Hardware Upgrade Preparations
System Board Components
Continued
Ref.
Component
9
Secondary processor slot
10
DIMM sockets 1-4. DIMM1 is closest to the edge of the system
board.
11
Processor power module connector (for secondary processor)
12
AGP expansion slot
13
Processor power module connector (for secondary processor)
14
SW1 switch
15
Riser board connector
