OPERATION 41
(NOT AVAILABLE FOR ALL MARKETS &
ALL MODELS)
OIL BATH AIR CLEANER - - Fig. 50
Remove the filter parts and wash them with kerosene
(paraffin). After cleaning and drying, refill with fresh
engine oil up to the level line stamped into the side
of the bowl. Re--install the bowl assembly.
OPERATION 42
FUEL SEDIMENTER- - Fig. 51
Unscrew the drain plug (1) fig. 51. Turn the
sedimenter element (2) completely to remove.
Replace the fuel sedimenter with new one. Install the
drain plug and tighten
OPERATION 43
ENGINE VALVES - - Fig. 52
Contact your dealer to check the clearance between
the
valves
and
(0.35 ± 0.05 mm; 0.012 ± 0.002 inches).
The inspection must be carried out when the engine
is cold.
4--24
SECTION 4 - - LUBRICATION AND MAINTENANCE
EVERY 600 HOURS OF WORK
it carefully
.
EVERY 900 HOURS OF WORK
the
rocker
TRE0831A
arms
2
1
1
50
51
52
