  • Page 1 AND-DNV3N2FL AND-DNV3N2FL Networking Desktop ® ® Intel Denverton 4GbE Copper (2-pair bypass) 2GbE Copper (or Fibber) User Manual Acrosser Technology Co., Ltd. www.acrosser.com...
  • Page 2 Acrosser Technology Co., Ltd. In no event will Acrosser Technology Co., Ltd. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 3: Table Of Contents

    AND-DNV3N2FL Table of Contents 1. System Introduction ..............5 1.1. Specifications ......................5 1.2. Package Contents ...................... 7 1.3. System Dissection ...................... 8 1.3.1. Dimensions ..................... 8 1.3.2. Front I/O Panel ....................10 1.3.3. Rear I/O Panel ....................11 2. Components Assembly ............... 12 2.1.
  • Page 4 4.3.3. LAN Bypass Subsystem ................37 4.3.4. Notes ......................38 5. FAQ ....................39 Q 1. Where is the serial number located on my system? ..........39 Q 2. Why does the system booting take so long? ............39 Acrosser Technology Co., Ltd.

  • Page 5: System Introduction

    AND-DNV3N2FL System Introduction The AND-DNV3N2FL series is a fanless version of AND-DNV3N2, a small form factor network appliance. They both equipped with the latest Intel microserver SoC Atom C3558 (4 core). AND-DNV3N2/ AND-DNV3N2FL series provides a more flexible system expansion versatility with 6x or 4x GbE copper LANs (with 2-pair bypass), optional 2x 1G fiber networks (SFP).
  • Page 6 Relative Humidity • 10 to 80%, non-condensing Anti-Vibration • IEC 60068-2-64, 5~500Hz, 3GRMS Anti-Shock • 10 G peak acceleration (11 m sec. duration), operation Certification • CE, FCC Class A, RoHS 2 Drop Test • ISTA-2A 2006 Acrosser Technology Co., Ltd.

  • Page 7: Package Contents

    AND-DNV3N2FL 1.2. Package Contents Check if the following items are included in the package. Item Q’ty AND-DNV3N2FL-04PC � or AND-DNV3N2FL-04PF Driver CD � Console Cable � 40W Power Adapter � Power Cord � Screw Pack � SATA & SATA power cable �...

  • Page 8: System Dissection

    AND-DNV3N2FL 1.3. System Dissection 1.3.1. Dimensions (Unit: mm) AND-DNV3N2FL-04PC Acrosser Technology Co., Ltd.
  • Page 9 AND-DNV3N2FL AND-DNV3N2FL-04PF www.acrosser.com...

  • Page 10: Front I/O Panel

    AND-DNV3N2FL 1.3.2. Front I/O Panel ANT1, ANT2 SMA Antenna Hole Reserved for optional Wi-Fi / BT, 4G LTE antenna. LED1~6 LAN1~6 Link/Active LED BP1, BP2 LAN Bypass LED Storage Active LED STATUS Status LED Power LED Acrosser Technology Co., Ltd.

  • Page 11: Rear I/O Panel

    AND-DNV3N2FL-04PF ANT3, ANT4 SMA Antenna Hole Reserved for optional Wi-Fi / BT, 4G LTE antenna. POWER Power Button LAN1, LAN2 RJ45 LAN Port (AND-DNV3N2FL-04PC) SFP1, SFP2 SFP LAN Port (AND-DNV3N2FL-04PF) LAN3~LAN6 RJ45 LAN Port with Bypass USB 3.0 Port CONSOLE...

  • Page 12: Components Assembly

    AND-DNV3N2FL Components Assembly Please follow the instruction to install the inner modules. 2.1. System Disassemble Step 1: Loosen the two screws that lock the bottom cover. Step 2: Turn the system upside down. Acrosser Technology Co., Ltd.
  • Page 13 AND-DNV3N2FL Step 3: Remove the bottom cover. Step 4: It is suggested to remove the RF cable first if there were modules installed. www.acrosser.com...

