- Page 1 ORIGINAL INSTRUCTIONS OPERATOR’S MANUAL 266WMM Mower Deck PIN YJWR00241 and above for Workmaster 25 Compact Tractor ™ Part number 51558669 edition English June 2019...
- Page 2 OM 0471MW-A rev3 10-18 717966336 19-05-22+29 PRÉLIMINAIRE 3 CORRECTIONS SIMON FAITES ATTENTE VALIDATION POUR ENVOYER À ERAN...
-
Page 3: Introduction
INTRODUCTION TO THE PURCHASER All products are designed to give safe, dependable TO THE DEALER service if they are operated and maintained Give this manual to the owner upon delivery of the according to instructions. Read and understand equipment. this manual before operation, and keep it in TO THE PURCHASER AND THE DEALER your files for further reference. - Page 4 INTRODUCTION All products are designed to give safe, dependable service if they are operated and maintained according to instructions. Read and understand this manual before operation. It is the owner's responsibility to be certain anyone operating this product reads this manual, and all other applicable manuals, to become familiar with this equipment and all safety precautions.
-
Page 5: Table Of Contents
TABLE OF CONTENT INTRODUCTION ..........................1 TABLE OF CONTENT ........................... 3 SAFETY INFORMATION ........................5 GENERAL SAFETY INFORMATION- Pictograms ................7 SPECIFICATIONS ..........................9 SAFETY LABELS ..........................10 ESTIMATED ASSEMBLY TIME ......................11 ASSEMBLY ............................12 Mower Assembly ........................12 Tractor 3-point Pins &... - Page 6 TABLE OF CONTENT OPERATION ............................23 General Preparation ........................23 Operating Controls ........................23 Engine Speed ......................23 Up and Down Control ....................23 Engaging the Drive Mechanism ................. 23 Transport Locking ....................... 23 MAINTENANCE ............................ 24 Maintenance ..........................24 Sharpening and Balance of blades ................
-
Page 7: Safety Information
SAFETY INFORMATION Children Tragic accidents can occur if the operator is 4. For your safety, do not work under any not alert to the presence of children. Children hydraulically supported machine elements, they are generally attracted to machines and the creep down, suddenly... - Page 8 SAFETY INFORMATION 17. Check all machine controls regularly and 8. Park the machine/implement on level ground, adjust where necessary. Make sure that the place the transmission in neutral, set the parking brakes are evenly adjusted. Periodically brake, disengage the driving system, lower the check all nuts and bolts for tightness, equipment to the ground, place all levers especially wheel hub and rim nuts.
-
Page 9: General Safety Information- Pictograms
GENERAL SAFETY INFORMATION OM 0471MW-A... - Page 10 GENERAL SAFETY INFORMATION (1) Safety stand 2) Secure point for safety stand OM 0471MW-A...
-
Page 11: Specifications
SPECIFICATIONS 66" LAWN MOWER Features and Specifications 717966336 HOUSING Cutting width – in (cm) 66 (168) Construction Welded drive-over floating deck Blades quantity Blade length – in (cm) 23 (58) diagonal Blades thickness - in (mm) 1/4 (6) Blade overlap - in (cm) 1 5/16 (3) Weight - lbs (kg) 423 (192) -
Page 12: Safety Labels
SAFETY LABELS Replace immediately if damaged OM 0471MW-A [10]... -
Page 13: Estimated Assembly Time
ESTIMATED ASSEMBLY TIME Refer to the following table for the estimated assembly time to open the package and assemble the equipment. 66" Lawn Mower 717966336 Estimated initial installation time 90 -120 min Reinstallation (on the tractor) 4-6 min The assembly times of the table are only a reference under normal conditions according to the following assumptions: 1. -
Page 14: Assembly
ASSEMBLY OWER SSEMBLY The mower is pre-assembled at the factory; however, parts in the bag and box must be assembled. Use the present manual and lay out all parts for assembly. Separate bolts and nuts into various sizes. After assembly, torque all the bolts according to the "Torque Specification Table" enclosed at the end of the manual. -
