- Page 1 Revision: 1.0 AR-ES5432FL Installation Guide Revision Description Date Release 2009/11/19...
-
Page 2: Table Of Contents
Revision: 1.0 Contents Introduction to AR-ES5432FL ..............3 Specifications....................3 Packing List......................3 Procedure of Assembly/Disassembly........... 7 2.5” Hard Disk Installation................7 Accessory (CF card, Outline bracket) Installation ........14 Appendix ....................17... -
Page 3: Introduction To Ar-Es5432Fl
Revision: 1.0 1 Introduction to AR-ES5432FL AR-ES5432FL is a Fan-less system product mainly for general industry PC applications. With powerful Intel CPU core & diverse memory card extension (CF card, SO-DIM), AR-ES5432FL can satisfy the users requirements in any general industry applications environment, especially in 0 to 60 environment fields. - Page 4 Revision: 1.0 System Dissection (1) Dimensions AR-ES5432FL 2D Overview (2) Front Panel “I/O” DVI-inlet S-Video LAN1/LAN2 Audio/Remote Antenna DC Inlet Power Switch CF Card inlet COM1/COM2/COM3/COM4 USB/ HDD&POWER LED...
- Page 5 Revision: 1.0 (3) System Configuration...
- Page 6 Revision: 1.0 Item Description Quantity AR-B5432 PW-V9427B WiFi Module(Option) PC104 Card(Option) Heatsink (for CPU/NB/SB) Upper Case(including Corners) Bottom Case(including I/O) HDD Module Mounting Bracket HDD Door CF Card Bracket...
-
Page 7: Procedure Of Assembly/Disassembly
Revision: 1.0 2 Procedure of Assembly/Disassembly 2.1 2.5” Hard Disk Installation The following instructions will guide you to install HDD step-by-step. 1. Remove the terminal plug from the AR-ES5432FL. 2. Unfasten the screw from top cover of AR-ES5432FL. Unscrew... - Page 8 Revision: 1.0 Remove top cover by below photo direction. Push Remove Push 4. Plug SATA cable and power cable into mainboard. SATA Power connecter SATA Connecter...
- Page 9 Revision: 1.0 Run the cables through gateway to back side. Cables gateway Unfasten the screws from HDD door. Unfasten the screws!!
- Page 10 Revision: 1.0 Unfasten four screws below to release HDD bracket. Unfasten the screws!! Insert the rubbers into the HDD bracket. Install the rubbers on the HDD bracket.
- Page 11 Revision: 1.0 9. Place HDD body into HDD bracket and assemble HDD and bracket by 4 screws. Screws up Insert SATA connecter and SATA power cable into HDD module.
- Page 12 Revision: 1.0 11. Place HDD module back into the case. 12. Fix HDD module to the chassis by four screws. The installing of bracket for HDD 13. Assemble HDD door back by four screws. Fasten the screws...
- Page 13 Revision: 1.0 14. Slide the top cover into the bottom case. Pay attention to make sure top cover has been installed into the notch! 15. Finish the HDD installation after fastening the screw. Push Fasten the screw Push...
-
Page 14: Accessory (Cf Card, Outline Bracket) Installation
Revision: 1.0 2.2 Accessory (CF card, Outline bracket) Installation Install CF Card 1. Remove the extending CF’s bracket by unfastening the screws. Unfasten the screws 2. Install CF card into bracket. The direction for installing the CF card. - Page 15 Revision: 1.0 Install CF card module back to CF socket. The direction for installing the CF card module. Install Outline Bracket 1. Install Outline Bracket with case by 4 screws.
- Page 16 Revision: 1.0 2.3 WiFi Modules Installation 1. After WiFi bracket release, please assemble WiFi with bracket by fastening 2 screws. 2. Place WiFi modules back to below location and fix it by two screws.
-
Page 17: Appendix
Revision: 1.0 3 Appendix Please don’t change SO-DIMM by yourself. Any disassembly and assembly behavior for the SO-DIMM will cause unexpected damage. Please do contact with Acrosser customer service center/FAE of changing SO-DIMM. Please DON’T disassemble and assemble the SO-DIMM by yourself...