  • Page 14: Sim / Dimm Installation

    AND-DNV3N2FL 2.2. SIM / DIMM Installation Step 1: Install your SIM card. Step 2: Install your DIMM card. Step 3: Loosen the four screws that lock the hard disk holder. Acrosser Technology Co., Ltd.

  • Page 15: Hdd Installation

    AND-DNV3N2FL Step 4: Use the washers and screws to assemble your hard disk to the holder. 2.3. HDD Installation Step 1: Now ready to install your hard disk. Step 2: Install your HDD and holder assembly to the bottom cover.
  • Page 16 Step 3: It is suggested to lock the screws by the order from 1 ~ 4. Step 4: Connect the HDD data and power cable. Put the RF cable back to its position and have it locked. Acrosser Technology Co., Ltd.

  • Page 17: System Assemble

    AND-DNV3N2FL 2.4. System Assemble Step 1: Arrange the cables. Step 2: Put the bottom cover back to the system. Step 3: Turn the system over to its upright position, and lock the cover with screws. www.acrosser.com...

  • Page 18: Antenna Installation

    Antenna Installation Step 1: Connect the antenna to the socket. Connect the SMA male antenna to the female socket. Step 2: Connect the antenna to the socket. Connect the SMA female antenna to the male socket. Acrosser Technology Co., Ltd.

  • Page 19: Bios Settings

    AND-DNV3N2FL BIOS Settings This chapter describes the BIOS menu displays and explains how to perform common tasks needed to get the system up and running. It also gives detailed explanation of the elements found in each of the BIOS menus. The following topics are covered: •...

  • Page 20: Advanced Setup

    Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.19.1266. Copyright (C) 2018 American Megatrends, Inc. • Case Open Warning Case Open detecting function. Acrosser Technology Co., Ltd.

  • Page 21: Advanced Setup: Trusted Computing

    AND-DNV3N2FL 3.2.1. Advanced Setup: Trusted Computing Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Advanced TPM20 Device Found Enables or Disables BIOS Vendor: IFX support for security Firmware Version: 5.51 device. O.S. will not show Security Device. Security Device Sup...

  • Page 22: Advanced Setup: Serial Port Console Redirection

    Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.19.1266. Copyright (C) 2018 American Megatrends, Inc. • Console Redirection Console Redirection Enable or Disable. Acrosser Technology Co., Ltd.

  • Page 23: Advanced Setup: Usb Configuration

    AND-DNV3N2FL 3.2.3. Advanced Setup: USB Configuration Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Advanced USB Configuration Enables Legacy USB support. AUTO option USB Controllers: disables legacy support 1 XHCI if no USB devices are USB Devices connected. DISABLE option...

  • Page 24: Advanced Setup: Sdio Configuration

    Version 2.19.1266. Copyright (C) 2018 American Megatrends, Inc. • Mass storage device emulation type Mass storage device emulation type. ‘AUTO’ enumerates devices less than 530MB as floppies. Forced FDD option can be used to force HDD formatted drive to boot as FDD. Acrosser Technology Co., Ltd.

  • Page 25: Advanced Setup: Sio Configuration

    AND-DNV3N2FL 3.2.5. Advanced Setup: SIO Configuration Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Advanced A5.07.03 View and Set Basic AMI SIO Drive Version: properties of the SIO Super IO Chip Logical device(s) Configuration Logical device. Like IO...

  • Page 26: Advanced Setup: Lan Bypass Configuration

    Configure LAN kit behavior when system in power-on state. (Bypass/Pass Through) • Mode for Power-off Configure LAN kit behavior when system in power-off state. (Bypass/Pass Through) • WDT Configuration Configure LAN kit behavior when WDT is triggered. (Bypass/Pass Through) Acrosser Technology Co., Ltd.

