- Page 1 AIV-TGH7Ex AIV-TGH7Ex In-Vehicle Computer ® Intel Core™ Xeon, i7, i5, i3 Processor (Tiger Lake Platform) User Manual Acrosser Technology Co., Ltd. www.acrosser.com...
- Page 2 Acrosser Technology Co., Ltd. In no event will Acrosser Technology Co., Ltd. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
-
Page 3: Table Of Contents
AIV-TGH7Ex Table of Contents 1. Introduction ..............5 1.1. Specifications ......................5 1.2. Packing List ........................ 7 1.3. System Dissection ...................... 8 1.3.1. Dimensions ..................... 8 1.3.2. Front I/O Panel ....................9 1.3.3. Rear I/O Panel ....................11 2. Power Subsystem ............13 2.1. - Page 4 4.4.1. Trusted Computing ..................40 4.4.2. Secure Boot ....................41 4.5. Boot Setup ........................ 42 4.6. Save & Exit Setup..................... 43 5. FAQ ................44 Q 1. Where can I find the serial number of this product? ..........44 Acrosser Technology Co., Ltd.
-
Page 5: Introduction
AIV-TGH7Ex Introduction ® AIV-TGH7Ex Series adopt the newest Intel 11th Gen. Tiger Lake H high- performance platform for wide operation temperature in-vehicle computers. ® Powered by the latest 11th Gen Intel Core™ i7/i5 Processor, HYPERLINK "https:// www.acrosser.com/en/Products/In-Vehicle-Computer/In-Vehicle-PCs/AIV-TGH7EX" AIV-TGH7Ex Series delivers high-performance data computing, and the newest ®... - Page 6 5% to 95% Humidity, non-condensing Vibration • IEC 60068-2-64 • SSD: 5Grms, 5Hz to 500Hz, 3 Axis Shock • IEC 60068-2-27 • SSD: 50G @ wallmount, Half-sine, 11ms Certification • CE / FCC class A/ E-Mark Acrosser Technology Co., Ltd.
-
Page 7: Packing List
AIV-TGH7Ex 1.2. Packing List Check if the following items are included in the package. Item Q’ty AIV-TGH7Ex � 3-Pin Terminal Block � M.2 / Mini PCIE Screw Pack � HDMI Locking Bracket � www.acrosser.com... -
Page 8: System Dissection
AIV-TGH7Ex 1.3. System Dissection 1.3.1. Dimensions (Unit: mm) 276.00 248.00 220.00 (The peripherals shown in this layout dimensions are used for illustration only, may not come with the package.) Acrosser Technology Co., Ltd. -
Page 9: Front I/O Panel
AIV-TGH7Ex 1.3.2. Front I/O Panel Line In, Line Out, MIC LINE IN: Audio input jack. LINE OUT: Audio output jack. MIC: Microphone input jack. DP1, DP2 DP Connector (Standard Specification) HDMI Pin # Signal Pin # Signal DATA2+ DATA2- DATA1+ DATA1- DATA0+ DATA0-... - Page 10 Pin # Signal Pin # Signal VCC5 SS_RX - DATA- SS_RX + DATA+ SS_TX - SS_TX + Status/HDD/Power LED Indicator Light Display Yellow Power Green SATA Device Activity Green Status COM3, COM4 Pin # RS-232 Signal Acrosser Technology Co., Ltd.
-
Page 11: Rear I/O Panel
AIV-TGH7Ex Power Button You may use a thin and long object to reach into the hole and push the button in. HDD-1 ~ HDD-2 HDD bays reserved for installation of your 2.5" hard disks (H: 7mm). 1.3.3. Rear I/O Panel POWER DC power input connector Pin #... - Page 12 Pin # RS-232 Signal RS-422 Signal RS-485 Signal RS-422_TX- RS-485_D- RS-422_TX+ RS-485_D+ RS-422_RX+ RS-422_RX- +5V/+12V +5V/+12V (0.5A) (0.5A) Pin # Pin Name Signal Type Signal Level DIO_1 DIO_2 DIO_3 DIO_4 DIO_5 DIO_6 DIO_7 DIO_8 DIO_9 DIO_10 DIO_11 DIO_12 DIO_13 DIO_14 DIO_15 DIO_16 Acrosser Technology Co., Ltd.
-
Page 13: Power Subsystem
AIV-TGH7Ex Power Subsystem This section describes the Smart ATX mode selection by the SW1 switch on power board model AR-PW0932V. (Not implement remote switch control function in this version.) Refer to bellow smart mode table: Power On Power Off Switch 1 Switch 2 Switch 3 Switch 4... -
Page 14: Mode Description
C. AR-PW0932V will ignore the status change of ignition after “ON/OFF Control” “OFF” pulse is send to motherboard for 3 minutes. After this period, the AR- PW0932V will start to check its status. This can avoid an improper “OFF” process before the OS is complete booted. Acrosser Technology Co., Ltd. -
Page 15: Led Indication
AIV-TGH7Ex 2.2. LED Indication Mode 0 and 1: LED will be constant ON when power output is ON. LED will be constant OFF when power output is off. Mode 2 to 15 (Smart ATX mode): The LED will flash a number of blinks to state the status. Each blink remains 500 milliseconds ON followed by a 500 ms OFF. -
Page 16: Components Assembly
As shown in the red circle, slide the door buckle to the right to take out the SSD tray. Step 2: Follow the deployment direction to insert the SSD. Please pay attention to the insertion direction. The red circle chown is a hollow hole. Acrosser Technology Co., Ltd. - Page 17 AIV-TGH7Ex Step 3: Place the SSD firmly into position. The 2 screws provided in the accessories package is used for spare only. Step 4: Insert the SSD tray into the system and press the part shown with red circle to attach with the system. www.acrosser.com...
