OPERATING INSTRUCTIONS
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
INSTALLATION AND
GSST8N
NATURAL GAS
GSST8P
WARNING: FOR OUTDOOR USE ONLY
WARNING
!
CAN-2.21-M85
IAS US. 4-96
PROPANE
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS UNTIL
COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
1.22B
W415-0689 / C / 06.13.12
1
