Four-Wire Smoke Detector
Figure 4-6 shows how to connect four-wire smoke detectors to the SK-4224 loops. The figure
uses Silent Knight's SLK-24F with HSC-4R base as an example. You can use any UL listed
device. Refer to the Appendix for a list of compatible devices. Information on selecting zone
configuration options is in Section 6.
Figure 4-6 Four-Wire Smoke Detector Wiring
151068
4-5
