Summary of Contents for Omega ODW702WB
- Page 1 ODW702WB/ODW702XB 12 place settings 12 place settings half-load function...
- Page 2 For detailed operating instructions read the corres ponding content in the instruction manual. Switch on the appliance Press the Power switch button to switch on the appliance, Open the door. With each wash cycle. Compartment Fill the detergent dispenser For programmes with pre-wash only. (Follow the user instructions!) Check the rinse aid level Electric indicator on control panel (if provided).
- Page 3 Dear Customer, Control Panel...........2 This appliance is in tended to be used in domestic Dishwash er Features........2 household and similar applicatio ns s uch as: -staff kitch en areas in shops, offices and other working en vironme nts; -farm hous es; 、...
- Page 4 When using your dishwasher, follow the precautions listed below: This appliance must be grounded. In the event of a Improper connection of the equipment-grounding malfunction or breakdown, grounding will reduce conductor can result in the risk of an electric shock. the risk of an electric shock by providing a path of Check with a qualified electrician or service least resistance of electric current.
- Page 5 To get the best performance from your dishwasher, read all operating instructions before using it for the first time. 7.If you have only about or less than half of full load 1. Program indicators: to show whic h dishes of the dishwasher, you can sel ect the half load program you hav e chosen;...
-
Page 6: Rinse Aid Dispenser
Before using your dishwas her for the first time: Fill th e rinse a id dispenser Fill in detergent Rinse Aid Dispenser The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. -
Page 7: Adjusting Rinse Aid Dispenser
Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming during the next wash. Don't forget to repla ce the cap before you close dishwasher door. Adjusting Rinse Aid Dispenser The rinse aid dispenser has six or four settings. Always start with the dispenser set on "4". -
Page 8: Amount Of Detergent To Use
Amount of Detergent to Use Detergent powder Detergent tablet If th e lid is close d: press rele ase button. The lid will spring ope n. Always add the dete rgent just before starting each wash cycle. Only use branded detergent aid for d ishwash er. Dishwasher detergent is corrosive! Take care to keep it ou t of reach of c hildren. - Page 9 Consider buying utensils which are identified as dishwasher-proof. Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further information from the detergent manufacturers. For particular items, select a program with as low a temperature as possible. To prevent damage, do not take gla ss a nd c utlery out of the dishwasher immediately after the programme h as ended.
-
Page 10: Adjusting The Upper Basket
The u pper basket is designed to hold more delicate We suggest that you place large items and the most and lighter dishware such as glasses, coffee and difficult to clea n ite ms are to be placed into the lo wer tea cups and saucers, as well as plates, small bowls basket: such as pots, pans, lids, se rving dishes and and shallow pans (as long as they are not too dirty). -
Page 11: Max. Dishes
Cutlery should be placed in the cutlery basket with the han dles at the bo ttom. If the rack has side baskets , the spoons should be loaded sep arately into the appropriate slots, especially long utensils should b e placed in the horizontal position at the fron t of the uppe r basket as shown in the p icture. - Page 12 Means: need to fill the Rinse-Aid Dispenser. ℃ Pre-wash(50 ) For the heaviest soiled ℃ Wash (65 loads, such as pots, pans, Rinse 5/25 g Intensive casserole dishes and dishes Rinse (OrAll that have been sitting with ℃ Rinse(55 ) dried food on them for a Drying while.
-
Page 13: Switch Off The Dishwasher
When you press the Start/Pause button to pause du ring washing, the running indicator will stop blinking and the buzzer will sound every minute unless you press the Start/Pause button to start. Premise: A cycle that is underway can on ly be modified if it has only been running for a short time. Otherwise, the detergent may have already be en released, a nd the appliance may have already drained the wash water. -
Page 14: Filter Assembly
The filter prevents larger remnants of food or other objects from getting inside the pump. The residues may block the filter, in this case they must be removed. The filter system consists of a coarse filter,a flat (Main filter) And a microfilter(Fine filter). Main filter Fo od and soil particles trap ped in this filter are pulverized by a specia l jet on the lower spray arm and washed down to drain. -
Page 15: Cleaning The Filter
Remarks: - Inspect the filters for blo cking a fter e very time the dishwa sher has been used. - By unscrewing the coarse filter, you can remove the filter system. Re move any foo d remna nts and clean the filters under running water. The entire filter assembly should be cleaned once a week. - Page 16 When not in Use for a LongTime After Every Wash It is recommend that you run a was h cy cle with the After every wash, turn off the water supply to the dishwasher empty an d the n remove the plug from the appliance and leave the door slightly open so that socket, turn off the wa ter supply and leave the door of moisture and odours are not trapped inside.
- Page 17 Improper connection of the equipment earthing conductor can result in the risk of an for personal safety: electric shock. DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS APPLIANCE. Check with a qualified electrician or service representative if you are in doubt whether the DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE EARTHING appliance is properly earthed.
- Page 18 How to Drain Excess Water From Hoses If the sink is 1000 higher from the floor, the excess water in hoses cann ot be drained dire ctly into the sink. It will be necessary to drain excess water from hoses into a bo wl o r suitable container that is held outside and lower th an the sink.
- Page 19 Fuse blown, or the Replace fuse or reset circuit breaker. Remove any other circuit breaker acted appliances sharing the same circuit with the dishwasher Make sure the dishwasher is turned on and the door is Power supply is not turned on closed securely.
- Page 20 The dishes were not See notes in " Loading the Dishwasher Baskets ". loaded correctly. The programme was Select a more intensive programme. not powerful enough. See" Wash Cycle Table . " Not enough detergent Use more detergent, or change your detergent. was dispensed.
- Page 21 If overflow occurs, turn off the main water supply before calling a service. If there is water in the base pan because of an overfill or small leak, the water should be removed before restarting the dishwasher. Height : 845mm Width : 598 mm Depth :...
- Page 22 Cups Saucers Glasses Dinner plates Soup plates Dessert dishes Cutlery basket...
- Page 23 Forks Knives Soup spoons 3 Dessert spoons Teaspoons...