Page 15: Locking Mower Bracket Installation
ASSEMBLY Locking Mower Bracket Installation (figures 3-4) 1. Figure 3: Attach the transport link (item 1) to the transport bracket (item 2) with a M12 x Figure 3 40mm hex bolt (item 3), 12mm flat washer (item4), 7/16" flat washer (item 5) between the transport link and transport bracket and a M12 nylon insert locknut (item 6). -
Page 16: Middle Supports Installation On Tractor With Front Loader
ASSEMBLY Middle Supports Installation on Tractor WITH FRONT LOADER (figures 5-6) NOTE : WITHOUT FRONT LOADER 3. Figure 6: Install the middle support (item 2) If you install the mower on a tractor not over the front loader plate of the front loader equipped with a front loader, a side bracket tower and secure with one M14 x 60mm hex kit is required. -
Page 17: Side Brackets Of The 439054016 & Middle Supports
ASSEMBLY Side Brackets of the 439054016 and Middle Supports Installation on Tractor WITHOUT FRONT LOADER (figures 7-8-9) 1. Figure 7: Secure the mower rear push 4. Figure 9: Insert the appropriate side lifting arm bar (item 1) underneath the tractor (item 1) onto the appropriate side middle support transmission (item 2) with two hex bolt (item 2) and secure in place a 1/4"... -
Page 18: Lifting Arms Installation
ASSEMBLY Lifting Arms Installation (figure 10) 4. Figure 10: Then bolt all this assembly into the 1. Figure 10: Align the three last holes of long thread bushing of the rear lifting lever (item the rear lifting lever (item 1) with the three 1) and adjust at the dimension as shown. -
Page 19: Remove Grill Guard
ASSEMBLY Remove Grill Guard Figure 11 Figure 11: The grill guard (item 1) needs to be removed for the installation of the front support. Remove the four hex bolts (item 2) lockwashers (item 3). The grill guard will be reinstalled with new hardware in a further step. Front Supports Installation 1. -
Page 20: Deflectors Installation
ASSEMBLY Deflectors Installation (figures 14-15) Figure 14 1. Figure 14: Install the rubber deflector (item 1) between the deflector support (item 2) and the deflector reinforcement (item 3). Secure with six 3/8"NC x 1 1/4" carriage bolts (item 4), 3/8" x 1 1/2" OD flat washers (item 5) and 3/8"NC nylon insert locknuts (item 6). -
Page 21: Front Anchor Installation
ASSEMBLY Front Anchor Installation (figures 17-18-19) 1. Figure 17: Attach the front "U" anchor Figure 17 (item 1) to the anchor rod (item 2) with two 1"NS nylon insert locknuts (item 3). Tighten slightly. 2. Figure 18: Install the front "U" anchor assembly (item 1) to the mower front anchors (item 2). -
Page 22: Roll Over Step
ASSEMBLY Roll Over Step (figures 20A-20B-20C) IMPORTANT: Adjust the wheels to the lower cutting height before climbing the mower. 1. Figure 20A: Start the tractor engine and Figure 20A slowly advance toward the mower, as much perpendicular as possible. Align the tractor front wheels with the grip welded over the top mower deck. -
Page 23: Lifting Arms And Driveline To Tractor Installation
ASSEMBLY Installation of the Lifting Arms and Front Anchor Rod Installation (figure 22) Driveline to Tractor (figure 21) 1. Figure 22: Pull out the latch (item 3) until it completely goes out of the hole and rotate it 1. Figure 21: Connect the driveline (item 1) to slightly until the end is against the plate. -
Page 24: Removing Mower From The Tractor
ASSEMBLY Removing Mower from Tractor (figures 24-25) Figure 24 1. Figure 24: Lower the tractor 3-point hitch to maximum. 2. Figure 24: Disconnect the driveline (item 4) from the PTO under the tractor. Lay it down relatively on the middle of the mower, away from the tractor wheels. -
Page 25: Operation
OPERATION PERATING ONTROLS ENERAL REPARATION Engine Speed 1. Read the operator's manual carefully before using the tractor and mower. Be 1. Start the tractor engine. Let the engine warm thoroughly familiar with the controls and up at least one minute before engaging the proper use of the equipment. -
Page 26: Maintenance
