- Page 1 Revision: 1.0 AR-R8601 Installation Guide Revision Description Date Release 2012/3/27...
- Page 2 Revision: 1.0 Contents Introduction to AR-R8601 ....................3 Specifications ......................3 1.2 Packing List ......................4 1.3 System Dissection ....................4 2 Procedures of Assembly/Disassembly .................7 2.1 Installing the CF card…………………………………………………………………….7...
- Page 3 Base on VIA CN700 with ULV Eden 1600MHz CPU, the AR-R8601 general very low heat. We also put a quiet Fan to keep the low noise which will not cause uncomfortable voice. By three 10/100 Lans, the AR-R8601 is sufficient for the small business security hardware solution.
- Page 4 Revision: 1.0 1.2 Packing List Description Quantity AR-R8601 Console cable Software driver CD Quick user’s manual Power cord 1.3 System Dissection (1) Dimensions...
- Page 5 Revision: 1.0 (2) Front Panel USB*2 LAN1~3 COM PORT Back Panel POWER SWITCH...
- Page 6 Revision: 1.0 (3) System Configuration Item Description Quantity TOP COVER RAM SOCKET CF SOCKET POWER BOTTOM BASE...
- Page 7 Revision: 1.0 2 Procedures of Assembly/Disassembly 2.1 Installing the CF card. 1. Unfasten two screws of chassis top cover and open it. Unscrew Unscrew Unscrew two screws of chassis top cover (c) Open chassis top cover...
- Page 8 Revision: 1.0 2. Insert the CF card into the CF socket. 3. Finally, assemble the top cover and fasten it with screws.
