- Page 1 Dishwasher Model number：PL402XA...
-
Page 2: Control Panel
For detailed operating method read the corresponding content on the instruction manual. Switch on the appliance Press the On/Off button to switch on the appliance, Open the door. With each wash cycle. Compartment Fill the detergent dispenser For programmes with pre-wash only. (Follow the user instructions!) Check the rinse aid level Electric indicator on control panel (if provided). -
Page 3: Table Of Contents
Dear Customer, Please carefully read this manual bef ore using the Control Panel...........2 dishwasher, it will help you to use and maintain the Dishwasher Features........3 dishwasher properly. Keep it to refer to it at a later date. Pass it on to any subsequent owner of the appliance. 、... - Page 4 When using your dishwasher, follow the precautions listed below: This appliance must be grounded. In the event of a Improper connection of the equipment-grounding malfunction or breakdown, grounding will reduce conductor can result in the risk of an electric shock. the risk of anelectric shock by providing a path of Check with a qualified electrician or service least resistance of electric current.
- Page 5 To get the best performance from your dishwasher, read all operating instructions before using it for the first time. In tens ive Heavy R inse Normal R apid O F F 6 Tablet wash Function Button :To select Tablet wash functions.
-
Page 6: Cutlery Basket
Upper Basket Spray Arms Lower Basket Main Filter Detergent Dispenser Cup Shelf Cutlery Basket Coarse Filter Back View Rinse Aid Dispenser Drain pipe connector Inlet pipe connector... -
Page 7: Rinse Aid Dispenser
Before using your dishwasher for the first time: Fill the rinse aid disp ense r Fill in detergent Rinse Aid Dispenser The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. -
Page 8: Adjusting Rinse Aid Dispenser
To open the dispenser, turn the cap to the "open" (left) arrow and lift it out. Pour the rinse aid into the dispenser, being careful not to overfill. Replace the cap by inserting it aligned with "open" arrow and turning it to the closed (right) arrow. Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming during the next wash. -
Page 9: Wash Cycle Table
Normally new pulverised detergent is with out phosphate. Thus the water softener function of phosphate is not given. In this case we recommend to fill salt in the salt con taine r even when ° the hardness of water is only 6 dH. If dete rgents witho ut phosphate are used in the case of hard water often white spots appear on d ishes and glasses. -
Page 10: Fill In Detergent
Fill in Detergent Fill the detergent dispenser with detergent. The marking indicate s the dosing levels , as illustrate d on the righ t: The place of main wash cycle deterg ent placed , “ ” MIN me ans approximately 20g of detergent. The place of pre-wash cycle deterge nt placed , approximately 5g o f detergent Plea se o bserve the manufacturers dosing and storage... - Page 11 Consider buying utensils which are identified as dishwasher-proof. Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further information from the detergent manufacturers. For particular items, select a program with as low a temperature as possible. To prevent damage, take glass and cutlery out of the dis hwa sher as soon as possible after the program has ended.
- Page 12 The upper basket is designe d to hold more delica te and lighter dishware s uch as g lasses, coffee and tea cups and saucers, as well as plates, small bowls and shallow pans (as long as they are not too dirty ). Position the dishes and cookware so that they will not get moved by th e sp ray o f water.
- Page 13 The upper rack is for more delicate and lighter dishware such as glasses, coffee & tea cups, saucers, plates, bowls, and shallow pans (provided these are not too dirty). Position the dishes and cookware so that they do not get moved by the spray of water.
- Page 14 Means: need to fill rinse into the Rinse-Aid Dispenser. ℃ Pre-wash(50 ) For the heaviest soiled loads, Pre-wash such as pots,pans,casserole ℃ Wash (65 Intensive dishes and dishe s that have 5/27.5g. Rinse been sitting with dried food Rinse on them for a while. ℃...
-
Page 15: Unloading The Dishwasher
Draw out the lower and up per b asket, load the dishes and push them back. It is commended to lo ad the lower bask et first, then the upper one (s ee the sectio n entitled “ ” Loading the Dishwasher ). “... -
Page 16: Filter Assembly
The filter prevents larger remnants of food or other objects from getting inside the pum. The residues may block the filter, in this case they must be removed. The filter system consists of a coarse filter,a flat (Main filter) And a microfilter(Fine filter). Main filter Fo od and soil particles trap ped in this filter are pulverized by a specia l jet on the lower spray arm and washed down to drain. -
Page 17: Cleaning The Filter
Remarks: - Inspect the filters for blo cking a fter e very time the dishwa sher has been used. - By unscrewing the coarse filter, you can remove the filter system. Re move any foo d remna nts and clean the filters under running water. The entire filter assembly should be cleaned once a week. -
Page 18: Installation Preparation
After Every Wash When not in Use for a LongTime It is recommend that you run a was h cy cle with the After every wash, turn off the water supply to the dishwasher empty an d the n remove the plug from the appliance and leave the door slightly open so that socket, turn off the wa ter supply and leave the door of moisture and odours are not trapped inside. - Page 19 【 】 Figure1 90 ° 90 ° Cabinet dimensions Less than 5mm between the top 820mm of dishwasher and 600mm Electrical, drain and cabinet and the water supply line entrances outer door aligned to cabinet. Space between cabinet bottom and floor 600 mm 【...
- Page 20 2 Install the hook on the aesthetic wooden panel and put the hook into the slot of the outer door of dishwasher(see figure 4a). After positioning of the panel , fix the panel onto the outer door by screws and bolts(See figure 4b) . Hop hook 【...
-
Page 21: Tension Adjustment Of The Door Spring
● Tension adjustment of the door spring The door springs are set at the factory to the proper tension for the outer door. If aesthetic wooden panel are installed, you will have to adjust the door spring tension. Rotate the adjusting screw to drive the adjustor to strain or relax the steel cable(see figure 5). -
Page 22: Dishwasher Installation Steps
● Dishwasher installation steps 1 Install the furniture door to the outer door of the dishwasher using the brackets provided. Refer to the template for positioning of the brackets. 2 Adjust the tension of the door springs by using an Allen key turning in a clockwise motion totighten the left and right door springs. - Page 23 Dishwasher must be level for proper dish rack operation and wash performance. Place level on door and rack track inside the tub as shown to check that the dishwasher is level. level the dishwasher by adjusting the four leveling legs individually. When level the dishwasher, please pay attention not to let the dishwasher tip over.
-
Page 24: Positioning The Appliance
Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure that it is fastened tightly in place. If the water pipes are new or have not been used for an extended period of time , let the water run to make sure that the water is clear. - Page 25 Fuse blown, or the Replace fuse or reset circuit breaker. Remove any other circuit breaker acted appliances sharing the same circuit with the dishwasher Power supply is not Make sure the dishwasher is turned on and the door is turned on closed securely.
- Page 26 The dishes were not See notes in " Loading the Dishwasher Baskets ". loaded correctly. The programme was Select a more intensive programme. not powerful enough. See" Wash Cycle Table . " Not enough detergent Use more detergent, or change your detergent. was dispensed.
-
Page 27: Hot Water Connection
Height : 820mm(adjustable+60mm) Width : 595mm Depth : 560mm Voltage connected Load : see rating label Water pressure: 0.04-1.0MPa Hot water connection : max 60 ℃ Power supply: see rating label Capacity: 14 Place settings...
