Ref. Component
1 Power on/off LED
2 Power button
3 Hard drive activity LED
4 Network activity LED
5 Bay 4 - CD-ROM drive
6 Bay 5
7 Bay 6
8 Bay 7 -diskette drive
9 Speaker
Table 1-2
Front Panel Components
After plugging the power cord into a grounded AC
outlet and the workstation, if the LED is:
Off - Workstation is ready to be powered up.
Steady Amber - Either the expansion board
assembly or the processor/processor terminator
board is not seated properly.
After pressing the power button, if the LED is:
Steady Green - Workstation is turned on, and
both the expansion board assembly and the
processor/processor terminator board are seated
properly.
Blinking green - Workstation is in standby mode.
Turns the workstation on or off
When lit, indicates the workstation is reading or
writing data to the hard drive(s)
When lit, indicates the workstation is receiving
or sending data on the network
5.25-inch, half-height drive bay
5.25-inch, half-height drive bay
5.25-inch, half-height drive bay
3.5-inch, third-height drive bay
PremierSound with fixed equalization
