SA Indoor Unit
1. Operation mode selector button
• Press this button to select the operation
mode of your preference.
* Available modes vary with the connecting
model.
2. Fan speed control button
• Press this button to select the fan speed of
your preference.
* Available fan speed vary with
the connecting model.
3. Menu/Enter button
• Used to indicate the main menu.
• Used to enter the setting item selected.
4. Up button
part with the symbol )
• Used to raise the set temperature.
• The next items on the upper side will be
highlighted.
(The highlighted items will be scrolled
continuously when the button is kept
pressed.)
• Used to change the item selected.
5. Down button
the part with the symbol )
• Used to lower the set temperature.
• The next items on the lower side will be
highlighted.
(The highlighted items will be scrolled
continuously when the button is kept
pressed.)
• Used to change the item selected.
6. Right button
the part with the symbol )
• Used to highlight the next items on the
right-hand side.
• Each screen is scrolled in the right-hand
direction.
• Home leave settings are enabled with this
button kept pressed for at least four
seconds.
129
(Be sure to press the
(Be sure to press
(Be sure to press
7. Left button (Be sure to press
the part with the symbol )
• Used to highlight the next items on the
left-hand side.
• Each screen is scrolled in the left-hand
direction.
• Home leave settings are enabled with this
button kept pressed for at least four
seconds.
8. On/Off button
• Press this button and system will start.
• Press this button again and system will
stop.
9. Operation lamp (Green)
• This lamp lights up during operation.
• This lamp blinks if a error occurs.
10. Cancel button
• Used to return to the previous screen.
11. LCD (with backlight)
• The backlight will be light for approximately
30 seconds by pressing any operation
button. Operate buttons excluding the On/
Off button while the backlight is lit.
• If two remote controllers are used to control
a single indoor unit, the backlight of the
remote controller operated earlier than the
other one will be lit.
SiBE121123_A
Remote Controller
