- Page 1 3950 NW 120 Ave, Coral Springs, FL 33065 TEL 561-955-9770 FAX 561-955-9760 NNG-Honda 3 Navigation interface for New Honda Accord/Odyssey NTV-KIT555/584 NTV-DOC225...
- Page 2 NTV-DOC225 Honda Accord 2013-2015 / Odyssey 2014-2015 Installation This is a NEW VERSION (HONDA 3) for Honda Accord and Odyssey. Please pay attention to this installation guide as MOST COMPONENTS HAVE CHANGED. DO NOT MIX WITH COMPONENTS FROM PREVIOUS VERSION AS DAMAGES MIGHT OCCUR. WARRANTY DISCLAIMER NOTICE! Radio removal, disassembly, installation of Navigation Electronics, and Radio re-assembly / re-installation is the responsibility of the installer.
- Page 3 NTV-DOC225 Honda Accord 2013-2015 / Odyssey 2014-2015 Installation Review the overall wire connections in the figure above HONDA-3 Component list GPS Module Main Harness – HONDA3-20PIN ** Touch Panel with TP-IN – see touch panel part number for accord / odyssey Display Y Cable –...
- Page 4 NTV-DOC225 Honda Accord 2013-2015 / Odyssey 2014-2015 Installation P a g e...
- Page 5 NTV-DOC225 Honda Accord 2013-2015 / Odyssey 2014-2015 Installation Connect HONDA3-20PIN main T-harness to radio (DO NOT CONNECT DISPLAY Y CABLE HERE) Connect Display Y Cable at the side of screen See instruction below for dip switch settings DIP Switch Settings DIP switches 1 –...
- Page 6 NTV-DOC225 Honda Accord 2013-2015 / Odyssey 2014-2015 Installation Accord Touch Panel Installation (*beware of the differences from Odyssey) Remove factory clear lens FIRST, do not reinstall! Lift clips on top and bottom of the screen housing to remove display screen Align the supplied touch panel to the top of screen as indicated Notice the touch panel ribbon cable for Accord is at the TOP of screen.
- Page 7 NTV-DOC225 Honda Accord 2013-2015 / Odyssey 2014-2015 Installation Odyssey Touch Panel Installation (*beware of the differences from Accord) Remove factory clear lens FIRST, do not reinstall! Remove screws from top (2) and behind (4) the display screen to remove screen housing Remove the frame from screen Place touch panel as indicated Orient the touch panel as indicated...
- Page 8 NTV-DOC225 Honda Accord 2013-2015 / Odyssey 2014-2015 Installation GPS Audio Integration for Factory Equipped External Amp By default, this system is wired for factory radio with internal amp (non-touch screen radio). If you are installing this system to premium sound radio with touch screen, you will have to do the following modification to the wiring in order to avoid “pop”...
- Page 9 NTV-DOC225 Honda Accord 2013-2015 / Odyssey 2014-2015 Installation (Or) 'BACK-DET' (Or) Right Turn Signal BACK-DET (Or) ACC+ (Black) Trigger + (Red) Right Turn Signal - (Green) P a g e...
- Page 10 NTV-DOC225 Honda Accord 2013-2015 / Odyssey 2014-2015 Installation Honda Crosstour LDW and Reverse wires CROSSTOUR reverse wire at dash fuse box CROSSTOUR right turn wire in steering column Honda Odyssey LDW and Reverse wires ODYSSEY reverse wire at dash fuse box ODYSSEY right turn wire in steering column P a g e...
-
Page 11: Troubleshooting
NTV-DOC225 Honda Accord 2013-2015 / Odyssey 2014-2015 Installation Trouble Shooting Please follow all the steps in this installation manual, failure to do so might void the product warranty and damage the factory radio Power Navigation system should have (2) led lights on the module box for indication of power and data connections.
