:qoF?
to
ConElect
electricity
Forpemoti safety,
thkappliance
mwt
be
properlygrounded.
Xlectrieni T equiremen@
~-voHt models require a 115/120-
volta.c., 60 hz grounded outlet
-.
protected with a 15amp time delay
fuse or circuit breaker.
The power cord on these modelshas
a three-prong (grounding)plug that
mates with a standard three-prong
@rounding)wall outlet (Fig. 1)to
minimize the possibility of electric
shock hazard from these appliances.
PREFERRED
METHOD
Fig. 1
INSUREPROPER
GROUND EXISTS
BEFORE USE
Where a standard two,prong wali
outlet is encountered, it is your
personalresponsibilityand ;bligation
to have it replaced with a properly
grounded three-prong wall outlet.
00 Nm, UNDER ANY
CIRCUMSTNCKS, CUT
OR mMovE THE THIRD
(GROIJND) PRONG FROM
THE Pov#ER CORD.
230/208-volt models
require their
own single branch circuit supplying
230/208-volt a.c., protected with a
time delay fuse or circuit breaker.
This is recommended for best
performance and to prevent
overlo;~di~]g h ouse wiring circuits,
which could cause a possible fire
hazard from overheating wires.
Ti]e p{~wer cord on these models
i]as a L230/203-volt perpendicular
i:~~ldcll~ or large tandem type ping
[hat mutes respectively with a
230/208-voltperpendicular,
tandemor large tandemtype wall
outlet. These types of outletsare
availableat most hardwarestores.
K? @--
230/208-VOLT MATCHING
PERPENDICULAR TYPE WALLOUTLET
LINE CORDPLUG
REQUIRES20 AMP TIME DELAYFUSE
OR CIRCUITBREAKER PROTECTION
Q@
2301208-VOLT MATCHING
TANDEMTYPE WALLOUTLET
LINE CORDPLUG
REQUIRES15 AMP TIME DELAYFUSE
ORCIRCUITBREAKERPROTE~lON
o
mm
@
230/208-VOLT
MAWHING
LARGETANDEMTYPE WALLOUTLET
LINE CORDPLUG
REQUIRES30 AMP TIME DELAYFUSE
OR CIRCUITBREAKERPROTECTION
Whetheryour air conditioner is a
us-volt or a 230/208-volt unit, it
is importint to have the wall
outIet and circuit checked by
a
qualified
electrician if there is
any doubt
as to whether
a proper
ground exisw.
Because of potential safety hazards
under certain conditions, we
strongly recommend
against use
of an adapter plug.
However,
if you still elect to t~sean adapter,
where local codes permit, a
'rEMPoRARY eoNNEaIoN
may be made to a properly grounded
two-pr[~?lg wall ol!tlet by use of a
$JL listed
adapter (Fig.
2) available
x
at most local i~ardwarestores.
TEMPORARY METHOD
(ADAPTER PLUGS NOT
PERMITTED INCANADA)
%
P
ON
Fi
The larger slot in the adaptermustbe
aligned-with the largers16tin thewall
outlet to provide proper polarity in
the connection of the power cord.
CAUTION: Attachingthe adapter
ground terminal to wall outlet cover
screwdoes not groundthe appliance
ufless cover screw is metal, and not
insulated,and walloutletisgrounded "
through house wiring. Youshould
havethecircuitcheckedby a qualifid
electrician to make sure the outlet
is properly grounded.
mentiwomwt~
t hepwer cord
from
theadapter, alwayshold the
adapter with one hand. If this is not
don=,the adap~r ground terminal is
verylikelyto break with repeateduse.
Should the adapter ground
terminal break, DO N~ USE the
appliance until a proper ground
has again been esbblishedo
use Gfewensiom cords
Because of potential safety
hazards under certain conditions,
we strongly IrecQKmemd agakt
the
use of an etiension cord.
However,
if you stfllelect to use all extension
cord, it is absolutely necessary that
it be a UL listed 3-wire grounding
type appliance extension cord and
that the current carrying rating of
the cord in amperes be equal to or
greater than the branch circuit size
shown on the rating nameplate of
the appliance. Such extension cords
are ob~inable through your local
service organization.
3
—
