Input Format — Press the navigation buttons to select an analog video input format for
inputs 1 and 2. All other inputs are digital inputs for HDMI or DVI input signals. The following
table shows the available formats for each input.
Input 1
Input 2
RGB (default)
HDMI (default)
YUV
S-Video
Composite
NOTE: Input 1 does not automatically detect the format.
Film Mode — Press the navigation buttons to turn Film Mode 3:2 and 2:2 detection on
(auto detect mode) or off.
Start — Press the
and
Left
Press the
and
buttons to adjust the vertical (V) pixel start value. This applies to
Up
Down
analog inputs only.
Active — Press the
and
Left
the
and
buttons to adjust the vertical (V) active pixels. This applies to analog inputs
Up
Down
only.
Total Pixels and Phase — Press the
the image. Press the
and
Up
analog inputs only.
HDCP Authorized — Press the navigation buttons to enable or disable the HDCP
Authorized feature. This feature determines if a digital input will report as an HDCP
authorized sink to a source.
For source devices that require encryption, enable HDCP Authorized. If HDCP Authorized
is disabled for sources that require encryption (for example, a Blu-ray player), the output is
muted or a warning message is displayed.
Some source devices may encrypt their output even if the source material does not require
HDCP encryption, preventing content from being displayed on a non-HDCP compliant
display. Disable HDCP Authorized to allow the output of the scaler to remain unencrypted.
EDID — Press the navigation buttons to select an EDID for the active input. Select a
discrete EDID from a list of factory-supplied EDID or select
resolution and refresh rate (see
resolution and refresh rates).
Input 3
HDMI (default)
HDMI (default)
buttons to adjust the horizontal (H) pixel start value.
Right
buttons to adjust the horizontal (H) active pixels. Press
Right
and
buttons to adjust the total pixels of
Left
Right
buttons to adjust the phase of the image. This applies to
Down
Output Resolution
on page 23 for a full list of available
IN1604 DTP and IN1604 HD Scalers • Operation
Input 4
to use the output
Match Output
21
