Compaq SP700 Reference Manual page 151

5. Change the jumper from pins 6-7
Figure E-2. Changing the jumper from pins 6-7 to pins 5-6
6. Place the pale blue sticker included with the battery kit above the power
connector on the back of the workstation.
7. Replace the expansion board assembly and the side access panel.
8. Plug the power cord into a grounded AC outlet.
9. Turn on the workstation.
10. Run Computer Setup to reconfigure the system.
11. If the workstation has a Compaq hard drive, you have now successfully
completed the installation.
If the workstation has a third-party hard drive, you must reconfigure the hard
drive using the parameters you recorded before you began the installation
procedure.
to pins 5-6 .
1
Compaq Professional Workstation SP700 Reference Guide
2
E-3
