Summary of Contents for Omega DW602XA
- Page 1 Dishwasher Model number：DW602XA...
- Page 2 For detailed operating method read the corresponding content on the instruction manual. Switch on the appliance Press the On/Off button to switch on the appliance, Open the door. With each wash cycle. Compartment Fill the detergent dispenser For programmes with pre-wash only. (Follow the user instructions!) Check the rinse aid level Electric indicator on control panel (if provided).
- Page 3 Dear Customer, Please carefully read this manual bef ore using the Control Panel...........2 dishwasher, it will help you to use and maintain the Dishwasher Features........3 dishwasher properly. Keep it to refer to it at a later date. Pass it on to any subsequent owner of the appliance. 、...
- Page 4 When using your dishwasher, follow the precautions listed below: This appliance must be grounded. In the event of a Improper connection of the equipment-grounding malfunction or breakdown, grounding will reduce conductor can result in the risk of an electric shock. the risk of anelectric shock by providing a path of Check with a qualified electrician or service least resistance of electric current.
-
Page 5: Control Panel Overview
To get the best performance from your dishwasher, read all operating instructions before using it for the first time. 1 ON/OFF Button: To turn on/off the power supply. Display Window: Display program remaining time, delay time, fault codes, etc . 2 Power Light : To come on when the ON/OFF Button is Pressed down. - Page 6 Upper Basket Spray Arms Lower Basket Main Filter Detergent Dispenser Cup Shelf Cutlery Basket Coarse Filter Back View Rinse Aid Dispenser Drain pipe connector Inlet pipe connector...
-
Page 7: Rinse Aid Dispenser
Before using your dishwasher for the first time: Fill the rinse aid disp ense r Fill in detergent Rinse Aid Dispenser The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. -
Page 8: Adjusting Rinse Aid Dispenser
To open the dispenser, turn the cap to the "open" (left) arrow and lift it out. Pour the rinse aid into the dispenser, being careful not to overfill. Replace the cap by inserting it aligned with "open" arrow and turning it to the closed (right) arrow. Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming during the next wash. -
Page 9: Concentrated Detergent
Normally new pulverised detergent is with out phosphate. Thus the water softener function of phosphate is not given. In this case we recommend to fill salt in the salt con taine r even when ° the hardness of water is only 6 dH. If dete rgents witho ut phosphate are used in the case of hard water often white spots appear on d ishes and glasses. -
Page 10: Fill In Detergent
Fill in Detergent Fill the detergent dispenser with detergent. The marking indicate s the dosing levels , as illustrate d on the righ t: The place of main wash cycle deterg ent placed , “ ” MIN me ans approximately 20g of detergent. The place of pre-wash cycle deterge nt placed , approximately 5g o f detergent Plea se o bserve the manufacturers dosing and storage... - Page 11 Consider buying utensils which are identified as dishwasher-proof. Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further information from the detergent manufacturers. For particular items, select a program with as low a temperature as possible. To prevent damage, take glass and cutlery out of the dis hwa sher as soon as possible after the program has ended.
- Page 12 The upper basket is designe d to hold more delica te and lighter dishware s uch as g lasses, coffee and tea cups and saucers, as well as plates, small bowls and shallow pans (as long as they are not too dirty ). Position the dishes and cookware so that they will not get moved by th e sp ray o f water.
- Page 13 The upper rack is for more delicate and lighter dishware such as glasses, coffee & tea cups, saucers, plates, bowls, and shallow pans (provided these are not too dirty). Position the dishes and cookware so that they do not get moved by the spray of water.
- Page 14 Means: need to fill rinse into the Rinse-Aid Dispenser. Pre-wash 50℃ For the heaviest soiled loads, Pre-wash such as pots,pans,casserol e wash 65℃ Intensive dishes and dishes that have 5/27.5 g Rinse been sitting with dried food Rinse on them for a while. Rinse 55℃...
-
Page 15: Switch Off The Dishwasher
Draw out the lower and up per b asket, load the dishes and push them back. It is commended to lo ad the lower bask et first, then the upper one (s ee the sectio n entitled “ ” Loading the Dishwasher ). “... -
Page 16: Filter Assembly
The filter prevents larger remnants of food or other objects from getting inside the pum. The residues may block the filter, in this case they must be removed. The filter system consists of a coarse filter,a flat (Main filter) And a microfilter(Fine filter). Main filter Fo od and soil particles trap ped in this filter are pulverized by a specia l jet on the lower spray arm and washed down to drain. -
Page 17: Protect Against Freezing
Remarks: - Inspect the filters for blo cking a fter e very time the dishwa sher has been used. - By unscrewing the coarse filter, you can remove the filter system. Re move any foo d remna nts and clean the filters under running water. The entire filter assembly should be cleaned once a week. - Page 18 After Every Wash When not in Use for a LongTime It is recommend that you run a was h cy cle with the After every wash, turn off the water supply to the dishwasher empty an d the n remove the plug from the appliance and leave the door slightly open so that socket, turn off the wa ter supply and leave the door of moisture and odours are not trapped inside.
- Page 19 Improper connection of the equipment earthing conductor can result in the risk of an for personal safety: electric shock. DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS APPLIANCE. Check with a qualified electrician or service representative if you are in doubt whether the DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE EARTHING appliance is properly earthed.
-
Page 20: Water Outlet
How to Drain Excess Water From Hoses If the sink is 1000 higher from the floor, the excess water in hoses cann ot be drained dire ctly into the sink. It will be necessary to drain excess water from hoses into a bo wl o r suitable container that is held outside and lower th an the sink. -
Page 21: Troubleshooting
Fuse blown, or the Replace fuse or reset circuit breaker. Remove any other circuit breaker acted appliances sharing the same circuit with the dishwasher Power supply is not Make sure the dishwasher is turned on and the door is turned on closed securely. - Page 22 The dishes were not See notes in " Loading the Dishwasher Baskets ". loaded correctly. The programme was Select a more intensive programme. not powerful enough. See" Wash Cycle Table . " Not enough detergent Use more detergent, or change your detergent. was dispensed.
- Page 23 Height : 850mm Width : 600mm Depth : 600mm Voltage connected Load : see rating label Water pressure: 0.04-1.0MPa Hot water connection : max 60 ℃ Power supply: see rating label Capacity: 14 Place settings...