MAINTENANCE Sharpening and Balance of blades AINTENANCE (figures 27-28) ALWAYS USE GENUINE PARTS WHEN IMPORTANT: It is important to wear protective REPLACEMENT PARTS glasses and gloves when you manipulate the REQUIRED mower blades. 1. Figure 27: Sharpen the blades with an angle WARNING grinder, a file or an electric grinder. -
Page 27: Blade Replacement
MAINTENANCE Blade Replacement (figures 29-30) 1. BLADE INSPECTION Figure 29: The edge of the blades must always be kept sharp as shown on figure 22-A. Grind the sharp edges if they look as shown on figure 22-B. Figure 29 Replace the blades if they look as shown on figure 22-C. -
Page 28: Belt Replacement
MAINTENANCE Belt Replacement (figures 31-31a-31b) 5. Do the reverse step for reinstallation. 1. Figure 31: Untighten the wing nut and pivot the latch (item 1) lift the left and/or 6. The spring must be at 8 5/8" between the hooks right belt guards (item 2 and 3) at an as shown in Figure 31b. -
Page 29: Adjustments
MAINTENANCE DJUSTMENTS WARNING To avoid serious personal injury: ake sure tractor engine and mower come to a complete stop and tractor drive mechanism is disengaged BEFORE making any adjustments. Belt Adjustment (figures 32-32a-32b) 1. According to the belt supplier the belt tension will need to be check after 24 and 48 hours of Figure 32a utilisation. -
Page 30: Cutting Height Adjustment
MAINTENANCE Cutting Height Adjustment (figure 33) 1. To adjust the mower cutting height, raise the mower to maximum. 2. Figure 33: Remove the circle cotter (item 2) and the 3/8" x 2 1/4" pin (item 1). Adjust front wheel (item 3) to the desired height. Reinstall the pin and secure with the circle cotter (item 2). -
Page 31: Lubrication
MAINTENANCE UBRICATION Use a good grease gun and lubricate as follows: INTERVAL SERVICE REQUIRED If operating in dry conditions, clean debris from mower Lubricate the CV ball with a quality lithium soap compatible E.P. grease 4 hours meeting the N.L.G.I. #2 specification and containing no more than 1% molybdenum disulfide (5 lever action pumps) Lubricate spindles, driveshaft, bearing, wheels, front wheel pivot, mower lift kit 24 hours... -
Page 32: Troubleshooting
MAINTENANCE ROUBLESHOOTING WARNING: Several corrective measures present a certain risk, which may cause WARNING: engine parts serious injuries or death. hydraulic oil can cause serious burns. Only a qualified person, familiar with the risks Always engine cool before associated with hydraulics, electricity and proceeding with repairs or maintenance. - Page 33 MAINTENANCE PROBLEM CAUSE CORRECTIVE MEASURE • • Cutting height too low Raise the cutting height • • Swing speed too fast Reduce the swing speed • • 4. Blades tear the Bumps in field Change mowing layout • • grass Hilly ground or irregular Adjust the anti-scalp rollers •...
- Page 34 MAINTENANCE PROBLEM CAUSE CORRECTIVE MEASURE STREAKING Thin strips of uncut grass are left behind the mower. Streaking is usually caused by operator error or poor blade maintenance • Sharpen your blades. • Blades are not sharp. • Replace your blades. •...
-
Page 35: Parts
PARTS NDER ART OF OWER RAME ESCRIPTION Under ejection deflector BER672097 Ejection deflector BER672171 Carriage bolt 3/8"NC x 1" lg PTD BER0300008 Nut hex 3/8"NC PTD BER0900003 Lockwasher 3/8" PTD BER1200004 Flat washer 3/8" (7/16" int) PTD BER1400004 Anti-scalp roller 2 1/2" x 6" - 9/16" hole BER3800075 Roll pivot pin 1/2"... -
Page 36: Upper Part Of Mower Frame
PARTS PPER ART OF OWER RAME ESCRIPTION Right belt guard BER672705 Left belt guard BER672706 Joint with threaded rod 3/8”NF BER4600071 Pin 3/8" x 1 5/8" lg PTD BER4600039 Wing nut 3/8”NF PTD BER1100038 Pin 3/8" x 2 1/4" lg PTD BER4600059 Circle Cotter 1 1/8"... - Page 37 PARTS PPER ART OF OWER RAME OM 0471MW-A [35]...
-
Page 38: Front Hitch Components
PARTS RONT ITCH OMPONENTS ESCRIPTION Front anchor rod BER669991 Anchor lever BER672087 Latch BER669894 Cotter pin 3/32" x 1 1/4" BER1500003 Compression spring ø.906"OD x 4 1/4" x 0.050" wire BER2200024 Front support BER 672086 Spacer plate BER672113 Hex bolt M16 x 2.00 x 60mm Gr.10.9 PTD BER0200137 Hex nut M16 x 2.00 PTD BER0900051... - Page 39 PARTS RONT ITCH OMPONENTS OM 0471MW-A [37]...
