPIO Test utility for W83627EHF\n\n");...
  • Page 43 Revision: 1.0 //==================================================================== ======= // Function : Show_Pass() // Input : - // Change // Return : - // Description : Show Pass Message. //==================================================================== ======= void Show_Pass() textcolor(LIGHTGREEN); gotoxy(20,10); cprintf(" 詗詗詗詗 詗詗詗 詗詗詗詗 詗詗詗詗"); gotoxy(20,11); cprintf(" 詗 "); 詗 詗 詗 詗 詗...
  • Page 44 檔名: ES6050_M10_0820_10am.doc 目錄: Z:\共用區\RD 交流區\Manual 暫存區(勿刪) 範本: C:\Documents and Settings\Roger_Nan\Application Data\Microsoft\Templates\Normal.dot 標題: AR-ES0631 主旨: 作者: 關鍵字: 註解: 建立日期: 2010/8/20 9:46:00 AM 修訂版編號: 前次更新日期: 2010/8/20 9:54:00 AM 前次存檔人員: Roger_Nan 編輯總時間: 9 分鐘 最後列印在: 2010/8/20 9:54:00 AM 最後列印的字數 頁數: 字數: 4,128 (約) 字元數: 23,532 (約)