-
Page 18: Antenna Connection
Connect your antennas needed according to your system configuration. You will have to match the gender in connecting antenna plug with socket. Connect a male type antenna to the female type socket (GPS): Connect a female type antenna to the male type socket (WiFi/BT): Acrosser Technology Co., Ltd. -
Page 19: Pcb Parts Description
AIV-TGH7Ex 3.3. PCB Parts Description Connect your antennas needed according to your system configuration. • CN39: NANO SIM Card Socket Install NANO SIM card here. • CN40: DDR4 SO-DIMM Slot When installing memory module, please note that both ends of the memory and solt are firmly attached. -
Page 20: Foot-Bracket Assembly
AIV-TGH7Ex 3.4. Foot-bracket Assembly Step 1: Attach two brackets with screws to each side of the body. Step 2: Attach four rubber pads to the bracket holes. Acrosser Technology Co., Ltd. -
Page 21: Hdmi Cable Connection
AIV-TGH7Ex 3.5. HDMI Cable Connection You can find in the package an HDMI locking-bracket set. This gaget is designed to secure your HDMI cable connection. Step 1: Lock the HDMI locking-bracket with the two black screws that came with the package. www.acrosser.com... - Page 22 AIV-TGH7Ex Step 2: Plug your HDMI cable head into the HDMI socket. Firmly push the HDMI cable all the way into the socket. Acrosser Technology Co., Ltd.
- Page 23 AIV-TGH7Ex Step 3: Fasten the HDMI cable-end with a cable-holder. Lock the cable-end to the bracket with this cable-holder by two screws that came with the package. (There are two types of cable-holder provided: 4mm and 7mm. Use the type 4mm for HDMI cable of thinner than 6mm in diameter. Use the type 7mm for HDMI cable of thicker than 6mm in diameter.) Choose the holes that allows the screw to lock the cable-end with cableholder.
-
Page 24: Bios Settings
System Time using the arrow keys. Enter new values using the keyboard. Press the key or the arrow keys to move between fields. The date must be entered in MM/DD/ YYYY format. The time is entered in HH:MM:SS format. Acrosser Technology Co., Ltd. -
Page 25: Advanced Setup
AIV-TGH7Ex 4.2. Advanced Setup Aptio Setup - AMI Main Advanced System I/O Security Boot Save & Exit Display Information Graphics Configuration Graphics Configuration System Information CPU Configuration Memory Configuration Hardware Monitor PCH-FW Configuration NVMe Configuration Power Management BIOS Robot →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. -
Page 26: Advanced Setup: Cpu Configuration
When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology. • Intel(R) SpeedStep(tm) Allows more than two frequency ranges to be supported. • Turbo Mode Enable/Disable processor Turbo Mode (requires EMTTM enabled too). Auto means enabled. Acrosser Technology Co., Ltd. -
Page 27: Advanced Setup: Memory Configuration
AIV-TGH7Ex 4.2.3. Advanced Setup: Memory Configuration Aptio Setup - AMI Advanced Memory Configuration Memory RC Version 2.0.2.0 Memory Speed 3200 MT/s →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save &... -
Page 28: Advanced Setup: Pch-Fw Configuration
↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.21.1278 Copyright (C) 2022 AMI • Firmware Update Configuration Configure Management Engine Technology Parameters. Acrosser Technology Co., Ltd. -
Page 29: Advanced Setup: Nvme Configuration
AIV-TGH7Ex 4.2.6. Advanced Setup: NVMe Configuration Aptio Setup - AMI Advanced NVMe Configuration 15.0.35.1951 No NVMe Device Found →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.21.1278 Copyright (C) 2022 AMI •... -
Page 30: Advanced Setup: Bios Robot
WDT. Also, this function should be disabled if OS is going to update itself. • Delayed POST (PEI phase) Enabled - ROBOT holds BIOS from starting POST right after power on. This allows BIOS POST to start with stable power or start after system is physically warmed-up. Acrosser Technology Co., Ltd. -
Page 31: System I/O Setup
AIV-TGH7Ex Note: ROBOT does this before ‘Sends watch dog’. • Delayed POST (DXE phase) Enabled - ROBOT holds BIOS before POST completion. This allows BIOS POST to start with stable power or start after system is physically warmed-up. Note: ROBOT does this after ‘Sends watch dog before BIOS POST’. •... -
Page 32: System I/O Setup: Pci Express Configuration
[Enabled] Hot Plug [Disabled] →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.21.1278 Copyright (C) 2022 AMI Acrosser Technology Co., Ltd. -