  • Page 27: Advanced Setup: Power Management

    AND-DNV3N2FL 3.2.8. Advanced Setup: Power Management Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Advanced Power Management Select system power mode. Power Mode [ATX Type] Restore AC Power Loss [Always Off] Wake Events RTC wake system from S5 [Disabled] →←: Select Screen...

  • Page 28: Advanced Setup: Digital Io Port Configuration

    Version 2.19.1266. Copyright (C) 2018 American Megatrends, Inc. • DIO Port1~4 Set DIO as Input or Output. • Output Level Set output level when DIO pin is output. • DIO Port5~8 Set DIO as Input or Output. Acrosser Technology Co., Ltd.

  • Page 29: Security Setup

    AND-DNV3N2FL 3.3. Security Setup Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Main Advanced Security Boot Save & Exit IntelRCSetup Password Description Set Administrator Password If ONLY the Administrator’s password is set, then this only limits access to Setup and is only asked for when entering Setup.

  • Page 30: Boot Setup

    Version 2.19.1266. Copyright (C) 2018 American Megatrends, Inc. • Quiet Boot Enable / Disable Quiet Boot option. • Launch PXE Rom Controls the execution of UEFI and Legacy PXE OpROM. • Boot Option #1 Sets the system boot order. Acrosser Technology Co., Ltd.

  • Page 31: Save & Exit Setup

    AND-DNV3N2FL 3.5. Save & Exit Setup Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc. Main Advanced Security Boot Save & Exit IntelRCSetup Save Options Reset the system after saving the changes. Save Changes and Exit Discard Changes and Exit...

  • Page 32: Intelrcsetup

    Turbo [Enable] →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.19.1266. Copyright (C) 2018 American Megatrends, Inc. Acrosser Technology Co., Ltd.

  • Page 33: Intelrcsetup: Server Me Configuration

    AND-DNV3N2FL • EIST Enable/Disable EIST. GV3 and TM1 must be enabled for TM2 to be available. GV3 must be enabled for Turbo. Auto - Enable for B0 CPU stepping, all others disabled, change setting to override. • Turbo Mode Enable or Disable CPU Turbo capability. This option only applies to ES2 and above.

  • Page 34: Intelrcsetup: North Bridge Chipset Configuration

    SATA Configuration →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.19.1266. Copyright (C) 2018 American Megatrends, Inc. Acrosser Technology Co., Ltd.

  • Page 35: Software Installation And Programming Guide

    4.1.1. Environment This test utility develop is based on kernel 4.8 above (Ubuntu 18.04.1 Server 64bit). 4.1.2. GPIO The AND-DNV3N2FL provides GPIO interface. Users can use the GPIO APIs to control GPO Pin. 4.1.3. Watchdog The AND-DNV3N2FL provides a Watchdog Timer. Users can use the Watchdog APIs to configure and to access the Watchdog timer.

  • Page 36: File Descriptions

    Get the status of GPIO output pins status. Parameters: This function fills in an integer variable as the parameter. The pin0 ~ pin1 is the status of the output pins. Return Value: 1: HIGH, 0: LOW. Acrosser Technology Co., Ltd.

  • Page 37: Watchdog

    AND-DNV3N2FL Syntax: Set_gpo(int pin, int value) Description: Set the status of GPIO output value. Parameters: Set value 0 is Low, 1 is High Return Value: If the function sets the values successfully, it returns 0 or -1, any other returned value stands for error.

  • Page 38: Notes

    Parameters: None. Return Value: 0: Successful, -1: Fail Syntax: void lib_close(void) Description: if watchdog, gpio fuction not use on your program, please call this function. Parameters: None. Return Value: None. Acrosser Technology Co., Ltd.

  • Page 39: Faq

    AND-DNV3N2FL Q 1. Where is the serial number located on my system? • The serial number (S/N) is an alpha-numeric character located on the bottom or side chassis. (for reference only) Q 2. Why does the system booting take so long? •...