-
Page 40: Rear Hitch Components
PARTS ITCH OMPONENTS ESCRIPTION Front lifting lever BER672106 Rear lifting lever BER672107 Carriage bolt 1/2"NC x 1 3/4" PTD BER0300025 Flat washer 1/2"(9/16" int) PTD BER1400006 Lockwasher 1/2" PTD BER1200006 Nylon insert locknut 1/2"NC PTD BER1000011 Cotter pin 3/16" x 2" lg PTD BER1500014 Flat washer 3/4"... - Page 41 PARTS ITCH OMPONENTS OM 0471MW-A [39]...
-
Page 42: Drive System
PARTS RIVE YSTEM ESCRIPTION Gearbox support BER672707 Pulley protector BER672091 Gearbox CW 1 @ 1.43 – ø1”-15 splines x ø1” with keyway BER4500213 - Seal kit BER4500141 Pulley ø6” BER4800050 Hex bolt 5/16"NC x 1" Gr.5 PTD BER0100019 Lockwasher 5/16" PTD BER1200003 Flat washer 5/16"(3/8"... - Page 43 PARTS RIVE YSTEM OM 0471MW-A [41]...
-
Page 44: Deflector
PARTS EFLECTOR ESCRIPTION Deflector support BER672094 Rubber deflector BER672096 Deflector reinforcement BER672095 Deflector pivot pin 7/16" X 9 13/16" lg BER672715 Torsion spring 23/32"ID X 2 1/2" x 0.12 wire BER2200026 Carriage bolt 3/8"NC x 1 1/4" lg Gr.5 PTD BER0300009 Flat washer 13/32"... -
Page 45: Wheels
PARTS HEELS ESCRIPTION Wheel shaft PTD BER669893 Front wheel support BER672099 Wheel bushing BER669940 Wheel 6 1/4" x 3" - 3/4" roller bearing BER3800077 Shoulder plastic bushing 1 1/4"OD x 1"ID x 1"lg BER4300099 Outer retaining ring 0.042 thick for 1" shaft BER655087 Bolt hex 1/2"NC x 5"... -
Page 46: Spindle
PARTS – BER5000017 PINDLE ESCRIPTION Flat washer 26mm x 50mm x 4mm PTD BER1400034 Bearing 6206_rs1 BER4300095 Bearing 6305_rs1 BER4300096 Lockwasher mb-5 BER4300097 Nut M25 x 1.5 km-5 BER4300098 Spindle hub BER5000018 Round end key 8 x 7 x 25 BER5000019 Grease fitting M8 x 1.0 BER5000020... -
Page 47: Driveline
PARTS – BER4700335 RIVELINE ESCRIPTION Male driveline 1"-15 splines and clamp yoke BER4700336 Male shaft 1"-15 splines and yoke BER4700225 Clamp yoke 1" – 15 splines BER4700339 Journal cross kit 6E BER4700130 Female driveline and Quick disconnect yoke 1”-15 splines BER4700337 Female shaft 1"-15 splines and yoke BER4700338... -
Page 48: Complement Kit For Tractor Without Loader
PARTS - 439054016 OMPLEMENT KIT FOR RACTOR WITHOUT OADER DESCRIPTION PART# Right side bracket BER672124 Left side bracket BER672125 Front push bar for mower BER672728 Rear push bar for mower BER672729 Bolt hex M12 x 1.75 x 30mm Gr. 10.9 PTD BER0200139 Lockwasher 12mm PTD BER1200019... -
Page 49: Torque Specification Table
TORQUE SPECIFICATION TABLE ENERAL SPECIFICATION TABLE SE THE FOLLOWING TORQUES WHEN SPECIAL TORQUES ARE NOT GIVEN Note:These values apply to fasteners as received from supplier dry, or when lubricated with normal engine oil. They do not apply if special graphited or moly sidulphide greases or other extreme pressure lubricants are used. These values apply to dry conditions;... - Page 52 Availability of some models and equipment builds varies according to the country in which the equipment is being used. For exact information about any particular product, please consult your New Holland dealer. © 2019 CNH Industrial America LLC. All Rights Reserved.