Page 33: System I/O Setup: Hd Audio Configuration
AIV-TGH7Ex • SATA Controller(s) Enable/Disable SATA Device. • Port 0 Enable/Disable SATA Port. • Hot Plug Designates this port as Hot Pluggable. 4.3.3. System I/O Setup: HD Audio Configuration Aptio Setup - AMI System I/O HD Audio Configuration Settings Control Detection of the HD-Audio device. -
Page 34: System I/O Setup: Digital Io Port Configuration
[Input] F4: Save & Exit DIO16 [Input] ESC: Exit Version 2.21.1278 Copyright (C) 2022 AMI • DIO1 ~ DIO16 Set DIO as Input or Output. • Output Level Set output level when DIO pin is output. Acrosser Technology Co., Ltd. -
Page 35: System I/O Setup: Legacy Logical Devices Configuration
AIV-TGH7Ex 4.3.5. System I/O Setup: Legacy Logical Devices Configuration Aptio Setup - AMI System I/O AMI SIO Driver Version : A5.16.00 View and Set Basic properties of the SIO Super IO Chip Logical Devices Configuration Logical device. [*Active*] Serial Port 1 Like IO Base, IRQ Range, [*Active*] Serial Port 2 DMA Channel and Device... -
Page 36: System I/O Setup: Serial Port Consol Redirection
F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.21.1278 Copyright (C) 2022 AMI • Console Redirection Console Redirection Enable or Disable. • Console Redirection EMS Console Redirection Enable or Disable. Acrosser Technology Co., Ltd. -
Page 37: System I/O Setup: Vmd Setup Menu
AIV-TGH7Ex 4.3.7. System I/O Setup: VMD setup menu Aptio Setup - AMI System I/O VMD Configuration Enable/Disable to VMD controller Enable VMD controller [Disabled] →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save &... -
Page 38: System I/O Setup: Intel(R) Ethernet Controller
Full Size Minicard Slot(CN4) →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.21.1278 Copyright (C) 2022 AMI Acrosser Technology Co., Ltd. -
Page 39: Security Setup
AIV-TGH7Ex • MiniCard Slot Function Select function enabled for Full Size Minicard Slot(CN4). 4.4. Security Setup Aptio Setup - AMI Main Advanced System I/O Security Boot Save & Exit Password Description Set Administrator Password If ONLY the Administrator’s password is set, then this only limits access to Setup and is only asked for when entering Setup. -
Page 40: Trusted Computing
• Platform Hierarchy Enable or Disable Platform Hierarchy. • Storage Hierarchy Enable or Disable Storage Hierarchy. • Endorsement Hierarchy Enable or Disable Endorsement Hierarchy. • TPM 2.0 UEFI Spec Version Select the TCG2 Spec Version Support. Acrosser Technology Co., Ltd. -
Page 41: Secure Boot
AIV-TGH7Ex TCG_1_2: The Compatible mode for Win8/Win10. TCG_2: Support new TCG2 protocol and event format for Win10 or later. • Physical Presence Spec Version Select to tell O.S. to support PPI Spec Version 1.2 or 1.3. Note some HCK tests might not support 1.3. -
Page 42: Boot Setup
F4: Save & Exit ESC: Exit Version 2.21.1278 Copyright (C) 2022 AMI • Quiet Boot Enabled or disables Quiet Boot option. • Network Stack Enable/Disable UEFI Network Stack. • Boot Option #1 Set the system boot order. Acrosser Technology Co., Ltd. -
Page 43: Save & Exit Setup
AIV-TGH7Ex 4.6. Save & Exit Setup Aptio Setup - AMI Main Advanced System I/O Security Boot Save & Exit Save Options Reset the system after saving the changes. Save Changes and Reset Discard Changes and Reset Default Options Restore Defaults →←: Select Screen ↑↓: Select Item Enter: Select... -
Page 44: Faq
Q 1. Where can I find the serial number of this product? • The serial number (S/N) is a label printed with alpha-numeric character. You can find the S/N label on the bottom of this product or on its packing box. Acrosser Technology Co., Ltd. - Page 45 AIV-TGH7Ex Technical Support Form We deeply appreciate your purchase of Acrosser products. Please find the “tech_form. doc” file in our utility CD. If you have any questions or problems about Acrosser products, please fill in the following information. We will answer your questions in the shortest time possible.
- Page 46 Acrosser Headquarters Acrosser Nanjing Office 欣扬通电子有限公司 南京办事处 241402新北市三重區重新路5段609巷4號3樓之8 江苏省南京市江宁区天元东路228号504室 Rm. 8, 3F., No. 4, Ln. 609, Sec. 5, Chongxin Rd., (邮编: 211100) Sanchong Dist., New Taipei City 241402, Taiwan Room 504, No. 228, Tian Yuan East Rd., (R.O.C.) Jiang Ning Dist., Nanjing City, Jiangsu Province, TEL: +886-2-29999000 China (Postal: 211100) FAX: +886-2-29992887...
